HIMA F6217 984621702 Programmable Logic Controller (PLC)
Technical Specifications
- Processor: Dual-core 1 GHz ARM Cortex A9 processor for high-speed processing.
- Memory: 4 GB flash memory for program storage and 512 MB RAM for real-time data handling.
- Input/Output:
- Analog Input: Supports 8 analog inputs with 12-bit resolution for current (0/4–20 mA) and voltage (0–5/10 V) signals.
- Digital Input/Output: Configurable digital channels for connecting sensors and actuators.
- Communication Interfaces:
- Ethernet, RS232/485, CAN, PROFIBUS, PROFINET, Modbus, OPC UA for seamless integration with other devices.
- Dual RS485 ports (isolated, up to 57.6 kbps) for robust communication.
HIMA F7553 984755302 Programmable Bus Coupling Module
Technical Specifications
- Compatibility: Designed for HIMA HIMatrix and PES H51q systems.
- Safety Integrity Level (SIL): Typically supports SIL 3 systems (module self-diagnostics).
- Power Supply: 5 VDC or 24 VDC.
- Power Consumption: 600 mA (typical at 5 VDC); 750 mA (typical at 24 VDC).
- Self-Diagnostic Functions: Automatic testing and safety-related watchdog signal monitoring.
- Indicators: LED indicators for watchdog signal (WD) and I/O module access (SEL).
- Physical Dimensions: 4 TE width (approximately 85 mm wide x 35 mm high x 125 mm deep).
- Weight: Approximately 0.14 kg to 0.2 kg.
- Operating Temperature Range: 0°C to +55°C.
- Storage Temperature Range: -40°C to +70°C.
- Humidity: 5% to 95% (non-condensing).
- Installation Method: Inserted into HIMA rack slots.
HIMA F8627X Industrial Safety Communication Module
Procurement Guidance
- For safety systems: Verify model suffix 984862765 (SIL 3 certified) .
- For communication roles: Confirm EtherNet/IP or Profinet support via suffix (e.g., 3BSE006503R1) .
- Avoid misuse: Industrial automation applications require -40°C rating; commercial variants (0°C to +40°C) lack SIL 3 .
HIMA F8628X 984862865 Communication Module
Technical Specifications
- Communication Interfaces:
- Ethernet (10/100 Mbps) with RJ-45 connector for high-speed data transfer.
- PROFIBUS DP slave interface via a 9-pole SUB-D plug for integration with PROFIBUS networks.
- High-Speed Serial Redundancy (HSR) interface via RJ-12 plug for redundant communication.
- Processor: 32-bit Motorola CPU MPC860T with integrated RISC communication controller.
- Power Supply: 24 VDC (5 VDC/1 A operating voltage).
- Physical Dimensions: 3 HU (height units) x 4 SU (width units), compact design for easy installation.
- Diagnostic Display: 6 LEDs for real-time status monitoring and diagnostics.
- DIP Switches: 2 DIP switches for configuring module functions.
- Warranty: 1-year warranty with global shipping availability.
HIMA F8650X 984865065 Safety System Central Module
Technical Specifications
- Processor: High-performance processor (specific model may vary, e.g., ARM Cortex-A9 or similar, depending on configuration).
- Memory: Large-capacity memory, including DDR3 RAM (e.g., 512 MB) and NAND flash storage (e.g., 128 MB), for storing and processing extensive data.
- Communication Interfaces: Equipped with multiple communication ports, such as Ethernet, fieldbus, RS-232, and USB, facilitating seamless connectivity with other devices and systems.
- Power Supply: Operates on 24V DC power supply.
- Operating Temperature: Ranges from 0°C to +60°C.
- Storage Temperature: From -40°C to +85°C.
- Certifications: Meets stringent safety standards, including IEC 61508 and DIN 19250, with certifications such as TÜV AK7/SIL4.
HIMA F8652X 984865265 Central Control Module
Technical Specifications
- Processor: Based on Arm Cortex industrial-grade TDA4VM processor, ensuring high-speed processing for complex control tasks.
- Power Supply: 24V DC input with 0-10V DC output, providing a maximum current of 500mA.
