Honeywell TC-PRR021 Redundancy Module
Technical Specifications
- Brand: Honeywell
- Model: TC-PRR021
- Type: Redundancy Module for DCS
- Voltage Rating: Supports a wide range of DC input voltages, typically from 18V to 32V DC, ensuring compatibility with various power supplies.
- Power Consumption: Low power consumption, with typical values around 3.25W for 4-20mA signals and 3.75W for catalytic sensors, contributing to energy efficiency.
- Environmental Resistance: Designed to operate in harsh industrial environments, with resistance to dust, moisture, and electrical noise.
- Physical Dimensions: Compact and rugged design, suitable for mounting in standard industrial enclosures or control panels.
- Weight: Lightweight, facilitating easy installation and handling.
Honeywell TC-PPD011 Analog Input Module
Technical Specifications
- Brand: Honeywell
- Model: TC-PPD011
- Type: Analog Input Module
- Signal Processing Capability:
- Supports 4-20mA and 0-5V analog signals.
- Capable of processing multiple types of analog inputs, converting them into digital signals for control systems.
- Communication Protocols:
- Supports UDP, TCP, and other communication protocols for multi-center data transmission.
- Ensures timely and accurate data transfer between the module and control systems.
Honeywell TC-PCIC01K Digital Input/Output Module
Technical Specifications
- Brand: Honeywell
- Model: TC-PCIC01K
- Type: Digital Input/Output Module
- Input/Output Configuration: The module supports multiple digital input and output channels, allowing for flexible configuration based on specific application requirements.
- Voltage Rating: Designed to operate within a standard industrial voltage range, ensuring compatibility with common power supplies.
- Communication Protocol: Supports standard industrial communication protocols, facilitating integration with Honeywell's Experion PKS and other control systems.
- Environmental Resistance: Built to withstand harsh industrial environments, featuring resistance to dust, moisture, and electrical noise.
- Physical Dimensions: Compact design for easy installation in standard industrial enclosures or control panels.
Honeywell TC-IXR061 FC-TPSU-2430
Technical Specifications (TC-IXR061)
- Brand: Honeywell
- Model: TC-IXR061
- Type: Input Module (specifically, an RTD input module for temperature measurement)
- Input Signal Support:
- Supports 3-wire or 4-wire RTD sensors.
- Compatible with standard platinum resistance sensors such as PT100 and PT1000.
- Measurement range covers -200°C to +850°C.
- Measurement Accuracy:
- Resolution of 0.05°C.
- Accuracy of ±0.1°C, ensuring high-precision temperature monitoring.
- Environmental Resistance:
- Designed to operate in harsh industrial environments.
- IP65 protection rating, resistant to dust and water ingress.
- Wide operating temperature range of -40°C to +70°C.
Honeywell TC-IXL061 Thermocouple Input Module
Honeywell TC-IDD321 Digital Input/Output Module
Technical Specifications
- Brand: Honeywell
- Model: TC-IDD321
- Type: Digital Input/Output Module
- Input/Output Configuration: The module supports a specific number of digital input and output channels, though the exact configuration may vary based on the specific variant or system requirements. Typically, such modules are designed to handle multiple channels to accommodate various industrial applications.
- Voltage Rating: The module is designed to operate within a specified voltage range, ensuring compatibility with standard industrial power supplies. For instance, some variants may support a 24V DC power supply.
- Communication Protocol: It supports standard industrial communication protocols, facilitating seamless integration with Honeywell's Experion PKS and other control systems. This ensures efficient data exchange and system interoperability.
Honeywell TARS-B Inertial Measurement Unit (IMU)
Technical Specifications
- Degrees of Freedom: Six (6DoF), providing motion sensing along three perpendicular axes for translational motion (surge, sway, heave) and rotational motion (roll, pitch, yaw).
- Gyroscope Performance:
- Range: ±500 deg/s
- Resolution: 7.81 mdps (milli-degrees per second)
- In-run bias stability: 3.8 deg/hr
- Noise density: 14 mdps/√Hz
- Offset (0°C to 50°C): ±0.5 deg/s
- Offset (-40°C to 85°C): ±1.1 deg/s
Honeywell T2798I-1000 High-Precision Inductive Proximity Sensor
Technical Specifications
- Brand: Honeywell
- Model: T2798I-1000
- Type: Inductive Proximity Sensor
- Detection Range: Varies based on the target material and size, but typically offers a short to medium detection range suitable for industrial applications.
- Output: Typically provides a digital output signal (e.g., NPN or PNP) for easy integration with PLCs and other control systems.
- Power Supply: Compatible with standard industrial power supplies, often operating at 24V DC.
- Environmental Resistance: Designed to withstand harsh industrial conditions, including resistance to dust, moisture, and electrical noise.
- Housing Material: Durable materials suitable for industrial use, ensuring long-term reliability.
- Connection Type: Typically features a quick-disconnect or cable connection for easy installation and maintenance.
Honeywell S8610M3009 Ignition Controller Module
Technical Specifications
- Input Voltage: 220/240V (-15% to +10%), 50Hz (40-60Hz)
- Main Current: 0.2A
- Ignition Time: Continuous ignition for no more than 1 minute
- Interference Level: Ignition voltage of 2x7Kv, secondary current of 40mA rms, secondary frequency of 20kHz
- Ignition Gap: 3-5mm
- Ignition Cable: Plug-in type
- Insulation Rating: IP40
- Ambient Temperature Range: -10°C to 60°C
- Installation Angle: Any angle
- Weight: 280 grams
- Output: 14KV
- Input: 230VAC
Honeywell S8600M3001 Gas Boiler Ignition Controller
Technical Specifications
- Brand: Honeywell
- Model: S8600M3001
- Ignition Type: Electronic ignition
- Power Supply: Typically operates on 120V AC or other suitable voltages
- Control Method: Automatic control, with the ability to respond to ignition signals to initiate gas ignition
- Ignition Output: Produces high-voltage sparks or ignition pulses for reliable ignition
- Working Temperature Range: Typically from -40°C to +85°C or higher, depending on the specific model
- Safety Features: Incorporates anti-backfire functionality to ensure safe ignition processes
- Dimensions: Vary based on the specific model, but designed to fit standard industrial enclosures
- Weight: Lightweight for easy installation and integration
Honeywell MU-TDOA13 51304648-100 PLC Module
Technical Specifications
- Brand: Honeywell
- Model Number: MU-TDOA13 51304648-100
- Place of Origin: United States
- Type: PLC Module
- Input/Output Configuration: Specific I/O configuration tailored for industrial control applications
- Power Supply: Compatible with standard industrial power supplies, typically 24V DC
- Environmental Resistance: Designed to withstand harsh industrial conditions, including resistance to dust, moisture, and electrical noise
Honeywell MS8120A1205 Spring Return Damper Actuator
Technical Specifications
- Actuator Type: Damper, Valve
- Control Signal: SPST (Single Pole, Single Throw), 2-position
- Supply Voltage: 24 Vac ±20%
- Frequency: 50 Hz / 60 Hz
- Torque: 175 lb-in (20 Nm)
- Rotational Stroke: 95° ±3°
- Spring Return Time: 20 seconds (maximum)
- Nominal Driving Time at 60 Hz: 45 seconds
- Internal Auxiliary Switches: 2
- Switch Ratings: 250 Vac, 5 A res (3 A ind)
- Shaft Adapter Type: Self-centering clamping
