B&R 3IF152.60-2 REV.C0

Product Introduction

The B&R 3IF152.60-2 REV.C0 is an 8-channel analog input module for the B&R X20 series I/O system. It acquires current (4–20 mA) and voltage (0–10 V) signals from field sensors including pressure transmitters, temperature transmitters, flow meters, and level sensors. The module features 16-bit A/D conversion, channel-to-channel isolation, and is designed for use in machine automation, packaging, and process control applications. REV.C0 is the third hardware revision of this module.

Category: B&R

Description

Technical Specifications

Parameter	Value
Manufacturer	B&R Industrial Automation (ABB Group)
Part Number	3IF152.60-2
Revision	REV.C0
Series	X20 I/O System
Channels	8 single-ended (or 4 differential)
Input Type	4–20 mA (2-wire) / 0–10 V
Resolution	16-bit (65,536 steps)
Accuracy	±0.1% of full scale (typical)
Sampling Rate	10 kS/s (aggregate), 1.25 kS/s per channel
Isolation	500 V DC channel-to-channel, 500 V DC channel-to-bus
Supply Voltage	24 V DC (via X20 bus), 19.2–30 V DC
Power Consumption	< 2 W
Operating Temperature	0°C to +55°C
Protection Class	IP20
Mounting	DIN rail TS35
Dimensions	90 mm × 120 mm × 62 mm
Standards	CE, UL 508, EN 61131

Functional Features

8 independent analog input channels with individual configurable ranges
Auto-detection of 4–20 mA or 0–10 V input type per channel
Differential mode available for noise-prone environments (4 channels)
On-board signal conditioning: filtering, linearization, scaling
LED status indicators per channel (Power, Activity, Fault)
Hot-swappable on the X20 bus
Diagnostic buffer stores last 100 samples per channel for troubleshooting

Performance Parameters

Parameter	Specification
Conversion Time	80 µs per channel
Linearity Error	±0.02% of full scale
Temperature Drift	±5 ppm/°C
Common Mode Rejection (CMR)	> 100 dB (differential mode)
Noise (RMS)	< 10 µV (voltage mode), < 1 µA (current mode)
MTBF	> 150,000 hours
Bus Communication	X20 bus, 100 Mbit/s

Material Composition

Component	Material
PCB	FR-4, 6-layer, ENIG finish
Analog Front-End IC	Texas Instruments ADS1256 (24-bit ADC, configured for 16-bit)
Isolation Barriers	Silicon-based digital isolators (Analog Devices ADuM1401)
Connectors	Weidmüller, screw-clamp, rated 6 mm²
Housing	Polycarbonate, UL94 V-0
Terminal Blocks	Phoenix Contact, rated 10 A, 600 V

Structural Features

DIN rail mounting (TS35, 7.5 mm pitch)
X20 bus connector on the rear for daisy-chaining with other X20 modules
Front-facing LED array: 8 channel indicators + bus status
Terminal blocks arranged in 2 rows of 4 for easy wiring
Lockable screw terminals — vibration-resistant

Working Principle

Each analog input channel passes through a precision shunt resistor (250 Ω for 4–20 mA) or a voltage divider (for 0–10 V). The conditioned signal is fed into a 24-bit sigma-delta ADC (ADS1256), which operates at 16-bit effective resolution. The digital value is transmitted across a 500 V DC galvanic isolation barrier to the X20 bus interface. The B&R CPU (X20 CP1541, CP1548, etc.) reads the values via the X20 bus and applies user-configured scaling and engineering unit conversion in the Automation Studio software.

Advantages & Highlights

16-bit resolution — superior to competing 12-bit modules in the same class
500 V DC isolation — eliminates ground loops in multi-sensor installations
Auto-ranging — no manual jumper settings required for 4–20 mA vs 0–10 V
Diagnostic buffer — captures transient events that standard scanning misses
Fully compatible with B&R Automation Studio 4.x software
REV.C0 improvements: updated ADC for lower noise, revised terminal block layout for faster wiring

Applicable Industries

Industry	Application
Packaging	Fill level, pressure, temperature monitoring
Machine Building	Hydraulic pressure, spindle load, coolant flow
Food & Beverage	Tank level, temperature, flow rate
Plastics	Melt pressure, mold temperature
Water/Wastewater	Flow metering, chemical dosing

Model Series

Part Number	Channels	Input Type
3IF152.60-1	4	4–20 mA / 0–10 V
3IF152.60-2	8	4–20 mA / 0–10 V
3IF154.60-2	8	Thermocouple (TC)
3IF156.60-2	8	RTD (PT100)

Installation Requirements

Mount on DIN rail TS35 with at least 10 mm spacing between modules
Connect 24 V DC power to the X20 bus via the first module in the chain
Use shielded twisted-pair cables for analog signals — maximum run 50 m
Ground cable shields at the controller end only
Verify input signal range matches module configuration in Automation Studio before commissioning

Usage Precautions

Do not apply voltage > 12 V DC or current > 24 mA to any input — permanent damage to the ADC
Never disconnect sensors while the module is powered — inductive kickback can destroy the input stage
Differential mode uses 2 channels per measurement — plan channel allocation accordingly
Update Automation Studio to version 4.5.2 or later for REV.C0 compatibility
Calibrate annually using a precision signal source (Fluke 754 or equivalent)
