Bently 330105-02-12-10-02-05 8mm Reverse Mount Proximity Probe - Image 1

Bently 330105-02-12-10-02-05 8mm Reverse Mount Proximity Probe - Image 2

Bently 330105-02-12-10-02-05 8mm Reverse Mount Proximity Probe

Product Overview
The Bently 330105-02-12-10-02-05 is an 8mm reverse mount proximity probe designed for the Bently Nevada 3300 XL series vibration monitoring system. It measures the gap between the probe tip and observed conductive surfaces, converting this distance into a proportional voltage output. This enables real-time monitoring of static (position) and dynamic (vibration) parameters in rotating machinery, supporting predictive maintenance and fault prevention.

Category: Bently

Description

Technical Specifications

Part Number: 330105-02-12-10-02-05
Manufacturer: Bently Nevada (a Baker Hughes business)
Probe Type: 8mm reverse mount proximity probe
Cable Length: 1.0 meter (3.3 feet)
Connector Type: Micro ClickLoc coaxial connector
Temperature Range: -51°C to +177°C (-60°F to +351°F)
Linear Range: 2mm (0.08 inches)
Sensitivity: 7.87 V/mm (200 mV/mil) ±5%
Frequency Response: 0–10 kHz
Mechanical Configuration: Reverse mount design for space-constrained installations
Certifications: CSA, ATEX, IECEx approved for hazardous environments

Functional Features

Reverse Mount Design: Enables installation in tight spaces where standard probes cannot fit.
High Precision: Provides accurate gap measurements with minimal drift, ensuring reliable vibration and position data.
Robust Construction: Built to withstand harsh industrial environments, including high temperatures, vibrations, and electromagnetic interference.
Interchangeability: Fully compatible with other 3300 XL series probes, extension cables, and proximity transmitters without requiring individual matching or calibration.
Easy Installation: Features a ClickLoc connector for secure, tool-free attachment to extension cables.
Environmental Resistance: Protected against oil, water, and other contaminants, ensuring long-term reliability.

Application Scenarios

Vibration Monitoring: Measures axial and radial vibration in rotating machinery such as turbines, generators, compressors, and pumps.
Position Measurement: Monitors shaft position and alignment to prevent rubbing, misalignment, and bearing damage.
Keyphasor Reference: Provides a timing reference for vibration signal phase analysis, supporting fault diagnosis and dynamic balancing.
Speed Measurement: Calculates rotational speed by detecting tooth or keyway passages on rotating components.
Oil Film Bearing Machines: Ideal for applications where space constraints limit probe installation options.

Key Advantages

High Reliability: Designed to meet API 670 standards, ensuring consistent performance in critical applications.
Reduced Downtime: Early fault detection enables proactive maintenance, minimizing unplanned outages.
Cost-Effective: Eliminates the need for frequent recalibration or replacement, lowering lifecycle costs.
Seamless Integration: Works with existing Bently Nevada 3300 XL monitoring systems, protecting prior investments.
