ABB E5LA HENF105296R0001 Industrial Filter Module

Technical Specifications

• Product Type: Industrial Transmit Filter Module
• Part Number: E5LA HENF105296R0001
• System Compatibility: ABB Bailey INFI 90, ABB 800xA DCS
• Primary Function: Signal filtering, harmonic suppression, EMI reduction
• Operating Voltage: 24 V DC nominal
• Isolation: Galvanic isolation between input and output circuits
• Frequency Response: Optimized for industrial control signal bandwidths
• Operating Temperature: -25°C to +70°C
• Storage Temperature: -40°C to +85°C
• Relative Humidity: 5%–95% (non-condensing)
• Protection Rating: IP20 (cabinet-mounted)
• Mounting: DIN rail mountable
• Dimensions: Standard modular form factor for control cabinet integration
• Weight: Approximately 1.0 kg
• Certifications: CE, UL, IEC 61131-2, RoHS compliant
• Country of Origin: Sweden

Key Features

• Advanced Signal Filtering: Effectively eliminates high-frequency noise, electrical harmonics, and transient interference from control signals, ensuring pure and stable signal transmission.
• Galvanic Isolation: Provides complete electrical isolation between input and output circuits, preventing ground loops, fault propagation, and cross-channel interference.
• Industrial-Grade Durability: Constructed with high-quality components to withstand vibration, shock, and extreme temperature fluctuations, ensuring continuous operation in demanding industrial environments.
• Wide Compatibility: Seamlessly integrates with ABB’s Bailey INFI 90 and 800xA DCS platforms, offering plug-and-play functionality for easy system integration.
• Compact Modular Design: Features a space-saving modular form factor, optimizing cabinet space utilization and supporting flexible system configuration.
• High Reliability: Delivers consistent performance with low failure rates, minimizing system downtime and reducing maintenance costs.
• Harmonic Suppression: Specifically designed to suppress harmonic distortions generated by variable frequency drives (VFDs) and other power electronics, improving overall power quality.
• Easy Installation: Equipped with clearly labeled terminal blocks for straightforward wiring, reducing installation time and minimizing errors.
• Long Service Life: Engineered for extended operational lifespans, providing reliable performance over extended periods in 24/7 industrial operations.
• EMI/RFI Protection: Offers robust protection against electromagnetic and radio frequency interference, safeguarding sensitive control systems from external disturbances.

Application Scenarios

Process Industries

• Power Generation: Filters control signals from turbine governors, boiler instrumentation, and generator protection systems in thermal, hydro, and renewable power plants, ensuring stable operation of critical control loops.
• Oil & Gas: Suppresses EMI in control signals for wellhead monitoring, pipeline automation, and refinery process control systems, maintaining signal integrity in hazardous and electrically noisy environments.
• Chemical & Pharmaceutical: Cleans control signals from pressure transmitters, flow meters, and temperature controllers in reaction vessels and processing lines, ensuring accurate process control and regulatory compliance.
• Water & Wastewater Treatment: Filters signals from level sensors, pump controls, and valve positioners in water treatment plants and distribution networks, preventing interference from pump motors and variable frequency drives.
• Mining & Metals: Protects control signals in mineral processing equipment, conveyor systems, and smelting operations from high levels of electrical noise generated by heavy machinery.

Manufacturing & Automation

• Automotive Production: Filters signals from robotic controllers, assembly line sensors, and welding equipment, ensuring precise motion control and reducing downtime due to signal interference.
• Electronics Manufacturing: Cleans control signals in SMT lines, pick-and-place machines, and semiconductor fabrication equipment, where high signal purity is critical for precision manufacturing.
• Food & Beverage: Suppresses interference in control signals for packaging lines, bottling equipment, and processing machinery, maintaining consistent product quality and production efficiency.
• General Machinery: Protects control signals in CNC machines, material handling systems, and industrial robots from electrical noise generated by motor drives and power electronics.

Power Electronics & Drives

• Variable Frequency Drives (VFDs): Filters harmonic distortions and EMI generated by VFDs, improving power quality and protecting connected control systems from interference.
• Motor Control Centers: Integrates with motor control circuits to filter noise and ensure reliable operation of motor starters, contactors, and protective relays.
• Uninterruptible Power Supplies (UPS): Cleans output signals from UPS systems, ensuring stable power delivery to sensitive control equipment and instrumentation.

Infrastructure & Utilities

• Substation Automation: Filters control and monitoring signals in electrical substations, protecting SCADA systems and protection relays from power line interference.
• Building Automation: Cleans signals in HVAC control systems, lighting controls, and building management systems, ensuring reliable operation in commercial and industrial facilities.
• Telecommunication Infrastructure: Suppresses EMI in control signals for telecom power systems and network equipment, maintaining stable communication links.

OEM Equipment Integration

• Industrial Machinery: Serves as a standard filtering component for original equipment manufacturers (OEMs) integrating ABB control systems into custom industrial machinery.
• Test & Measurement Equipment: Filters signals in precision test and measurement systems, ensuring accurate data acquisition and analysis.
