GE

Technical Specifications

• Hardware Architecture
  • Input Voltage: 125V DC (operational range: 70–145V DC) .
  • Output Voltage: 5V DC (logic supply) and 28V DC (actuation supply) .
  • Sampling Rate: Up to 100 Hz for real-time monitoring of turbine speed, vibration, and other parameters .

Technical Specifications:

• It operates as a servo interface module, playing a critical role in interfacing between the servo valve and the turbine control system.
• Voltage and current specifications are tailored to ensure compatibility with various servo valves used in turbine applications.
• The module supports precise signal conversion and transmission essential for accurate control of hydraulic actuators associated with fuel valves or other turbine mechanisms.



• Processor: 1066 MHz EP80579 Intel processor
• Input/Output: 2 Hall effect pulse inputs, 2 analog inputs, 4 digital I/O (DIOs)
• Redundancy: Supports triple modular redundancy (TMR), simplex, and dual redundancy
• Operating Voltage: 220 V
• Frequency Output: 50 kHz
• Operating System: QNX Neutrino operating system

Technical Specifications

• Voltage/Power:
  • Operating voltage: 120V AC/DC or 220V AC (varies by configuration).
  • Power consumption: ≤25W for standard models.
• I/O Capabilities:
  • 1200 input/output points for connecting sensors, actuators, and other field devices.
  • Supports analog/digital signals, including 4-20mA, 0-10V, and thermocouple inputs.
• Communication:
  • RS485, Modbus RTU, CAN, and Ethernet for integration with SCADA systems or HMIs.
  • Optional PROFINET, DeviceNet, or PROFIBUS for factory automation.

Technical Specifications:

• Function: Servo Output Board
• Compatibility: Designed for use with the Mark VI and Mark Vie Speedtronic turbine control systems.
• Channels: Typically includes multiple channels for controlling different servo mechanisms.
• Signal Processing: Converts digital control signals from the system into analog outputs to drive servos.
• Power Supply: Operates within specified voltage ranges suitable for industrial environments.
• Environmental Conditions: Rated for operation under specific temperature and humidity conditions, ensuring reliability in demanding settings.

The GE 369-HI-R-M-F-E-H-E (also referred to as the Multilin 369 Motor Management Relay) is a high-performance industrial device designed for advanced motor protection, monitoring, and control in mission-critical applications. As part of GE’s Multilin product line, it combines robust hardware with programmable logic to ensure reliability in harsh environments.
