Technical Specifications:

• I/O Capacity: Supports up to 64 I/O modules (8 modules per rack, with a maximum of 8 racks).
• Memory: 1024 discrete input points, 1024 discrete output points, 128 bytes of analog input memory, and 128 bytes of analog output memory.
• Transmission Speed: Supports up to 153.6 kbaud for extended network configurations, with standard speeds of 153.6 kbaud, 76.8 kbaud, and 38.4 kbaud.
• Bus Connections: Dual Genius bus terminals (upper terminal for primary connection, lower terminal for redundancy).
• Power Consumption: 250 mA at 4VDC and 10 mA at 3.3VDC.

Product Introduction The GE IC200MDD842B is a discrete hybrid I/O module designed for the VersaMax series by GE (now part of Emerson Automation Solutions). It serves as a key component in industrial automation systems, facilitating the connection and control of various discrete input and output devices. This module is known for its robustness, reliability, and versatility in handling different industrial applications. Technical Specifications

• Module Type: Discrete hybrid I/O module
• Series: VersaMax
• Input/Output Points: The module supports a combination of discrete input and output points, allowing for flexible configuration based on application requirements.

Product Description The GE IC200MDL240B is a discrete input module from the GE Fanuc VersaMax I/O series . It is designed to receive AC voltage signals from field devices and convert them into digital signals for the PLC backplane. The module provides 16 input points, organized into two groups of eight channels, with each group sharing a dedicated common .

Technical Specifications:

• Input Channels: 16 non-isolated inputs, divided into two groups of eight channels each.
• Voltage Ratings:
  • Nominal operating voltage: 240 VAC.
  • Operating voltage range: 0 to 264 VAC.
  • On-state voltage range: 155 VAC to 264 VAC.
  • Off-state voltage range: 0 to 40 VAC.
• Current Consumption:
  • Maximum backplane current consumption: 110 mA at 110.0 V.
  • Maximum operating current: 5.0 mA at 110.0 V from the backplane.

Technical Specifications

• Module Type: Discrete output module
• Series: VersaMax
• Output Points: 16 outputs
• Output Type: Sourcing type (positive logic)
• Output Voltage Range: 10.2 to 30 VDC (compatible with 12/24 VDC nominal external power supply)
• Backplane Current Consumption: 45 mA

Product Introduction The IC200MDL740E is a discrete output module from the GE Fanuc VersaMax I/O series, designed to translate internal PLC logic signals into physical switching actions for external industrial devices. This module features 16 independent output points with positive logic (sourcing) characteristics, operating at a nominal supply voltage of 24 VDC to drive a wide range of actuators and indicators .
