GE IC9445-B200AB
- Product Overview: Heavy-duty watertight limit switch from GE’s industrial safety control portfolio, designed for position detection and safety interlocking in harsh industrial environments. Features a lever actuator, two independent non-overlapping circuits, and a robust watertight enclosure. Rated for 600VAC/15A to handle high-power industrial loads, it integrates seamlessly with PLCs, safety relays, and motor control centers to enforce machine travel limits and emergency stops.
- Technical Specifications - Electrical Ratings: 600VAC maximum voltage; 15A continuous current per circuit; 2 independent non-overlapping circuits; 2-pole (2P) contact configuration
GE IC800SSI228RD2
- Product Overview: Single-axis servo drive/controller in GE’s IC800 VersaMotion series, delivering 28A continuous output at 230VAC for precise motion control of servo motors. Integrates position, speed, and torque control modes with DeviceNet communication, supports SSI absolute encoder feedback, and includes comprehensive protection functions. Modular design enables seamless integration into PLC/DCS systems, ideal for industrial automation requiring high-precision motion control.
- Technical Specifications - Electrical Ratings: 230VAC 3-phase input; 28A continuous output current; 56A peak output current; 0–600 Hz output frequency range
GE IC754VSI12CTD
- Product Overview: 12.1-inch color TFT touchscreen HMI terminal from GE Fanuc QuickPanel View series, running Windows CE.NET with preloaded Proficy View-Machine Edition for HMI development and runtime. Features 800×600 resolution, 320 MHz Intel XScale PXA255 processor, 32 MB flash, 32 MB DRAM, 512 KB battery-backed SRAM, 1×10/100 Ethernet, 1×RS-232/RS-485 serial, and Type II PCMCIA slot. Powers from 12–30 VDC, has NEMA 4/12/4x (IP65 front) sealing, and operates in -20°C–60°C. Serves as a high-visibility HMI for large-panel industrial control rooms and standalone machine monitoring.
- Technical Specifications - Display: 12.1-inch color TFT; 800×600 pixels; 65,536 colors; resistive touchscreen; LED backlight (50,000-hour MTBF)
GE IC754VSI06STD-LH
- Product Overview: 6-inch color STN touchscreen HMI terminal in GE Fanuc QuickPanel View series, LH configuration, with 320×240 resolution, resistive touch, and Windows CE OS preloaded with Proficy View-Machine Edition. Equipped with 32 MB flash, 32 MB DRAM, 512 KB battery-backed SRAM, 512 KB boot ROM, 1×10/100 Ethernet, and 1×RS-232/RS-485 serial port. Powers from 12–30 VDC, consumes 24 W max, and has IP65 front-panel sealing. Serves as a compact HMI for industrial automation, linking operators to PLCs/controllers for monitoring, control, and data entry.
- Technical Specifications - Display: 6-inch color STN; 320×240 pixels; 256 colors; resistive touchscreen; LED backlight (50,000-hour MTBF)
GE IC754VGL06CTD ES0622
- Product Overview: 6-inch color TFT touchscreen HMI terminal in GE Fanuc QuickPanel View series, part of the ES0622 configuration lineup. Runs Windows CE.NET (Windows Compact Embedded) with Proficy View-Machine Edition preloaded for HMI application development and runtime operation. Features resistive touch input, 32 MB flash, 32 MB DRAM, RS-232/RS-485 serial, and 10/100 Ethernet connectivity. Powers from 12–30 VDC, operates in -20°C–60°C environments, and has an IP65 front panel for industrial use. Serves as a compact, networked HMI for machine and process control, supporting standalone or integrated plant-wide systems.
- Technical Specifications - Display: 6-inch color TFT; 320×240 pixels; 65,536 colors; resistive touchscreen; LED backlight (50,000-hour MTBF)
GE IC754VGI06MTD
- Product Overview: 5.75-inch color TFT HMI terminal in GE Fanuc QuickPanel View series, with 320×240 resolution, 65,536 colors, and resistive touchscreen. Runs Windows CE.NET 3.0 on 300 MHz Intel XScale PXA255 CPU; equipped with 32 MB flash, 32 MB DRAM, 512 KB SRAM, 512 KB boot ROM. Connects via 10/100 Ethernet, RS-232/RS-485 serial ports, Type II PCMCIA slot, and 100-pin DIMM expansion bus. Powers from 10.8–30 VDC, operates at -20°C–60°C, and features IP65 front-panel sealing. Supports Proficy View-Machine Edition for application development and runtime data visualization.
