GE IC693CPU313 5‑Slot Embedded Turbo CPU Baseplate for Series 90‑30 PLC Systems
Product Overview
The IC693CPU313 is a compact, all‑in‑one embedded CPU baseplate designed by GE Fanuc (now part of Schneider Electric) for the Series 90‑30 PLC platform, integrating a turbo CPU directly into a 5‑slot baseplate. It features an 80188 16‑bit processor running at 10 MHz, a 12 KB user program memory, and a built‑in serial port, serving as a cost‑effective, non‑expandable solution for small‑to‑medium industrial control applications. The module delivers a fast scan rate of 0.6 ms per 1K Boolean logic, supports up to 160 discrete I/O points each for inputs and outputs, and enables communication via SNP/SNP‑X slave protocols, making it ideal for standalone automation systems requiring reliable, real‑time control.
GE IC693CMM321 Ethernet Interface Module (TCP/IP Module) for Series 90-30 PLC Systems
Product Overview
The IC693CMM321 is a single-slot Ethernet interface module engineered by GE Fanuc (now part of Schneider Electric) for the Series 90-30 Programmable Logic Controller (PLC) platform. It serves as a critical communication gateway, enabling seamless integration between Series 90-30 PLCs and Ethernet networks via an external transceiver and AAUI cable, supporting both client and server communication roles. The module facilitates real-time data exchange with hosts, HMIs, SCADA systems, remote I/O, and third-party industrial devices, making it essential for distributed control and industrial automation networks.
GE IC695CPU310-ACAT
Product Introduction
The IC695CPU310-ACAT is a single-slot VME CPU module of the PACSystems RX3i family, built for real-time control of industrial machines, processes, and material handling systems. It features a 300 MHz Intel Celeron (Pentium III) processor, 10 MB RAM, and 10 MB non-volatile flash user memory, with battery-backed data retention via IC695ACC302 lithium smart battery. It has 2 front-facing serial ports (RS-232 and RS-485) and works with RX3i universal backplanes, supporting up to 512 program blocks and Series 90-30 I/O for seamless migration. Programming is via Proficy Machine Edition using Ladder Diagram, Structured Text, Function Block Diagram, and C, delivering reliable processing and flexible integration for industrial automation applications.
GE IC695CPE310CA-ABAN
Product Introduction
The IC695CPE310CA-ABAN is a 2-slot, high-performance multicore CPU module in the PACSystems RX3i family, designed for real-time control of complex machines, industrial processes, and distributed automation systems. It integrates a 1.1 GHz dual-core Intel Atom processor, 10 MB RAM, and 10 MB non-volatile flash user memory, with battery-less data retention via the IC695ACC400 Energy Pack. It comes with 2 switched gigabit Ethernet ports, 1 isolated RS-232/485 serial port, and 1 USB 2.0 Type-A port, supporting protocols like SRTP, Modbus TCP/IP, OPC UA, PROFINET, and Modbus RTU. It works on RX3i Universal Backplanes, supports up to 512 program blocks, and is compatible with Series 90-30 I/O for seamless migration. Programming is done via Proficy Machine Edition using Ladder Diagram, Structured Text, Function Block Diagram, and C, providing robust processing, secure communication, and flexible scalability for industrial applications requiring high I/O capacity and reliable connectivity.
GE IC695CPE310-ABAD
Product Introduction
The IC695CPE310-ABAD is a high-performance multicore CPU module within the PACSystems RX3i family, engineered for real-time control of complex machines, industrial processes, and distributed automation systems in harsh and hazardous environments. It incorporates a 1.1 GHz dual-core Intel Atom processor, 10 MB RAM, and 10 MB non-volatile flash user memory, with battery-less data retention via the IC695ACC400 Energy Pack. It is outfitted with 2 switched gigabit Ethernet ports, 1 isolated RS-232/485 serial port, and 1 USB 2.0 Type-A port, supporting protocols including SRTP, Modbus TCP/IP, OPC UA, PROFINET, and Modbus RTU. The module operates on RX3i Universal Backplanes, supports up to 512 program blocks, and maintains compatibility with Series 90-30 I/O for seamless migration. Programming is done via Proficy Machine Edition using Ladder Diagram, Structured Text, Function Block Diagram, and C, delivering robust processing, secure communication, and flexible scalability for mission-critical industrial applications in extreme settings.
GE IC695CPE305LT-ABAD
Product Introduction
The IC695CPE305LT-ABAD is a rugged, high-performance multicore CPU module in the PACSystems RX3i lineup, built for real-time control of machines, processes, and distributed automation systems in extreme industrial environments. It features a 1.1 GHz dual-core processor, 5 MB RAM, and 5 MB non-volatile flash user memory, with battery-less data retention via the IC695ACC400 Energy Pack. It is equipped with 2 switched gigabit Ethernet ports, 1 isolated RS-232/485 serial port, and 1 USB 2.0 port, supporting protocols such as SRTP, Modbus TCP/IP, OPC UA, PROFINET, and Modbus RTU. The module operates on RX3i Universal Backplanes, supports up to 512 program blocks, and is compatible with Series 90-30 I/O for seamless migration. It uses Proficy Machine Edition for programming in Ladder Diagram, Structured Text, Function Block Diagram, and C, delivering powerful processing, secure communication, and flexible scalability for mission-critical industrial applications in harsh conditions.
