GE IC695CPE330
Product Overview
The IC695CPE330 is a dual‑width hot standby redundancy CPU module from GE Fanuc (Emerson Automation) for PACSystems RX3i PLCs, powered by a 1.6GHz dual‑core industrial processor. It provides 64MB user RAM, 64MB non‑volatile flash, and a CFast slot for removable storage, plus 3‑port 10/100/1000 Ethernet (2 switched + 1 uplink), USB 2.0, and dual independent LANs for redundancy. The module supports Hot Standby Redundancy (PROFINET/EGD/Genius I/O), 32Kbits discrete %I/%Q and 32Kwords analog %AI/%AQ, and runs on 3.3V (2.0A)/5V (2.5A)/24V (0.6A startup/0.2A run, Energy Pack) backplane power. It uses ladder/ST/FBD/C programming, handles up to 512 program blocks (128KB max/block), and offers optional IC695ACC400 Energy Pack for power‑loss data protection, with UL/CE/ATEX/DNV GL certifications for industrial/hazardous/marine use.
GE IC695CPE310-ACAT
Product Overview
The IC695CPE310 - ACAT is a high - performance dual - width CPU module belonging to GE Fanuc (Emerson Automation)'s PACSystems RX3i PLC series, with a 1.1GHz Intel Atom industrial processor at its core. It is equipped with 10MB user RAM and 10MB non - volatile flash storage, and integrates a 3 - port 10/100/1000 Ethernet switch (2 switch ports and 1 uplink port), isolated RS - 232/RS - 485 serial ports, and a USB 2.0 Type - A port. This module supports dual - purpose PCI and serial backplanes, which enables seamless compatibility with RX3i and Series 90 - 30 I/O modules. It has a Boolean logic execution speed of 0.72ms per 1000 instructions, can handle 32Kbits of discrete %I/%Q and 32Kwords of analog %AI/%AQ, and supports 4 programming languages, namely Ladder Diagram, Structured Text, Function Block Diagram, and C, along with a maximum of 512 program blocks (128KB per block). It holds UL, CE, ATEX Zone 2, and DNV GL marine certifications, and its optional IC695ACC400 Energy Pack can protect data when power is lost.
GE IC695CPE310
Product Overview
The IC695CPE310 is a high‑performance dual‑width CPU module from GE Fanuc (Emerson Automation) for PACSystems RX3i controllers, featuring a 1.1GHz Intel Atom processor, 10MB user RAM, 10MB non‑volatile flash, and a 3‑port 10/100/1000 Ethernet switch (2‑port switch + 1 uplink). It includes isolated RS‑232/RS‑485 serial ports, USB 2.0, and dual PCI/serial backplane support for RX3i/Series 90‑30 I/O. The module delivers 0.72ms per 1000 Boolean instructions scan time, supports 32Kbits discrete %I/%Q and 32Kwords analog %AI/%AQ, and runs on 3.3V (1.2A)/5V (1.5A)/24V (0.5A startup/0.1A run, Energy Pack) backplane power. It uses ladder/ST/FBD/C programming, handles up to 512 program blocks (128KB max/block), and offers optional IC695ACC400 Energy Pack for power‑loss data protection, with UL/CE/ATEX/DNV GL certifications for industrial/hazardous/marine use.
GE IC695CPE305
Product Overview
The IC695CPE305 is a single‑slot, high‑performance CPU module from GE Fanuc (Emerson Automation) for PACSystems RX3i PLCs, featuring a 1.1GHz processor, 5MB RAM user memory, 5MB non‑volatile flash storage, and embedded 10/100Mbps Ethernet (PROFINET, Modbus TCP, SRTP), RS‑232 serial, and USB 2.0 ports. It supports 4 programming languages (Ladder Diagram, Structured Text, Function Block Diagram, C), 512 program blocks (max 128KB/block), and legacy Series 90‑30 I/O compatibility. The module runs on 3.3V (1.0A)/5V (1.0A, up to 1.5A with USB)/24V (0.5A startup/0.1A run, Energy Pack) backplane power, has 32Kbits discrete/%I/%Q and 32Kwords analog/%AI/%AQ reference tables, and includes an optional IC695ACC400 Energy Pack for power‑loss data protection. It delivers deterministic control for process/manufacturing automation with 0.72ms per 1000 Boolean instructions scan time and seamless HMI/SCADA integration via OPC UA.
GE IC695CHS007
Product Overview
The IC695CHS007 is a 7‑slot universal backplane from GE Fanuc (Emerson Automation) for PACSystems RX3i controllers, supporting both PCI‑based (IC695) and serial backplane (IC693/IC694) I/O/option modules, plus Series 90‑30 I/O. Slot 0 is dedicated to IC695 power supplies; Slots 1–5 have dual PCI/serial connectors; Slot 6 has PCI‑only connectors for IC695 single‑width modules. It features a left‑end 24V terminal strip, integral grounding bar, backplane ground point, and printed slot numbering. The backplane uses 3.3V (600mA)/5V (240mA) internal power, fits compact industrial enclosures, and carries UL/CE/ATEX certifications, enabling flexible, high‑density control system builds with hot‑swap capability and mixed module compatibility.
