MOTOROLA MVME-5100 VMEbus Single Board Computer
Technical Specifications
- Processor: Supports multiple processor options, including MPC7410, MPC750, or MPC755-grade microprocessors from Motorola or Freescale, featuring high performance and low power consumption.
- Memory:
- Standard configuration includes 128 MB SDRAM, expandable up to 1 GB via memory mezzanine cards.
- Typically equipped with a 2 GB IDE hard disk or solid-state drive (SSD).
- I/O Interfaces:
- 2 x RS-232C serial ports.
- 1 x 10/100BaseTX Ethernet interface (some models offer dual Gigabit Ethernet ports).
- 1 x PCI slot and 1 x CompactFlash slot for extensive peripheral expansion.
MOTOROLA MVME-761-001 VMEbus Single Board Computer
Technical Specifications
- Processor: The MVME-761-001 is equipped with a high-performance processor (specific model may vary based on version) to ensure fast and efficient computation.
- Memory: It supports multiple memory configurations, including RAM and Flash/ROM, to meet different application requirements.
- VMEbus Interface: Features an A32/D32 VMEbus master/slave interface with system controller functionality, ensuring high-speed data transfer and reliable operation.
- I/O Interfaces:
- Serial Ports: Two EIA-574 asynchronous serial ports (DTE) and two asynchronous/synchronous serial ports configurable for EIA-232-D, EIA-530, V.35, or X.21 interfaces (DCE or DTE).
- Parallel Port: One parallel port compliant with IEEE standard 1284-1.
- Ethernet: One 10Base-T/100Base-TX Ethernet port for network connectivity.
- SIM Connectors: Two 60-pin SIM (Serial Interface Module) connectors for configuring asynchronous/synchronous serial ports.
MOTOROLA MVME-2434 VMEbus Processor Module
Technical Specifications
- Processor:
- Motorola 68020 (some versions may feature different processors, such as the PowerPC e500 in advanced models).
- Advanced models may include the Freescale MPC8540 system-on-chip with a PowerPC e500 core, running at speeds up to 833 MHz.
- Memory:
- 2MB RAM (expandable in some models).
- 1MB Flash memory for firmware storage.
- Advanced models support up to 512MB DDR333 ECC memory for enhanced data processing accuracy.
MOTOROLA MVME-717 VMEbus-Based Controller Module
Technical Specifications
- Processor: Features a high-performance processor (specific model may vary based on version) for fast and efficient computation.
- Memory: Supports multiple memory configurations, including RAM and Flash/ROM, to meet different application requirements.
- VMEbus Interface: A32/D32 VMEbus master/slave interface with system controller functionality, ensuring high-speed data transfer and reliable operation.
- I/O Interfaces: Includes multiple serial communication ports, parallel interfaces, and optional additional interfaces such as SCSI and Ethernet for versatile connectivity.
- Timers and Watchdog: Equipped with timers and a watchdog mechanism to ensure system stability and reliable operation.
MOTOROLA MVME-376 VME High-Performance Ethernet Controller
Technical Specifications
- Processor: The MVME-376 is equipped with a high-performance processor that delivers fast computational speeds for real-time control tasks. (Specific processor model may vary based on version).
- Memory:
- Supports multiple memory configurations to meet different application requirements.
- Features shared DRAM for efficient data handling.
- Includes SRAM with battery backup for critical data retention.
- VMEbus Interface:
- A32/D32 VMEbus master/slave interface.
- Supports system controller functionality for enhanced system management.
MOTOROLA MVME147S-1 VME Single-Board Computer
Technical Specifications
- Microprocessor:
- 16, 25, or 33.33 MHz MC68030 enhanced 32-bit microprocessor with on-chip cache memory for both instructions and data, increasing processor efficiency by 20% to 40%.
- Optional 16, 25, or 33.33 MHz MC68882 floating-point coprocessor for enhanced numerical computation capabilities.
- Memory:
- 4, 8, 16, or 32MB shared DRAM with programmable parity checking.
- 4K x 8 SRAM with battery backup for real-time clock and data retention.
- Four 28/32-pin sockets for ROM/PROM/EPROM/EEPROM (16-bit wide).
- VMEbus Interface:
- A32/D32 VMEbus master/slave interface with system controller functionality.
- Supports 4-level requester, 7-level interrupter, and 7-level interrupt handler for VMEbus operations.
MOTOROLA MVME162-13 Embedded Controller
Technical Specifications
- Microprocessor Options:
- 32 MHz MC68040 enhanced 32-bit microprocessor with 8KB cache, MMU, and FPU.
- Optional 25 MHz MC68040 32-bit microprocessor with 8KB cache, MMU, and FPU.