- Technical Specifications - Display: 5.75-inch color TFT; 320×240 pixels; 65,536 colors; resistive touch; LED backlight (50,000-hour MTBF)
GE IC752SPL013-BA
- Product Overview: Dedicated operator interface keypad for GE EX2100 excitation control systems, enabling direct command input, parameter adjustment, and real-time status monitoring. Features a 12-button keypad with 16-character alphanumeric display, function keys for excitation-specific tasks, and field-replaceable hot-swap capability. Installs as a front-panel HMI in EX2100 cabinets; communicates via system backplane to exchange data with the excitation controller. Powers from 24 VDC system bus, operates in -40°C–70°C environments, and supports hot-swap without system shutdown.
- Technical Specifications - Input Power: 24 VDC (nominal), 21.6–26.4 VDC range; 0.5A maximum current draw
GE IC698PSA350D
- Product Overview: High-power primary power supply for GE PACSystems RX7i main racks, installed in slot 0 of the VME64 backplane. It converts 85–264 VAC (47–63 Hz) or 100–150 VDC input to +5 VDC (60A), +12 VDC (12A), -12 VDC (4A) outputs with 350W total power. The module sends logic-level sequencing signals to backplane modules, maintains output during 1 AC line cycle interruption, and includes overcurrent/overvoltage/short-circuit protection with front-panel LED indicators. Active power factor correction (PFC) improves efficiency and reduces harmonic distortion.
- Technical Specifications - Input Voltage: 85–264 VAC (47–63 Hz) or 100–150 VDC; nominal 120/240 VAC or 125 VDC
GE IC698PSA100
- Product Overview: Dedicated primary power supply module for GE PACSystems RX7i PLC main racks, installed in slot 0 (leftmost) of the VME64 backplane. It converts 85–264 VAC or 100–150 VDC input to +5 VDC (20A), +12 VDC (2A), -12 VDC (1A) outputs, delivering 100W total power at 0°C–60°C without forced cooling. The module provides logic-level sequencing signals to backplane modules, maintains output during 1 AC line cycle interruption, and includes overcurrent/overtemperature/overvoltage protection with front-panel LED status indicators.
- Technical Specifications - Input Voltage: 85–264 VAC (47–63 Hz) or 100–150 VDC; nominal 120/240 VAC or 125 VDC
GE IC698CRE040-HN
- Product Overview: High-performance redundant control processor module for GE PACSystems RX7i PLCs, featuring a 1.8 GHz processor, 64 MB RAM, 64 MB non-volatile flash, dual 10/100 Mbps Ethernet ports, RS-232/RS-485 serial ports, and VME64 backplane compatibility. The HN firmware optimizes stability at high loads and 40°C–60°C, preventing false alarms and data corruption. It enables seamless main-standby switchover (<50ms) for uninterrupted control in critical systems, with battery-backed RAM and self-diagnostics for system integrity.
GE IC698CPE030-HN
- Product Overview: Core CPU module for GE PACSystems RX7i programmable automation controllers, powered by a 600 MHz Pentium-M processor with 64 MB user RAM and 64 MB non-volatile user flash, dual 10/100 Mbps Ethernet ports, RS-232/RS-485 serial ports, and VME64 backplane compatibility. The HN firmware version delivers enhanced stability for high-data-load and extended-temperature operations, supporting Series 90-70 I/O and VME64 modules. It performs real-time control, data processing, and communication, with battery-backed memory for data retention and self-diagnostics for system integrity.
- Technical Specifications - Processor: 600 MHz Pentium-M microprocessor with floating-point unit
GE IC698CMX016-ED
- Product Overview: Single-slot reflective memory communication module for GE PACSystems RX7i PLCs, using reflective memory technology to enable deterministic real-time data sharing across fiber optic networks. It has 16MB SDRAM with parity, LC fiber optic ports, 2.12 Gbaud transfer rate, supports up to 256 nodes per network, and redundant transfer mode. The ED firmware fixes false alarms in high-temperature/high-data-load conditions, ensuring stable operation in industrial environments. It is CPU-independent, requires +5VDC/1.8A, and mounts in RX7i main rack slots 3 or 4.
- Technical Specifications - Memory: 16MB SDRAM with parity checking, 400ns typical access time
