Honeywell CC-TUIO31

Product Brief

9-inch non-redundant multi-signal wiring terminal base exclusively designed for CC-PUIO31 32-channel universal IOM; supports mixed analog input, analog output, digital input, digital output and pulse frequency signal termination on single terminal unit; integrates multi-type signal surge protection, HART coupling, channel isolation and pulse signal conditioning circuits, unified mechanical wiring interface for all universal field signal types.

Category: Honeywell

Description

Technical Specifications

Form Factor Length: 9-inch non-redundant chassis
Supported IOM Quantity: Single CC-PUIO31 universal I/O IOM per CC-TUIO31
Total Channel Terminal Count: 32 multi-function configurable signal channels
Supported Field Signal Types: 4–20 mA analog, 0–10 VDC voltage, RTD, TC, dry/wet digital contact, 0–10 kHz pulse frequency
Surge Withstand Rating: 36 VDC transient voltage per channel
Channel-to-Bus Galvanic Isolation Voltage: 2500 VAC
HART Signal Passband: 1200 Hz standard HART communication
Terminal Screw Torque Rating: 0.8 N·m recommended tightening torque
Acceptable Wire Gauge: 24 AWG to 14 AWG solid/stranded copper wire
Operating Temperature Range: -40 °C to +70 °C
Physical Dimensions: 228 mm × 105 mm × 28 mm
Net Weight: 0.33 kg

Functional Features

Multi-signal universal terminal circuit compatible with all CC-PUIO31 software-configurable channel signal types
Per-channel independent surge suppression circuits for analog, digital and pulse signals
Integrated HART signal coupling hardware for bidirectional HART instrument communication on analog channels
Hardware pulse signal conditioning filter for 0–10 kHz frequency input signals
Full channel galvanic isolation eliminating cross-signal interference between analog and digital circuits
Front terminal block labeled channel numbering aligned with CC-PUIO31 software channel addressing
Rear edge connector mechanical lock mating with CC-PUIO31 universal I/O IOM module