GE IC695ALG616-EA
Product Overview
The IC695ALG616‑EA is a non‑isolated differential analog input module from GE Fanuc (Emerson Automation) for PACSystems RX3i PLCs, delivering 16 single‑ended or 8 differential channels for voltage/current signals (0–20mA, 4–20mA, ±20mA, ±10V, 0–10V, ±5V, 0–5V, 1–5V). It uses a 24‑bit ADC (12‑bit effective for linearity) with 10µs per‑channel conversion, 0.2% voltage/0.35% current accuracy, and 6 selectable filter cutoffs (8–500Hz). The single‑slot module runs on 3.3V (450mA)/5V (600mA) backplane power, has Module OK/Field Status LEDs, and works with RX3i universal backplanes (CPU firmware ≥3.0, Machine Edition ≥5.0 SP3). It converts sensor signals (temperature, pressure, flow) into PLC‑readable data for real‑time control in process/manufacturing automation.
GE IC695ACC412
Product Overview
The IC695ACC412 is a capacitor-based energy pack accessory for the GE Fanuc PACSystems RX3i IC695CPE330 controller, preserving user memory during power loss via an internal capacitor array. It mounts at the energy pack bottom, provides 60 seconds of typical memory retention, charges fully in 60–90 minutes, and uses IN/OUT/STAT LEDs for status/charging. The module carries T4A temperature code, suits Class I, Division 2, Groups A–D hazardous locations, and meets UL/CE safety standards, ensuring data integrity for mission-critical industrial control systems.
GE IC694MDL940
Product Overview
The IC694MDL940 is a 16‑channel normally‑open (Form A) relay output module from GE Fanuc (Emerson Automation) for PACSystems RX3i PLCs, offering 16 individually isolated outputs split into 4 groups of 4, each with a dedicated common terminal. It switches AC/DC loads (5–250VAC, 5–30VDC) with 2A per point (pilot duty), 4A per group common, and 5A inrush handling, plus 250VAC continuous (1500VAC surge) field‑to‑backplane/point‑to‑point isolation. It has 15ms on/off response, per‑channel LED indicators, and runs on +24VDC backplane power (135mA) with no external supply needed. The single‑slot module converts PLC digital commands into relay‑switched signals for industrial actuators, ideal for mixed AC/DC control with noise immunity and safety isolation.
GE IC694MDL753
Product Overview
The IC694MDL753 is a 32‑channel positive logic (sourcing) digital output module from GE Fanuc (Emerson Automation) for PACSystems RX3i PLCs, delivering 32 discrete outputs organized into 4 isolated groups of 8 channels, each with its own common terminal. It operates at 12–24 VDC (10.2–28.8 VDC range), sources 0.5A per point (4A max per group, 3A per common pin), and features 250VAC continuous field‑to‑backplane isolation (1500VAC surge for 1 minute) and 50VAC group‑to‑group isolation (500VAC surge). The module uses opto‑couplers for isolation, has LED diagnostics (Module OK, Power, Group/Channel Faults), and forces all outputs OFF during CPU/backplane power loss (external power active). It fits any RX3i I/O slot, requiring +5VDC backplane power (260mA max) and user‑supplied 12–24 VDC external power, converting digital commands into switching signals for industrial loads.
GE IC694ALG392
roduct Overview
The IC694ALG392 is a high‑precision 8‑channel analog current/voltage output module from GE Fanuc (Emerson Automation) for PACSystems RX3i PLCs, offering 8 single‑ended channels configurable per channel to 0–10V, -10–+10V (voltage) or 0–20mA, 4–20mA (current) ranges. It delivers 16‑bit resolution, ±0.25% full‑scale accuracy at 25°C, and 8ms update for all 8 channels, with 1500VAC input‑to‑backplane isolation, open‑wire detection in current mode, and LED diagnostics (Module OK, Power, Channel Faults). The module fits any RX3i I/O slot, requiring +5VDC backplane power (110mA) and 20–30VDC external power (315mA), converting digital data into precise analog signals to control industrial actuators in real‑time process applications.
GE IC694ALG222GE
Product Overview
The IC694ALG222GE is a high‑density 16‑channel analog voltage input module from GE Fanuc (Emerson Automation) for PACSystems RX3i PLCs, offering 16 single‑ended or 8 differential voltage inputs configurable per channel to 0–10V (unipolar) or -10–+10V (bipolar) ranges. It delivers 12‑bit resolution, ±0.25% full‑scale accuracy at 25°C, and ±0.5% full‑scale accuracy over the operating range, with 6ms update for all 16 single‑ended channels or 3ms for all 8 differential channels. The module provides 1500VAC input‑to‑backplane isolation, 41Hz/82Hz selectable input filters, and LED diagnostics (Module OK, Power, Channel Faults). It fits any RX3i I/O slot, requiring +5VDC backplane power (112mA) and isolated +24VDC external power (41mA), converting voltage signals from sensors/transmitters into digital data for real‑time process control in industrial environments.
GE IC693TCM302
Product Overview
The IC693TCM302 is a high‑performance 8‑channel temperature control module from GE Fanuc (Emerson Automation) for Series 90‑30 PLC systems, integrating 8 thermocouple inputs (J, K, L types) and 8 PWM relay outputs in a single slot. It supports closed‑loop PID control or open‑loop manual control per zone, with 12‑bit (0.2°C) resolution, ±1°C accuracy, and automatic cold junction compensation via 1 RTD channel or external reference. The module provides 18–30VDC relay outputs (100mA per channel), open thermocouple/reverse connection detection, and LED status indicators for quick diagnostics, fitting standard Series 90‑30 baseplates to control 8 independent temperature zones in industrial processes.
