ABB IMAS102 Digital Valve Driver Module

Technical Specifications

• Input Voltage: TTL-compatible (5 VDC) for logic-level signals.
• Output Voltage: Nominal 24 VDC (26 VDC maximum, 2 VDC minimum).
• Output Current: 0.6 Amps maximum per channel; 6.4 Amps maximum total per module.
• Isolation: 2500 Vrms optical isolation between channels.
• Power Supply: External supply required (e.g., GE Fanuc IC690PWR 24).
• Response Time: Less than 0.5 seconds for both turn-on and turn-off with resistive loads.
• Leakage Current: 26 µA at 26 VDC operating voltage.
• Voltage Drop: 0.32 VDC under full load.
• Indicators:
  • DIG CH:1–4: LEDs illuminate when corresponding inputs are at logic level.
  • PWR: Indicates presence of +26 VDC input power.

Functional Characteristics

• Multi-Channel Control: Simultaneously manages up to four solenoid valves, reducing the need for multiple modules.
• High Isolation: Optical isolation prevents interference between channels, enhancing system reliability.
• Fast Response: Sub-0.5-second activation and deactivation times ensure quick valve operation.
• Diagnostic Indicators: LEDs provide real-time status feedback for inputs and power.
• Compact Design: Space-efficient form factor simplifies integration into control panels.
• Robust Construction: Built to withstand industrial environments with stable performance under varying loads.

Application Scenarios

• Process Control Systems: Used in chemical, petrochemical, and water treatment plants for fluid control.
• Industrial Automation: Manages pneumatic or hydraulic actuators in manufacturing and assembly lines.
• Power Generation: Regulates valves in steam turbines, boilers, and cooling systems.
• Oil and Gas: Controls injection and extraction valves in upstream and downstream operations.
• Food and Beverage: Ensures precise ingredient dosing and hygienic process control.
• HVAC Systems: Modulates dampers and valves in heating, ventilation, and air conditioning units.
