Honeywell FTA-T-08 Digital Input Module
Technical Specifications:
- Input Channels: 8 digital input channels
- Input Type: Dry contact signals
- Input Voltage: 24 V DC
- Power Supply: 24 V DC
- Power Consumption: Low power design for energy efficiency
- Protection Rating: IP65 (dust and water resistance)
- Dimensions: Compact size for easy installation
- Mounting: DIN rail or panel mounting options
Honeywell FC-TSDO-0824 Digital Discrete Output Module
Technical Specifications
- Output Channels: 8 independent digital output channels
- Voltage Rating: 24 V DC
- Current Output per Channel: Up to 550 mA
- Maximum Load per Channel: 13 W
- Watchdog Timer: Built-in to reset outputs automatically in case of signal loss or system faults
- Compatibility: Works with Honeywell Safety Manager 4000, 5000, and 6000 series, as well as third-party controllers compliant with EN61508 SIL2 or SIL3 standards
- Housing: Robust metal enclosure with NEMA 4X and IP66 ratings for protection against dust and water ingress
- Mounting: Modular design for easy DIN rail or rack installation
- Operating Temperature: -20°C to +70°C (expandable to -40°C to +85°C with optional variants)
Honeywell FC-SAO-0220M Analog Output Module
Technical Specifications
- Output Channels: 2 independent analog output channels
- Signal Type: Supports current (4–20 mA) and voltage (0–10 V DC) outputs
- Accuracy: ±0.1% of full-scale span
- Resolution: 16-bit for high-precision control
- Response Time: ≤10 ms (configurable)
- Isolation: Channel-to-channel isolation to prevent cross-talk
- Power Supply: 24 V DC ±10%
- Operating Temperature: -20°C to +70°C (expandable to -40°C to +85°C with optional variants)
- Protection Rating: IP20 (standard); IP67 with protective cover
- Mounting: DIN rail or rack-mounted
- Communication: Compatible with Honeywell’s proprietary protocols and industrial standards (e.g., Modbus, HART).
Honeywell FC-QPP-0002 Industrial Automation Processor Module
Technical Specifications
- Processor: 1.2 GHz quad-core ARM Cortex-A7 processor
- Memory: 1 GB RAM, 8 GB eMMC storage
- Power Supply: 24 VDC (±20%)
- Operating Temperature: -20°C to +70°C (operational), -40°C to +85°C (storage)
- Dimensions: 110 mm × 110 mm × 40 mm
- Weight: Not specified in available sources
- Communication Interfaces:
- 4-port Ethernet for high-speed data exchange
- RS232, RS485, and USB for legacy device integration
- Support for Modbus, MQTT, and other industrial protocols
- Certifications: CE, UL, and other international safety standards
Honeywell FC1000B1001 Flame Controller Ionization Type
Technical Specifications
- Power Supply: 220V AC ±10%, 50/60Hz
- Power Consumption: 5W
- Operating Temperature Range: 0°C to 60°C
- Humidity Tolerance: Up to 90% non-condensing
- Flame Failure Response Time: <1 second (standard)
- Output Type: Two sets of independent single-pole double-throw (SPDT) relays
- Relay Contact Rating: 2A at 220V AC (resistive load)
- Flame Signal Output: Optional analog output (0-5V DC or 4-20mA)
- Protection Rating: IP40
- Dimensions: Approximately 73mm (H) × 43mm (W) × 58.4mm (D)
- Weight: Not specified in available sources
Honeywell CC-TAIM01 51305959-175 Low-Level Analog Input Multiplexer Module
Technical Specifications
- Brand: Honeywell
- Model: CC-TAIM01
- Part Number: 51305959-175
- Input Channels: 8 channels (expandable via cascading)
- Signal Types: Supports low-level voltage (mV) and current (mA) signals.
- Input Range: ±150mV (typical for thermocouples/RTDs).
- Resolution: 16-bit ADC for high-precision measurements.
- Sampling Rate: Up to 100 samples per second (configurable per channel).
- Accuracy: ±0.1% full-scale error.
- Isolation: Channel-to-channel isolation to prevent cross-talk.
