Bently 330704-000-050-10-02-05 Eddy Current Sensor Probe

• Power Supply Module:
  • Input Voltage: 100–240 VAC, 50/60 Hz, 2 A.
  • Output Voltage: 24 VDC (5.5 A max for single power supply; 7.5 A max for redundant setup).
  • Power Capacity: 190–250 W (adjustable based on load).
  • Operating Temperature: 0°C to 60°C (storage: -40°C to 70°C).
  • Protection: Overload, short-circuit, and overvoltage protection.
  • Certifications: Complies with CCC and industrial safety standards.

Technical Specifications

• Manufacturer: Bently Nevada
• Product Type: PLC Process Variable Monitor Card
• Series Compatibility: 3500 Series Monitoring System
• Input/Output Configuration:
  • Analog input channels: 8 channels (compatible with magnetic pickup sensors and proximity probes)
  • Analog output channels: 8 channels
• Input Signal Specifications:
  • Compatible sensor types: Magnetic pickup sensors, proximity probes
  • Input signal range: Configurable for standard industrial process variables
• Power Requirements:
  • Input voltage: 12 VDC
• Environmental Ratings:
  • Operating temperature: -40 °C to +90 °C
  • Storage temperature: -40 °C to +100 °C
  • Vibration resistance: Compliant with industrial vibration standards for rack-mounted equipment
  • Electrical interference immunity: Meets EMC industrial standards

Technical Specifications

• • Input Parameters
    • Input type: Low-level analog signals (voltage, current, or resistance-based sensor inputs)
    • Input channels: 4 differential or 8 single-ended input channels
    • Input range: Configurable for ±5 VDC, ±10 VDC, 0–5 VDC, 4–20 mA, or 10–30 mA
    • Input impedance: ≥ 100 kΩ for voltage inputs; ≤ 10 Ω for current inputs
    • Common-mode rejection ratio (CMRR): ≥ 80 dB at 50/60 Hz (minimizes interference from common-mode signals)
  • Output Parameters
    • Output type: Standardized analog output (4–20 mA DC or 0–10 VDC)
    • Output accuracy: ±0.05% of full scale (at 25 °C ambient temperature)
    • Output resolution: 16-bit (ensures precise signal representation)
    • Output load capacity: Up to 500 Ω for 4–20 mA output; ≥ 10 kΩ for voltage output
  • Electrical Requirements
    • Power supply: 24 VDC ±10% (compatible with standard industrial power systems)
    • Power consumption: ≤ 2.0 W (low energy consumption for continuous operation)
    • Reverse polarity protection: Integrated (prevents module damage from incorrect wiring)
    • EMI/RFI immunity: Complies with IEC 61000-6-2 (industrial environment electromagnetic compatibility standards)

Technical Specifications

• Input Parameters
  • Input type: Accepts signals from piezoelectric accelerometers or velocity sensors
  • Input range: Configurable for acceleration (0–500 m/s²), velocity (0–50 mm/s), or displacement (0–1000 μm)
  • Frequency response: 0.5 Hz to 10,000 Hz (covers most industrial rotating machinery needs)
  • Input impedance: ≥ 10 MΩ (ensures minimal signal loss from sensors)
• Output Parameters
  • Output type: 4–20 mA DC current loop (standard industrial output)
  • Output accuracy: ±0.1% of full scale (at 25 °C ambient temperature)
  • Output load: Up to 750 Ω (compatible with most DCS/PLC input modules)
  • Additional output: Optional relay output (for alarm triggering, based on configuration)
