GE IC694ALG223
Product Introduction
The IC694ALG223 is a 16-channel single-ended analog current input module for PACSystems RX3i/RX7i, converting industrial 4-20 mA, 0-20 mA, and 4-20 mA Enhanced current signals to 12-bit digital data for PLC processing. Each channel is independently configurable, factory-calibrated, and features open-wire detection in Enhanced mode. It integrates 250 VAC optical isolation, high/low alarm limits, and hot-swap capability for mission-critical process and discrete applications. The module uses a detachable terminal board, has two status LEDs (Module OK, User Power), and occupies one chassis slot, serving as a high-density, high-precision solution for industrial signal acquisition.
GE IC693TCM302B
Product Introduction
The IC693TCM302B is an 8-channel temperature control module for the GE Fanuc Series 90-30 PLC system, managing eight independent temperature zones with thermocouple/RTD inputs and PWM discrete outputs. It supports open-loop manual control and closed-loop auto PID control, delivering ±1°C temperature accuracy and 12-bit (0.2°C) resolution. Revision B enhances temperature range and diagnostic capabilities, integrating seamlessly with Series 90-30 PLCs to simplify complex industrial temperature regulation. It features open thermocouple/reverse connection detection, out-of-tolerance monitoring, and programmable PWM outputs (0.1–60 seconds) for precise heating/cooling control, serving as a high-performance solution for multi-zone temperature management in industrial automation.
GE IC693PWR331D
Product Introduction
The IC693PWR331D is a high-capacity 30-watt power supply module designed exclusively for the GE Fanuc Series 90-30 PLC system, installed in the leftmost slot of Series 90-30 baseplates to supply power to CPUs, I/O modules, and peripheral devices. It is a DC-input module that operates on a 24 VDC nominal input with a wide range of 18-30 VDC, delivering three configurable outputs: +5 VDC (max 30 W for high-current logic needs), +24 VDC (relay) for relay output modules, and isolated +24 VDC for input modules and internal circuits. The module integrates overvoltage, overcurrent, and short-circuit protection with auto-shutdown, maintains a 20 ms minimum holdup time during voltage dips, and features four top-mounted LEDs for status monitoring (PWR, OK, RUN, BATT). It includes an RS-485 port for diagnostics and uses a detachable terminal board for simplified wiring, serving as a high-current power solution for Series 90-30 systems requiring enhanced +5 VDC capacity.
GE IC693PWR324
Product Introduction
The IC693PWR324 is a 30-watt AC/DC input power supply module for the GE Fanuc Series 90-30 PLC system, installed in the leftmost slot of Series 90-30 baseplates to power CPUs, I/O modules, and peripheral components. It accepts 85-264 VAC (50/60 Hz) or 100-300 VDC input, delivering three stable outputs: +5 VDC for logic circuits, +24 VDC (relay) for relay output modules, and isolated +24 VDC for input modules and internal circuits. The module integrates overvoltage, overcurrent, and short-circuit protection, with 20 ms minimum holdup time during power dips, and uses a detachable terminal board for field wiring. It features four top-mounted LEDs (PWR, OK, RUN, BATT) for status monitoring, supports RS-485 communication, and operates in 0°C - 60°C environments, serving as a foundational power component for Series 90-30 system integrity.
GE IC693PWR321
Product Introduction
The IC693PWR321 is a standard 30-watt power supply module dedicated to the GE Fanuc Series 90-30 PLC system, designed to mount in the leftmost slot of Series 90-30 baseplates and power the CPU, I/O modules, and peripheral components. It accepts a wide input range of 85-264 VAC (50/60 Hz) or 100-300 VDC, delivering three stable outputs: +5 VDC for logic circuits, +24 VDC (relay) for relay output modules, and isolated +24 VDC for input modules and internal module circuits. The module integrates overvoltage, overcurrent, and short-circuit protection, plus smart switch fusing and advanced diagnostics, ensuring reliable power delivery in industrial environments. It uses six user terminals for input wiring, maintains 20 ms minimum holdup time during power dips, and operates within a wide temperature range, serving as a foundational component for Series 90-30 system power integrity.
GE IC693MDL940L
Product Introduction
The IC693MDL940L is a 16-point normally-open (NO) relay output module belonging to the GE Fanuc Series 90-30 PLC system, tailored to switch both AC and DC loads with 2A per channel and 4A per group common. It is structured into four isolated groups of four output points each, each group having an independent common terminal. The module supports 5-30VDC and 5-250VAC (50/60Hz) field voltages, and provides 1500VDC isolation between the field and logic sides, as well as 500VAC isolation between groups. It is fitted with individual green LED indicators for each output point, uses a 20-pin removable terminal block, and draws 7mA from the 5VDC backplane and 135mA from the 24VDC backplane when all outputs are on. It can be installed in any I/O slot of Series 90-30 baseplates, providing a reliable solution for controlling heavy industrial loads in various automation applications.
