Bently Nevada 350005-01-01-00-00-00 3500/05 Mini System Rack
Technical Specifications
-
Form Factor: 12-inch mini-rack, 7 usable module slots
-
Material: High-strength aluminum alloy frame with stainless-steel guide rails
-
Power Inputs: 85–264 Vac or 88–300 Vdc, auto-ranging; redundant inputs accepted
-
Back-plane Output: +5 Vdc @ 30 A, +12 Vdc @ 4 A, –12 Vdc @ 1 A, all isolated
-
Slot Pitch: 20.3 mm (0.8 in) per slot, hot-swappable modules
-
Earth Isolation: 500 Vdc module-to-earth, 1500 Vdc channel-to-earth
-
Vibration Survivability: 5 g, 10–500 Hz per IEC 60068-2-6
-
Shock: 30 g, 11 ms half-sine per IEC 60068-2-27
-
Operating Temperature: –40 °C to +85 °C (–40 °F to +185 °F)
-
Ingress Protection: IP 20 (NEMA 1); optional IP 54 door kit
-
Dimensions: 228 mm × 132 mm × 160 mm (9.0" × 5.2" × 6.3") without door
-
Weight: 1.2 kg (2.6 lb) empty
-
Mounting Options: Panel, 19-inch sub-rail, or bulk-head; front or rear access
-
Agency Approvals: CE, UL, ATEX, IECEx, CSA, TR CU, ABS Marine, RoHS, REACH
Bently Nevada 350005-01-01-00-00-01 3500/05 Mini System Rack
Technical Specifications
-
Form Factor: 9.1-inch mini-rack, 7 usable module slots
-
Material: High-strength aluminum alloy frame with stainless-steel guide rails
-
Power Inputs: 85–264 Vac or 88–300 Vdc, auto-ranging; redundant inputs accepted
-
Back-plane Output: +5 Vdc @ 30 A, +12 Vdc @ 4 A, –12 Vdc @ 1 A, all isolated
-
Slot Pitch: 20.3 mm (0.8 in) per slot, hot-swappable modules
-
Earth Isolation: 500 Vdc module-to-earth, 1500 Vdc channel-to-earth
-
Vibration Survivability: 5 g, 10–500 Hz per IEC 60068-2-6
-
Shock: 30 g, 11 ms half-sine per IEC 60068-2-27
-
Operating Temperature: –40 °C to +85 °C (–40 °F to +185 °F)
-
Ingress Protection: IP 20 (NEMA 1); optional IP 54 door kit
-
Dimensions: 231 mm × 160 mm × 81 mm (9.1" × 6.3" × 3.2") without door
-
Weight: 1.2 lb (0.54 kg) empty
-
Mounting Options: Panel, 19-inch sub-rail, or bulk-head; front or rear access
-
Agency Approvals: CE, UL, ATEX, IECEx, CSA, TR CU, ABS Marine, RoHS, REACH
Bently Nevada 350040M 125680-01 4-Channel Proximitor Monitor
Technical Specifications
– Channels : 4 independent, fully isolated
– Input types : eddy-current, velocity, accelerometer
– Measurement modes : radial vibration, thrust position, eccentricity, differential expansion, REBAM, shaft absolute
– Full-scale range : 0 – 10 mm pk-pk or 0 – 50 g (software selectable)
– Frequency response : 0.125 Hz – 3 836 Hz (–3 dB) with direct, gap, band-pass and high-pass filters
– Resolution : 16-bit ADC, <0.02 % non-linearity
– Accuracy : ±0.33 % typical, ±1 % max
– Update rate : 10 kHz per channel
– Alarm relays : 2 per channel (Warning & Danger), latched or unlatched
– Analog outputs : 4 – 20 mA isolated, proportional to measured value
– Power draw : 24 Vdc from rack back-plane, 2.5 W typical
– Sensor supply : –24 Vdc, 50 mA max per channel
– MTBF : >300 000 h @ 45 °C per MIL-HDBK-217F
– Operating temperature : –40 °C to +85 °C
– Storage temperature : –55 °C to +125 °C
– Humidity : 5 % – 95 % RH non-condensing
– Shock / vibration : 15 g ½-sine 11 ms; 2 g 5 – 500 Hz operational
– Dimensions : 99 mm × 24 mm × 241 mm (3.9" × 0.96" × 9.5")
– Weight : 0.34 kg (0.75 lb)
– Agency approvals : CE, UL/cUL Class I Div 2, ATEX/IECEx Zone 2, RoHS
