ABB PM564-RP-ETH

• Integrated I/O:
  • Digital Inputs (DI): 6
  • Digital Outputs (DO): 6
  • Analog Inputs (AI): 2
  • Analog Outputs (AO): 1
• Output Type: Relay
• Power Supply: 24 V DC
• Communication Interface:
  • Integrated Ethernet port (supports web server functionality)
  • 1 x RS485 serial interface (configurable as RS-485, Modbus RTU, free protocol, or CS31)
  • Optional second RS485 interface
• Expansion Capability: Supports up to 10 local I/O modules (standard S500 or S500-eCo series)
• Data Storage: Optional SD card adapter for program backup and data logging
• Processing Speed:
  • Bit operations: 0.08 μs
  • Word operations: 0.1 μs
  • Floating-point operations: 1.2 μs

Functional Characteristics

• Flexible Communication: The integrated Ethernet port enables seamless integration into industrial networks, supporting protocols such as Modbus TCP and proprietary ABB protocols. The RS485 interface provides compatibility with a wide range of devices and systems.
• High Reliability: Designed for industrial environments, the module features robust hardware with protection against voltage surges, reverse polarity, and electromagnetic interference.
• Easy Programming: Compatible with ABB’s Automation Builder software, which includes the Control Builder Plus programming environment. This software supports ladder logic, function block diagram, and structured text programming languages.
• Modular Design: The module can be expanded with additional I/O modules to meet specific application requirements, providing scalability and flexibility.
• Web Server Functionality: The integrated Ethernet port includes a built-in web server, allowing for remote monitoring and configuration via a standard web browser.

Application Scenarios
The ABB PM564-RP-ETH is suitable for various industrial automation applications, including:

• Machine Control: Used in the control of individual machines or small production lines, such as packaging machines, assembly lines, and material handling systems.
• Building Automation: Manages HVAC systems, lighting control, and access control in commercial buildings.
• Water Treatment: Controls pumps, valves, and monitoring equipment in water and wastewater treatment plants.
• Energy Management: Monitors and controls energy consumption in industrial facilities, optimizing efficiency and reducing costs.
• Process Control: Used in small-scale process control applications, such as chemical dosing, temperature control, and flow monitoring.

Mechanical Specifications

• Dimensions: 132 mm (H) x 105 mm (W) x 52 mm (D)
• Weight: 800 g
• Mounting: 35 mm DIN rail mounting
• Enclosure Rating: IP30 (protection against solid objects and limited water ingress)
• Operating Temperature: -10 °C to 70 °C (wide temperature range option available: -40 °C to +85 °C)
• Storage Temperature: -40 °C to 80 °C
• Relative Humidity: ≤90% (non-condensing)

Certifications and Compliance
The ABB PM564-RP-ETH complies with various international standards, including:

• EN55022: Electromagnetic compatibility (EMC) standards for information technology equipment.
• EN61000-4-2: Immunity to electrostatic discharge (ESD).
• EN61000-4-3: Immunity to radiated electromagnetic fields.
• EN1122: Test standards for heavy metals and hazardous substances.
