Product Name:

Honeywell Experion PKS Series C General Purpose Output / Analog Output Module (GOA-X02 type, 8-Channel Analog Output)

Product Description:

An 8-channel analog output (AO) module for the Honeywell Experion PKS Series C I/O subsystem, delivering 4–20 mA or 0–20 mA signals to field actuators through the associated FTA (Field Termination Assembly).

Category: Honeywell

Description

Technical Specifications:

Channels: 8 isolated analog outputs
Output Signal: 4–20 mA DC (default), 0–20 mA configurable
Load Resistance: ≤ 750 Ω @ 24 VDC external loop supply
Accuracy: ± 0.1 % of full scale typical
Update Rate: Per control execution cycle (typically 100–500 ms)
Backplane Power: 24 VDC from I/O rack
Isolation: 500 VAC channel-to-backplane, channel-to-channel non-isolated (common loop supply)
Operating Temp: 0 °C to +60 °C
Certifications: CE, UL, cUL, FM Class I Div 2 (selected versions)

Features:

Open-circuit detection per channel
D/A converter with drift compensation
LED status: Module OK, Comm OK, Fault
Hot-swappable in live rack (with proper procedure)

Applications: Valve positioners, I/P converters, variable speed drive setpoints, recorder inputs in process plants.

Construction & Materials: Series C molded housing, gold-edge connector, surface-mount DAC circuitry, conformal-coated PCB (option).

Working Principle: Receives digital output command from C300 controller via I/O link → on-board D/A converter generates proportional current → current sourced/sunk through FTA terminals to field instrument loop.

Installation & Precautions:

Use proper FTA (e.g., AO FTA with loop power terminals).
Ensure external 24 VDC loop power polarity is correct.
Do not exceed maximum loop resistance; check cable length.
Ground shield at one point only (typically at FTA).
Remove module only after acknowledging in system software for safe hot-swap.