GE IC693MDL940
Product Introduction
The IC693MDL940 is a 16-point normally-open (NO) relay output module designed for the GE Fanuc Series 90-30 PLC system, engineered to switch AC/DC loads with 2 A per channel and 4 A per group common. It features four isolated groups of 4 output points each, with independent common terminals, supporting 5-30 VDC and 5-250 VAC (50/60 Hz) field voltages to control devices like motor starters, solenoids, and indicators. The module provides 1500 VDC isolation between field and logic sides and 500 VAC between groups, with individual green LEDs for each output point for real-time status monitoring. It uses a 20-pin removable terminal block, draws 7 mA from the 5 VDC backplane and 135 mA from the 24 VDC backplane (all outputs on), and fits any I/O slot of Series 90-30 baseplates, serving as a robust solution for switching heavy industrial loads.
GE IC693MDL753
Product Introduction
The IC693MDL753 is a 32-point discrete output module dedicated to the GE Fanuc Series 90-30 PLC system, designed to drive 12/24VDC loads through positive (sourcing) logic. It has 32 output points divided into four isolated groups of eight, each with an independent common terminal that can bear up to 3A current per pin. The module can provide 0.5A current per channel and 4A current per group, supporting an inrush current of 5.4A for 10ms to meet the operation of inductive loads. It is equipped with optocouplers that provide 1500VDC isolation between the field side and the logic side to ensure the safety and stability of the system. Each output point is equipped with an individual green LED indicator for real-time monitoring, and it is installed with a 26-screw removable terminal block for easy wiring. It draws 260mA from the 5VDC backplane and can be inserted into any I/O slot of the Series 90-30 baseplate, making it an ideal choice for high-density and high-reliability load control applications.
GE IC693MDL740
Product Introduction
The IC693MDL740 is a 16-point discrete output module tailored for the GE Fanuc Series 90-30 PLC system, designed to drive 12/24VDC loads via positive (sourcing) logic. It features two independent groups of 8 output points with separate common terminals, delivering 0.5 A per channel and 2 A per group common, supporting inrush currents up to 4.78 A for 10 ms to handle inductive loads like relays and solenoids. The module provides 1500 VDC isolation between field and logic sides and 500 VAC between groups, with individual green LEDs for each output point to enable real-time status monitoring. It uses a 20-screw terminal block for secure wiring, draws 110 mA from the 5 VDC backplane, and fits any I/O slot of 5-slot or 10-slot Series 90-30 baseplates, serving as a reliable solution for industrial load control applications.
GE IC693MDL655K
Product Introduction
The IC693MDL655K is a high-density discrete input module tailored for the GE Fanuc Series 90-30 PLC system, engineered to collect 24VDC discrete input signals from industrial field devices. It features 32 input points split into four isolated groups of eight, each with an independent common terminal, supporting both positive and negative logic for versatile device integration. The module provides 1500 VDC isolation between the field and logic sides, plus 250 VAC isolation between groups, ensuring operational safety in harsh industrial environments. It incorporates individual LED indicators for each input point, a 32-screw removable terminal block for secure wiring, and optocoupler-based isolation for noise immunity. It draws 195 mA max from the 5 VDC backplane and 224 mA typical from the 24 VDC isolated bus, and fits any I/O slot of Series 90-30 baseplates, making it ideal for large-scale signal acquisition with high isolation and flexible grouping.
GE IC693MDL645
Product Introduction
The IC693MDL645 is a discrete input module designed for the GE Fanuc Series 90-30 PLC system, dedicated to collecting 24VDC discrete input signals from industrial field devices. It offers 16 input points arranged in a single group with a common power terminal, supports both positive and negative logic for flexible device compatibility, and features 1500 VDC isolation between the field and logic sides for enhanced safety. The module includes individual LED indicators for each input point, enabling real-time status monitoring, and comes with a 20-screw terminal block for secure wiring. It draws 80 mA from the 5 VDC backplane and 125 mA from the isolated 24 VDC bus, and can be installed in any I/O slot of 5-slot or 10-slot Series 90-30 baseplates, serving as a reliable solution for industrial signal acquisition applications.
GE IC693CPU374
Product Introduction
The IC693CPU374 is a high-performance single-slot CPU module in the GE Fanuc Series 90-30 PLC system, serving as the core for advanced industrial automation with real-time processing and communication. It is powered by a 133 MHz AMD SC520 (586-class) processor, delivering a 0.15 ms per 1K Boolean logic scan rate for rapid control execution. It features 240 KB of user memory (Flash + RAM), dual embedded 10/100 Mbps Ethernet ports with auto-sensing, and an RS-485 serial port (via power supply) supporting SNP/SNPX protocols. The module supports up to 8 baseplates (1 CPU + 7 expansion/remote), works with VersaPro 2.03+ and Proficy Machine Edition 2.60+ software, and preserves data via battery backup, making it ideal for medium to large-scale automation requiring high-speed communication and complex logic processing.
