Foxboro 870ITEC-AYFNZ Industrial Controller Module
Technical Specifications
- Power Supply:
- 24V DC (standard configuration)
- Optional 220V AC (50/60 Hz) for specific applications
- I/O Configuration:
- Digital Input: 16 channels (supporting 24V DC signals)
- Digital Output: 16 channels (relay or solid-state, configurable)
- Analog Input: 4 channels (4-20mA, 0-10V, or 0-5V with HART communication)
- Analog Output: 2 channels (4-20mA or 0-10V)
- Communication Interfaces:
- Ethernet (10/100 Mbps) for high-speed data exchange
- RS-232/RS-485 for serial communication with legacy devices
- Environmental Tolerance:
- Operating Temperature: -10°C to 60°C
- Storage Temperature: -40°C to 70°C
- Humidity: 5% to 95% (non-condensing)
Foxboro 1C31169G02 Industrial Control Module
Technical Specifications
- Input/Output Channels:
- Supports multiple discrete and analog I/O channels (specific configurations vary by model).
- Discrete inputs: 125 VAC/VDC (differential or single-ended).
- Discrete outputs: 5-60 VDC (relay or solid-state).
- Analog inputs: 4-20 mA, 0-10 V, or 0-5 V with HART communication capability.
- Analog outputs: 4-20 mA or 0-10 V.
- Power Supply:
- Dual redundant DC power inputs (24 VDC or 48 VDC) for fail-safe operation.
- Optional AC power supply (120/230 VAC, 50/60 Hz).
ExtremeNetworks A2H124-24FX Industrial Ethernet Switch
Technical Specifications
- Ports:
- 24 x 100BASE-FX fiber ports (multi-mode or single-mode, depending on module)
- 2 x Gigabit Ethernet SFP uplink ports (for high-speed backbone connections)
- Switching Capacity: Up to 17.6 Gbps
- Forwarding Rate: 9.5 Mpps (million packets per second)
- MAC Address Table: 16K entries
- VLAN Support: Up to 4096 virtual LANs for network segmentation
- Jumbo Frame Support: Up to 9216 bytes for efficient data transmission
- Stacking: Supports up to 8 units in a stack, creating a virtual switch with 140.8 Gbps bandwidth and 192 x fiber ports + 16 x Gigabit uplinks
- Power Supply:
- Dual DC 48V power inputs (redundant design for failover)
- AC power option available (120/230V, 50-60Hz)
ExtremeNetworks A4H124-24FXP0973JN
Technical Specifications
- Switching Capacity: Up to 17.6 Gbps
- Forwarding Rate: 9.5 Mpps (million packets per second)
- Port Configuration:
- 24 x 10/100 Ethernet ports (100Base-FX fiber ports)
- 4 x Gigabit Ethernet uplink ports (SFP slots for fiber or copper modules)
- MAC Address Table: 16K entries
- VLAN Support: Up to 4096 virtual LANs
- Jumbo Frame Support: Up to 9216 bytes
- Stacking Capability: Supports stacking up to 8 units, creating a virtual switch with up to 140.8 Gbps of capacity and 384 x 10/100 ports + 16 x Gigabit uplinks
