ABB PFTL201C 10KN 3BSE007913R10 Tension Sensor

Technical Specifications

• Rated Load: 10 kN (10,000 N)
• Accuracy: ±0.1% FS (Full Scale)
• Repeatability: ≤0.03% FS
• Response Time: ≤350 ms
• Output Signal: 4-20 mA or 0-10 V (standard analog signals)
• Power Supply: 24 V DC ±10%
• Protection Class: IP67 (dustproof and waterproof)
• Operating Temperature: -30°C to +80°C
• Material: Stainless steel (17-4PH) for durability and corrosion resistance
• Mounting: Supports horizontal force measurement with anti-vibration design (IEC 60068-2-6 compliant)
• Cable: Fixed cable with protective sheath (ATEX Zone 2 compatible for explosive environments)

Key Features

• High Precision: ±0.1% FS accuracy ensures consistent tension control, reducing material waste and improving product quality.
• Robust Design: Stainless steel construction withstands harsh industrial conditions, including humidity, dust, and chemical exposure.
• Fast Response: Sub-400 ms response time enables real-time tension adjustments, preventing defects like wrinkles or breaks.
• Temperature Compensation: Built-in algorithm minimizes measurement errors caused by temperature fluctuations (full-range error <0.05% FS).
• Overload Protection: Supports 150% rated load (15 kN)瞬时 overload without damage, enhancing operational safety.
• Flexible Integration: Compatible with Profibus-DP, Ethernet/IP, and ABB Ability™ platforms, as well as third-party PLCs (e.g., Siemens S7-1500, Rockwell ControlLogix).
• Easy Maintenance: Modular design allows quick installation and calibration, with LED indicators for status monitoring.

Application Scenarios

• Metal Processing:
  • Monitors tension in cold/hot rolling lines to maintain ±0.5 μm thickness tolerance, reducing breakage rates by 40%.
  • Used in aluminum foil slitting (6-12 μm thickness) to eliminate wrinkles and improve yield to 99.2%.
• Paper & Packaging:
  • Controls tension in high-speed paper machines (1,200–1,500 m/min) to prevent breaks and enhance surface quality.
  • Optimizes material handling in packaging lines, minimizing褶皱 (creases) and edge damage.
• Textile & Film:
  • Ensures uniform tension in optical-grade PET film production, achieving thickness uniformity (CV ≤1.5%).
  • Supports nanoscale tension control in lithium battery separator manufacturing, improving pore consistency and safety.
• Renewable Energy:
  • Stabilizes tension in fuel cell membrane production, ensuring nanometer-level thickness accuracy.
  • Used in solar panel backsheet coating to reduce material fragmentation by 15%.
• General Industry:
  • Ideal for light-to-medium-duty applications like CNC machining, conveyor systems, and robotic material handling.

Additional Advantages

• Industry Compliance: Meets IEC 60068-2-6 (vibration resistance), ATEX Zone 2 (explosion-proof), and RoHS standards.
• Predictive Maintenance: Supports remote diagnostics via ABB Ability™, enabling proactive component replacement and reducing downtime.
• Cost Efficiency: Lowers maintenance costs by 10% through durable design and extended service life (>10 years).