- Physical Dimensions: 120mm x 80mm x 40mm, compact design for easy installation.
- Operating Temperature Range: -20°C to 60°C, suitable for harsh industrial environments.
- Communication Interfaces: Supports multiple protocols including Ethernet, serial port, Profibus, and CAN, enabling seamless data exchange with other devices.
- Safety Features: Equipped with overcurrent, overvoltage, and short-circuit protection functions to enhance system reliability.
- Programming Flexibility: Supports IEC 61131-3 standard PLC programming languages, allowing customization of safety logic.
HIMA X-DO1201 985210204 Digital Output Module
Technical Specifications
- Input/Output Configuration:
- 1 analog input for motor speed control signals.
- Multiple digital inputs for additional control signals.
- 12 digital output channels for controlling external devices.
- Output Specifications:
- Output voltage range: 0-230 VDC or 0-125 VDC.
- Maximum output current per channel: 2 A.
- Power Supply:
- Operating voltage: 24 VDC.
HIMA X-FAN1003 993201013 Discrete I/O Controller
Technical Specifications
- Input/Output Configuration:
- Built-in discrete I/O points for handling digital signals (single-bit or discrete states).
- Supports multiple discrete input/output channels for flexible signal management.
- Power Supply:
- Operating voltage: 24 VDC / 120 VAC, accommodating diverse power requirements.
- Physical Dimensions:
- Compact design with dimensions of approximately 50 mm x 35 mm x 15 mm, facilitating easy installation in space-constrained environments.
- Environmental Resistance:
- Operates reliably in harsh conditions, including extreme temperatures and humidity levels.
HIMA X-SB01 985210207 System Bus Module
Technical Specifications
- Supported Bus Protocols: Profinet, EtherNet/IP, and other industrial Ethernet protocols.
- Operating Voltage: Typically 24 VDC or 220 V (specific voltage may vary based on configuration or customer requirements).
- Input/Output Configuration:
- Input Channels: 16 or 32 (configurable).
- Input Voltage Range: 0 to 125 VDC.
- Input Current Range: 4-20 mA.
- Environmental Conditions:
- Operating Temperature Range: -40°C to 70°C.
- Suitable for harsh industrial environments with robust design.
- Physical Dimensions: Compact form factor for easy installation in space-constrained environments.
- Weight: Approximately 1.6 kg (may vary slightly based on configuration).
- Warranty: One-year standard warranty, indicating supplier confidence in product quality.
HONEYWELL 05701-A-0351 Control Card
Honeywell 32300323-002C Pressure Transmitter
Technical Specifications
- Model: 32300323-002C
- Type: Pressure Transmitter
- Pressure Range: Customizable based on application requirements (specific range not publicly listed for this model).
- Output Signal: Standard industrial communication protocols (e.g., 4-20 mA, HART, or others depending on configuration).
- Accuracy: High-precision measurement with minimal error margins (exact value depends on calibration).
- Operating Temperature: -40°C to 85°C (standard industrial range; may vary with configuration).
- Environmental Rating: IP67 or higher for dust and water resistance (typical for industrial transmitters).
- Power Supply: 24 VDC (common for industrial automation systems).
- Material: Stainless steel or other durable materials for housing and wetted parts.
Honeywell 51195153-902 Pressure Sensor Module
Technical Specifications
- Model: 51195153-902
- Brand: Honeywell
- Origin: United States
- Pressure Range: ±5 PSI to ±200 PSI (customizable for specific needs)
- Output Signal: 0-5 V analog voltage or 4-20 mA current loop (configurable)
- Operating Temperature: -40°C to +125°C
- Protection Rating: IP67 (dustproof and waterproof)
- Communication Interface: Supports Modbus RTU and Profinet (industrial Ethernet protocols)
- Material: Stainless steel 316L housing for compatibility with corrosive media
- Response Time: 1 ms (typical for dynamic pressure scenarios)
- Accuracy: ±0.1% FS (full-scale) over the specified range
- Long-Term Stability: Zero drift ≤0.02% FS/year; span drift ≤0.05% FS/year