- Optional 25 MHz MC68LC040 enhanced 32-bit microprocessor with 8KB cache and MMU.
- Memory:
- 4, 8, or 16MB shared DRAM.
- 512KB SRAM with battery backup.
- 1MB flash memory for onboard monitor/debugger or user-installed firmware.
- 8K x 8 NVRAM with battery-backed clock.
- VMEbus Interface:
- A32/D64 VMEbus master/slave interface with system controller functionality.
- High-performance DMA support for VMEbus D64 and local bus memory burst cycles.
MOTOROLA MVME 147SB-1 VME Single-Board Computer
Technical Specifications
- Microprocessor: MC68030 32-bit enhanced microprocessor with clock speeds of 16, 25, or 33.33 MHz.
- Floating-Point Coprocessor: MC68882 floating-point coprocessor for accelerated numerical computations.
- Memory:
- 4, 8, 16, or 32MB shared DRAM with programmable parity checking.
- 4K x 8 SRAM with battery-backed real-time clock for data retention.
- Storage: Four 28/32-pin sockets for ROM/PROM/EPROM/EEPROM (16-bit wide).
- Bus Interface: A32/D32 VMEbus master/slave interface with system controller functionality.
- Serial Communication: Four EIA-232-D serial ports for connecting peripherals.
- Printer Interface: Centronics-compatible parallel printer port.
- Timers: Two 16-bit timers and a watchdog timer for system monitoring.
- SCSI Interface: DMA-enabled SCSI bus interface for storage devices.
- Ethernet Interface: Ethernet transceiver for network connectivity.
- VMEbus Support: 4-level requester, 7-level interrupter, and 7-level interrupt handler.
- Debugging: Onboard debugger and diagnostic firmware for development and troubleshooting.
MOTOROLA IPMC761-001 High-Performance Multifunction Control Module
Technical Specifications
- Processor: Built-in ARM or Intel architecture processor for embedded computing tasks.
- Memory: 128 KB SRAM for storing program data and temporary results.
- I/O Ports:
- Super-Wide SCSI Interface: High-speed data transfer for storage devices.
- Parallel Port: For connecting legacy peripherals.
- Serial Ports: Two asynchronous and two synchronous/asynchronous serial ports for diverse communication needs.
- Communication Interfaces: Ethernet, USB, and additional serial ports for seamless integration with other devices.
- Power Inputs: Supports multiple voltages including +3.3V, +5V, and ±12V.
- Output Voltages: Provides +12VDC, -12VDC, and +3.3VDC with maximum currents of 40A, 10A, and 3A respectively.
- Dimensions: 40.64 x 195.58 x 390.12 mm (H x W x D), compatible with most ATCA systems.
- Operating Temperature: -40°C to +85°C, suitable for harsh industrial conditions.
- Protection Features: Overvoltage, overcurrent, and thermal protection for enhanced reliability.
MOOG G123-825-001 Buffer Amplifier
Technical Specifications
- Power Supply: 24 VDC (65 mA current draw).
- Input Signal: 4-20 mA (standard PLC analog output).
- Output Signals:
- 4-20 mA (fixed).
- 0-10 V (fixed).
- 0-5 mA to ±100 mA (switch-selectable).
- Filtering: Single-pole active filter to remove input noise, with switch-selectable time constants.
- Mounting: Compact DIN rail enclosure (dimensions: 16 x 25 x 12 mm).
- Weight: 0.16 kg.
- Operating Temperature: 0°C to 85°C.
- Humidity Tolerance: 0-95% non-condensing.
MOOG D136-001-007 High-Performance Motion Controller Module
Technical Specifications
- Control Resolution: High-resolution analog input/output for precise motion control.
- Interface Options: Multiple communication ports, including Ethernet, USB, and serial interfaces, for seamless integration with other devices.
- Power Supply: Single 5V DC power supply (AT or ATX compatible).
- Operating Temperature Range: 0°C to 60°C (32°F to 140°F).
- Environmental Protection: Designed for industrial environments with robust construction to resist dust and vibrations.
- Mounting Options: Compact form factor for DIN rail or panel mounting.
MOOG M128-010-A001B Dual-Port Communication Module
Technical Specifications
- Ports: Dual-port design supporting two independent communication channels.
- Protocols: Compatible with multiple industrial protocols, including Modbus, Profibus, and EtherNet/IP, enabling integration with diverse devices.
- Data Transfer: High-speed data transmission with real-time communication capabilities.
- Environmental Resistance: Robust construction suitable for harsh industrial conditions, with resistance to dust, moisture, and vibrations.
- Power Supply: Integrated power management for stable operation in varied voltage ranges.
- Mounting: Compact form factor for easy installation in control cabinets or DIN rails.