- Communication: Compatible with Honeywell C300 controllers and Experion PKS systems via standard protocols (e.g., Modbus, Ethernet/IP).
- Power Supply: 24V DC ±10%.
Honeywell CC-PWRR01 Redundant Power Supply Module
Technical Specifications
- Brand: Honeywell
- Model: CC-PWRR01
- Order Number: 51199929-100
- Input Voltage: AC 220V (typical industrial power input)
- Output Type: DC 24V (for powering controllers and I/O modules)
- Output Current: 20A (supports high-load devices)
- Redundancy Design: Dual AC power inputs with optional BBU for ≥30 minutes of backup during outages.
- Physical Dimensions: Approximately 220mm (length) × 230mm (width) × 80mm (height).
- Weight: ~0.3kg
- Protection Rating: IP20 (dust- and touch-proof, suitable for indoor environments).
- Operating Temperature: 0°C to 55°C (industrial-grade).
- Storage Temperature: -20°C to 70°C.
- Certifications: ATEX (Zone 2), DIN, CE, UL.
Honeywell CC-PDIL01 Digital Input Module
Technical Specifications
- Input Channels: 16 digital input channels (24V DC).
- Signal Types: Supports dry and wet contact inputs.
- Input Range: 0V (off) to 24V DC (on).
- Input Current: 5mA @ 24V DC (typical).
- Communication Protocol: Compatible with Modbus and other industrial standards.
- Power Supply: 24V DC.
- Operating Temperature: -20°C to +60°C (standard); some versions extend to -40°C to +110°C.
- Protection Rating: IP20 or higher (varies by model).
- Mounting: DIN rail or rack-mounted.
- Dimensions: Approximately 100mm (height/width/depth may vary by version).
- Weight: Around 2kg.
Honeywell CC-PCF901 51405047-175 Control Firewall Module
Technical Specifications
- Brand: Honeywell
- Model: CC-PCF901 51405047-175
- Origin: USA
- Voltage: 24V DC
- Communication Protocols: Supports Modbus, Profibus, Ethernet, and other industrial protocols for interoperability.
- Environmental Resistance: Operates in temperatures ranging from -40°C to 85°C, with IP67-rated protection against dust and water ingress.
- Mounting: DIN rail or rack-mounted for compact installation.
- Certifications: Complies with international safety and EMC standards, including CE and UL certifications.
Honeywell CC-PAIN01 Analog Input Module
Technical Specifications
- Input Channels: Typically 4 analog input channels (configurable for current/voltage signals).
- Input Range:
- Current: -20 mA to 20 mA
- Voltage: -10 V to 10 V
- Accuracy: ±0.1% of full-scale range.
- Resolution: 16-bit analog-to-digital conversion.
- Communication Interface: RS-485 for seamless integration with process control systems.
- Power Supply: 24 VDC.
- Operating Temperature: -40°C to 85°C (wide temperature range for extreme environments).
- Humidity Tolerance: 0% to 95% non-condensing.
- Protection Rating: IP67 (dust-tight and waterproof).
- Dimensions: 100 mm x 60 mm x 30 mm.
- Weight: 200 g.
Honeywell 80363975-100 PLC Module
Technical Specifications
- Brand: Honeywell
- Model: 80363975-100
- Place of Origin: United States
- Type: PLC Module
- Power Supply: Typically operates on standard industrial voltage levels (e.g., 24 VDC)
- Mounting: DIN rail or rack-mounted for compact installation
- Environmental Conditions: Designed to withstand harsh industrial environments, including temperature extremes and vibration.
- Communication Capabilities: Supports various communication protocols for seamless integration with other automation components.
Honeywell 51403519-160 K4LCN-16 Input/Output Module
Technical Specifications
- Brand: Honeywell
- Model: 51403519-160 K4LCN-16
- Processor: Motorola 68040
- Memory: 16 MB (non-expandable)
- Communication Protocol: LCN (Local Control Network) standard at 5 MHz
- I/O Channels: Configurable for analog and digital signals
- Operating Temperature: -40°C to 85°C
- Protection Rating: IP65 or higher (dust and water resistance)
- Mounting: DIN rail or rack-mounted
- Power Supply: 24 VDC
