ABB PFEA111-65 3BSE050090R65 Tension Controller

Technical Specifications

• Power Supply: 24 V DC
• Power Consumption: 8 W (at 24 V)
• Input Current: 250 mA (+5 V), 10 mA (+3.3 V)
• Output Current: 0.5 A RMS, 330 Hz
• Input Impedance: 10 kΩ
• Number of Inputs: 2 (for load cell inputs)
• Outputs: Voltage and current outputs (A+B)
• Display: Shows signals A, B, A+B, and A-B
• Operating Temperature: +5 to +55 °C (32 to 131 °F)
• Non-operating Temperature: -40 to +70 °C (-40 to 158 °F)
• Dimensions: 180 x 120 x 100 mm
• Weight: 1.9 kg
• Enclosure Rating: IP 20 (unsealed), designed for wall mounting

Functional Characteristics

• High Precision Control: Utilizes advanced control algorithms to achieve precise tension control, ensuring material stability during processing.
• Stable Performance: Features reliable hardware design and excellent anti-interference capabilities, enabling stable operation in various industrial environments.
• Easy Installation and Maintenance: Compact size supports DIN rail or wall mounting, facilitating integration into electrical cabinets.
• Rich Functionality: Includes adjustable filtering to effectively eliminate interference signals and supports ramp and triangular wave outputs.
• Tension Measurement: Accurately measures material tension by converting analog signals from load cells into intuitive tension data.
• Tension Control: Automatically adjusts material tension based on set values to maintain stable tension within the desired range.
• Signal Processing: Processes sensor input signals through filtering and amplification to improve signal quality and accuracy, providing a reliable basis for tension control.

Application Scenarios

• Printing and Packaging Industry: Used in printing machines, rewinders, and slitting machines to control the tension of paper and plastic films, ensuring printing and packaging quality.
• Textile Industry: Controls yarn and fabric tension in textile machinery such as spinning machines, looms, and dyeing machines to prevent yarn breakage and fabric deformation.
• Metal Processing Industry: Manages tension in metal rolling and wire drawing processes to ensure product dimensional accuracy and surface quality.
• Cable Manufacturing Industry: Controls the tension of insulating materials and conductors during cable production to guarantee cable performance and quality.
• Rubber and Plastics Processing Industry: Used in extrusion, calendering, and blow molding processes to control the tension of rolled or sheet materials, preventing deformation or breakage.
