ABB IPS21-35AD Fieldbus Connector Module

Technical Specifications

• Model Number: IPS21-35AD (3BHB017688R0001)
• Connector Type: CANBUS 5-pin “mini” female contact with 7/8-16 UN-2A THD female connection thread.
• Design Compliance: Meets ANSI/B93.55M-1981 standards for design and interchangeability.
• Electrical Connections:
  • Base Connection: Multi-contact TSS+2/25 water, G1/2″-14 thread.
  • Upper Arm Connection: Multi-contact TSB+2/25 water, G1/2″-14 external thread.
• Fiber Optic Support:
  • Supports 155M fiber optic interfaces for high-speed, long-distance data transmission.
  • Fiber distance capability of up to 20 km.
• Network Topologies: Supports point-to-point, chain, star, redundant dual-network, and fiber ring self-healing protection.
• Power Supply: DC9-36V wide redundant dual power supply with DC1500V power isolation and reverse connection protection.
• Protection Features:
  • 4000V lightning protection, 1.5A overcurrent protection, and 600W surge protection.
  • IP30 protection rating for industrial environments.

Functional Characteristics

• High-Speed Data Transmission: Enables reliable data transfer at high speeds over long distances, supporting up to 12 Mbps communication rates.
• Redundant Network Support: Features logic-independent dual Profibus DP buses for redundant dual-network fiber ring topology, enhancing system reliability.
• Self-Healing Fiber Ring: Automatically rebuilds network links within 10ms in case of fiber faults, ensuring continuous communication.
• Rich Status Indicators: Equipped with six bicolor LED status indicators for easy monitoring of network and module status.
• Easy Installation: Designed for DIN rail mounting, facilitating quick and easy installation in control panels.

Application Scenarios

• Industrial Automation: Used in manufacturing lines for connecting PLCs, sensors, and actuators, ensuring efficient data acquisition and control.
• Power Generation: Integrates with turbine control systems in power plants for monitoring and controlling generator operations.
• Water Treatment: Supports data communication in water treatment plants for chemical dosing, flow measurement, and quality monitoring.
• Renewable Energy: Facilitates communication in solar and wind farms for efficient energy management and grid integration.
• Building Automation: Manages HVAC systems, lighting, and security in commercial buildings, providing centralized control and monitoring.

Key Advantages

• High Reliability: Designed for long-term operation in harsh industrial environments, ensuring stable and consistent performance.
• Flexible Configuration: Supports multiple network topologies and communication protocols, meeting diverse application requirements.
• Easy Maintenance: Features hot-swapping capability and comprehensive diagnostics for quick troubleshooting and maintenance.
• Scalability: Easily integrates with existing control systems, supporting system expansion and upgrades.
