ABB PP835A 3BSE042234R2 Touch Panel

Technical Specifications

• Display:
  • Size: 6.5 inches
  • Resolution: 640 x 480 pixels
  • Colors: 16-bit true color
  • Type: TFT LCD with touch functionality
• Touch Technology: Multi-touch support (finger and glove-compatible)
• Interfaces: RS-232, RS-485, Ethernet
• Power Supply: 24V DC
• Operating Temperature: 0°C to 50°C
• Dimensions:
  • Depth/Length: 180 mm
  • Height: 270 mm
  • Width: 76.5 mm
• Weight: 1.48 kg
• Housing Material: Industrial-grade, durable design for harsh environments

Key Features

• High Visibility: High-brightness and high-contrast display ensures clear visibility under various lighting conditions.
• Multi-Touch Support: Enables intuitive operation with fingers or gloves, enhancing user convenience.
• Rich Graphic Display: Supports graphics, animations, and text for comprehensive data visualization.
• Multiple Communication Interfaces: Facilitates seamless integration with PLCs and other devices via RS-232, RS-485, and Ethernet.
• Robust Design: Built to withstand industrial challenges such as vibrations, temperature fluctuations, and humidity.
• Modular Structure: Part of the ABB Panel 800 series, offering flexibility with various sizes and functionalities.
• Advanced Functionality: Includes alarm management, trend graphs, and recipe management for enhanced process control.
• Open Platform: Supports multiple programming languages and third-party software for customized solutions.

Application Scenarios

• Manufacturing: Monitors and controls production lines, machinery, and automated workstations, ensuring efficient and synchronized operations.
• Process Control: Manages industrial processes in sectors like chemicals, petroleum, and food and beverage, maintaining product quality and operational safety by monitoring parameters such as temperature, pressure, liquid level, and flow rate.
• Power Industry: Oversees power distribution, generation, and substation equipment to ensure stable and reliable electricity supply.
• Building Automation: Controls lighting, HVAC, and security systems in smart buildings, improving energy efficiency and occupant comfort.
• Water Treatment: Supervises treatment processes, pumps, and gas analyzers in water and wastewater plants, ensuring water quality and environmental compliance.
• Traffic Control: Manages traffic signals, railway signals, and tunnel safety equipment for safe and efficient transportation systems.

Additional Highlights

• Fan and Pump Control: Specifically designed for fan and pump applications, the PP835A offers enhanced Power Factor Correction (PFC) functionality, enabling control of up to seven pumps with cyclic soft start capabilities.
• Flexible U/F Curves: Allows users to define five-point U/F curves, adapting to diverse application requirements.
• Dual Independent PID Controllers: Features two built-in PID controllers (PID1 and PID2), with PID1 supporting two sets of parameters and PID2 controlling an independent external valve, ensuring high precision and flexibility in control.
• Diverse Display Modes: Supports envelope mode, average mode (with coefficients from 2 to 64), and XY mode, allowing users to switch modes based on specific needs for optimal data presentation.
• Comprehensive Measurement and Calculation: Provides FFT analysis, digital operations, pointer measurements, and multimeter modes, meeting various measurement and calculation demands across applications.
