GE IC687RCM711 Redundant Communication Module
Technical Specifications
- Communication Protocol: Supports Ethernet/IP (compliant with ODVA standards), including Class 1 (real-time control) and Class 3 (non-real-time data) modes.
- Network Interface: Two RJ45 Ethernet ports, supporting 10/100 Mbit/s adaptive speed with Auto-MDIX auto-crossover functionality.
- Processor: 32-bit microprocessor with a main frequency of 200 MHz.
- Memory: 128 MB RAM for data caching and 64 MB Flash for configuration storage.
- Power Supply: Draws power from the internal 5V DC bus of GE RX3i PLC, with a maximum power consumption current of ≤300 mA.
GE IC670MDL740K Digital Output Module
Technical Specifications
- Number of Output Channels: 16 digital output channels
- Output Signal Types: Supports 24 VDC output signals
- Output Current: 0.5 A per channel
- Maximum Total Output Current: 8 A (for all channels combined)
- Output Voltage Range: 10 VDC to 30 VDC
- Power Consumption: 111 mA from the Bus Interface Unit (BIU) power supply
GE IC670MDL640 Digital Input Module
Technical Specifications
- Number of Input Channels: 16 digital input channels
- Input Signal Types: Accepts 24 VDC input signals
- Input Voltage Range: 0 to 30 VDC, with a nominal voltage of 24 VDC
- User Input Current: 7.5 mA per point
- Current Consumption: 75 mA from the Bus Interface Unit (BIU) power supply with all inputs active; maximum current consumption of 83 mA
- On-State Voltage Rating: +15 VDC to +30 VDC for positive logic; -15 VDC to -30 VDC for negative logic
GE IC670CHS002 I/O Terminal Module
Technical Specifications
- Terminal Count: 37 terminals
- Supported Modules: Can accommodate two field control modules
- Installation Method: Supports DIN rail or panel mounting, designed for horizontal installation
- Wire Specifications: Each terminal can accommodate two solid or stranded copper wires ranging from AWG #14 (2.1 mm²) to AWG #22 (0.35 mm²)
- Operating Temperature: 0°C to 60°C
- Storage Temperature: -40°C to 85°C
GE IC670ALG310-JA Analog Input Module
Technical Specifications
- Input Channels: 8 single-ended analog input channels
- Input Signal Types: Supports 0-20 mA, 4-20 mA, 0-5 VDC, 1-5 VDC, and ±10 VDC signals
- Resolution: 12-bit analog-to-digital conversion for precise signal representation
- Conversion Time: 100 microseconds per channel (typical)
- Input Impedance:
- Current inputs: 250 ohms
- Voltage inputs: 10 megohms
GE IC670ALG230K Analog Input Module
Technical Specifications
- Number of Channels: 8 single-ended analog input channels
- Input Signal Types: Accepts 0-20 mA and 4-20 mA current signals
- Resolution: 12-bit digital resolution for accurate signal representation
- Conversion Time: 1 microsecond per channel at a 60 MHz module clock frequency
- Input Impedance: 2.87 kilohms
- Isolation: Each channel has ground and logic isolation rated at 1500 VAC for one minute and 250 VAC continuously
GE Fanuc IC610MDL179 Digital Output Module
GE IC200UEX626 PLC Module
Technical Specifications
- Brand: GE (General Electric)
- Series: VersaMax
- Model: IC200UEX626
- Type: Digital Input/Output Module
- Input/Output Configuration:
- Digital Inputs: Supports multiple digital input channels for connecting sensors and switches.
- Digital Outputs: Provides multiple digital output channels for controlling actuators and other devices.
GE IC200UDR005 VersaMax Micro PLC Module
GE IC200PWR102 Power Supply Module
Technical Specifications
- Brand: GE Digital (formerly GE Fanuc)
- Series: VersaMax
- Model: IC200PWR102
- Input Voltage: 120/230 V AC (auto-switching)
- Input Voltage Range: 90–264 V AC, 47–63 Hz
- Output Voltages:
- +5 V DC: Up to 2.0 A (for CPU and I/O modules via backplane)
- +24 V DC: Up to 0.8 A (for field sensors and actuators)
GE IC200PWR002 Power Supply Module
Technical Specifications
- Input Voltage Range: 85-264V AC (47-63Hz) or 100-375V DC
- Output Voltage: 24V DC (±1%)
- Output Current: 2.0A (continuous)
- Power Capacity: 48W
- Efficiency: Up to 90% at full load
- Isolation Voltage: 3000V AC between input and output
- Operating Temperature: -20°C to +70°C (-4°F to +158°F)
