• Frequency Bands: 5.8 GHz (5.725 - 5.850 GHz), 4.9 GHz (4.940 - 4.990 GHz), 2.4 GHz (2.400 - 2.4835 GHz).
• Data Rate: Up to 48 Mbps.
• Channel Bandwidth: 5, 10, or 20 MHz.
• Duplex Technique: TDD.
• Modulation: OFDM - BPSK, QPSK, 16 - QAM.
• RF Dynamic Range: More than 50 dB.
• Ethernet Interface: 10/100 BaseT, auto - negotiation, IEEE 802.3u.
• MAC Addresses: Up to 2048.
• Audio Channel: 2 Mbps or 64 kbps, Ethernet 10BaseT (64 kbps) G.711.

• Designed as part of the Mark VI or Mark Vie control system family, which are widely recognized for their application in gas and steam turbine controls.
• Supports various input/output configurations tailored to handle signals from sensors, actuators, and other field devices integral to turbine operations.
• Capable of operating within specific voltage ranges and environmental conditions suitable for industrial settings.
• Equipped with robust communication capabilities that facilitate integration with broader plant networks and SCADA systems.

• Communication Interfaces:
  • Four independent Ethernet interfaces
  • An integrated network switch
  • Supports various Ethernet-based protocols such as SRTP and Modbus TCP/IP
• Serial Interface: Enables on-board connectivity and allows for the addition of further network and fieldbus interfaces through PLC’s dual expansion ports
• Power Requirements: Varies depending on specific applications and configurations
• Remote Configuration and Diagnostics: Supports remote library linking functions, enabling remote configuration and diagnostics using a specific architecture
• Scalability: Offers a variety of expandable input/output (I/O) options, allowing users to select suitable I/O modules based on their actual needs
• Monitoring and Measurement: Integrates monitoring and measurement functions to provide real-time insights into the operational status of power systems and rich measurement data

• Channel Configuration: Typically offers multiple digital input channels for receiving and collecting discrete state signals from sensors, switches, and other digital devices. Some configurations may include a combination of digital inputs (DI) and digital outputs (DO), such as 4DI+6DO.
• Working Voltage: Supports a wide range of operating voltages, including 220V AC ±10%, ensuring compatibility with different power systems.
• Response Time: Features a rapid response time of ≤5ms, enabling real-time monitoring and control.
• Isolation Voltage: Provides high isolation voltage of 2500Vrms, ensuring electrical isolation and safety.
• Mechanical Dimensions: Compact design with dimensions of 180×150×40mm, facilitating easy installation in control cabinets.

Procurement Guidance

1. Compatibility Notes
   • Valid for VMEbus Rev. C.1 systems; firmware suffixes denote processor variants (e.g., -841 = Pentium III).
   • Backward-compatible with legacy GE VersaPAC/VME systems .
2. Critical Accessories
   • IC698ACC701 Lithium Battery: Mandatory for RAM backup .
   • Resolver/Encoder Modules (e.g., X6/X12 interfaces) for closed-loop control .
3. Avoid Mismatches
   • High-channel I/O claims → Use GE VMIVME-5565 series.
   • Core i7 processors → Refer to GE IC698CPE030.
4. Authenticity Verification
   • Holographic seals on factory-sealed units; 12-month warranty .
   • Cross-check part number 3BHE030579R0003 for industrial-grade variants .

Technical Specifications:

• Module Type: 16-channel analog-to-digital input module for VMEbus systems.
• Input Resolution: 16-bit resolution ensures high accuracy and fine signal discrimination across the measurement range.
• Input Voltage Ranges: Supports multiple selectable input ranges including ±10 V, ±5 V, 0–10 V, and 0–5 V, accommodating a wide variety of sensor and transducer outputs.
• Sampling Rate: Capable of high-speed data acquisition with a per-channel sampling rate up to 100 kHz, enabling real-time monitoring of fast-changing signals.
• Analog Inputs: Features 16 single-ended or 8 differential input channels, providing flexibility in signal connection and noise rejection.
