Emerson DeltaV KJ2222X1-BA1

Product Introduction:​
The KJ2222X1-BA1 is a DeltaV Series 2 I/O module for use in Emerson DeltaV distributed control systems. Depending on carrier and terminal block combination it functions as a 16-channel 24 V DC discrete (sinking/sourcing) output module or specialty I/O. It interfaces field devices to the DeltaV controller via the local bus and supports online module replacement.
Category:
Description
Technical Specifications (typical for Series 2 DO):
  • Manufacturer:​ Emerson Automation Solutions (Fisher-Rosemount)
  • Model / Part No.:​ KJ2222X1-BA1
  • Series:​ DeltaV Series 2
  • Module Type:​ Discrete Output (24 V DC, 16-channel typical) — verify with your terminal block (e.g. VE4002 etc.)
  • LocalBus Power:​ 12 V DC, 150 mA max
  • Field Power (Bussed):​ 24 V DC, up to 600 mA per carrier (shared among modules)
  • Output Rating per Channel:​ 0.5 A @ 24 V DC (typical sinking type; check terminal block polarity)
  • Isolation:​ Channel-to-bus isolation; group isolation between channels (usually grouped in 8s)
  • Diagnostics:​ Open-wire detection (on some terminal blocks), module health LED, short-circuit protection per group
  • Hot-Swap:​ Yes — can be replaced under power
  • Operating Temp:​ -40 °C to +70 °C
  • Humidity:​ 5 %–95 % non-condensing
  • Certifications:​ Class I Div 2 Groups A-D T4; CE; FM; CSA
  • Weight:​ ~0.18 kg
Functional Features:
  • Auto-sensing of carrier type
  • Software configurable fail-safe state per channel
  • Force capability via DeltaV software (with security)
  • Integrates with DeltaV alarm and event system
Installation Notes:
  • Insert into DeltaV I/O carrier (e.g. KJ4001X1-xxx); secure with retaining screw
  • Use correct terminal block (e.g. VE4002 for 24 V DC DO) — mixing types causes misconfiguration
  • Field power must be correctly fused per plant standard
  • Earth I/O chassis to plant ground
Applications:​ On/off valve solenoid control, motor start permissive, pump run command, stack/annunciator driving in process plants.