GE IC695CPE302
Product Introduction
The IC695CPE302 is a high - performance multicore CPU module for PACSystems RX3i, engineered for real - time control of machines, processes, and distributed automation systems. It integrates 2 MB RAM and 2 MB non - volatile flash user memory, with battery - less data retention via the included IC695ACC400 Energy Pack, which writes user memory to non - volatile storage during power loss. It features 2 switched gigabit Ethernet ports, an isolated RS - 232 serial port, and a USB 2.0 port, supporting diverse industrial protocols like SRTP, Modbus TCP/IP, OPC UA, PROFINET, and Modbus RTU. The module operates on RX3i Universal Backplanes, supports up to 512 program blocks, and is compatible with Series 90 - 30 I/O for seamless migration. It uses Proficy Machine Edition for programming in Ladder Diagram, Structured Text, Function Block Diagram, and C, delivering powerful processing, secure communication, and flexible scalability for mission - critical industrial applications.
GE IC695ALG708
Product Introduction
The IC695ALG708 is an 8-channel non-isolated analog output module for PACSystems RX3i, designed to deliver precise voltage and current signals for industrial control applications. It is fully software-configurable via Proficy Machine Edition (no jumpers), with each channel independently settable to voltage (±10 V, 0–10 V) or current (0–20 mA, 4–20 mA) outputs. It offers 15.6–15.9 bits resolution (per range), 8 ms full-channel update rate, full autocalibration, and on-board diagnostics including high/low/high-high/low-low alarms, clamping, and over/underrange detection. The module uses detachable terminal boards (IC694TBB032/TBS032 or extended versions), supports hot-swap, and operates with RX3i CPUs (firmware 3.00+), providing flexible, high-precision control for actuators, valves, drives, and other field devices.
GE IC695ALG600
Product Introduction
The IC695ALG600 is an 8-channel universal analog input module for PACSystems RX3i, split into 2 isolated groups of 4 channels, plus 2 dedicated Cold Junction Compensation (CJC) channels for thermocouple accuracy. It is fully software-configurable via Proficy Machine Edition (no jumpers), supporting individual channel setup for voltage, current, thermocouple, RTD, and resistance inputs. It offers 6 selectable hardware filter frequencies (8–1000 Hz), 11–16 - bit resolution (per configuration), and full autocalibration. The module provides 250 VAC continuous optical isolation (field to backplane) and group - to - group isolation, with on - board diagnostics including open - circuit (most types) and RTD short - circuit detection. It uses a detachable terminal board (IC695TBB016/IC695TBS016), supports hot - swap, and operates with RX3i CPUs (release 9.00+), delivering flexible, high - precision analog signal acquisition for industrial automation.
GE IC694PWR330
Product Introduction
The IC694PWR330 is a 30-Watt high-capacity serial expansion power supply module tailored for GE PACSystems RX3i, dedicated to supplying regulated power to serial expansion backplanes. It accepts a wide input range of 85–264 VAC or 100–300 VDC, and delivers three outputs: 5 VDC (30W max) for backplane logic, 24 VDC Relay (15W max) for output relay modules, and 24 VDC Isolated (20W max) for 24 VDC input modules and external devices. It integrates 1500 VAC input-to-backplane isolation, comprehensive protection (overvoltage, undervoltage, overcurrent, short - circuit), and LED indicators for power, output status, and faults. It is a non - hot - swappable module, exclusively for serial expansion backplanes, offering stable supplementary power for distributed RX3i systems in industrial automation applications.
GE IC694MDL660CA-BC
Product Introduction
The IC694MDL660CA-BC is a 32-channel discrete input module for PACSystems RX3i, featuring 4 isolated groups of 8 channels, positive/negative logic per group, and 7 selectable input filter times (0.5–100 ms). It converts 24 VDC field signals (0–30 VDC range) to digital data, with 250 VAC continuous optical isolation (field to backplane) and 250 VAC group-to-group isolation. Each channel has a green LED for ON/OFF status, and the module uses a detachable terminal board (IC694TBB032/IC694TBS032). It supports hot-swap, integrates advanced diagnostics, and operates with RX3i CPUs (release 2.90+), delivering high-density, flexible input acquisition for industrial automation. The CA-BC variant denotes specific manufacturing and compliance standards, ensuring consistency with global industrial certifications.
GE IC694MDL655
Product Introduction
The IC694MDL655 is a 32-channel discrete input module for PACSystems RX3i, designed to monitor 24 VDC field devices with positive/negative logic compatibility and 4 isolated groups of 8 inputs. It converts dry contact, proximity switch, and sensor signals to digital data for PLC processing, integrating 250 VAC optical isolation, 2 ms response time, and individual channel LEDs for status monitoring. Each group has a dedicated common for flexible wiring, and it supports hot-swap for minimal downtime. It delivers high-density, reliable input acquisition for industrial automation, suitable for high-channel-count monitoring in manufacturing, energy, and infrastructure applications.
