ICS Triplex T8850 Triple Modular Redundant (TMR) Digital Input/Output Module
Technical Specifications
- Channels: 40 digital input/output channels (configurable for either input or output).
- Voltage Range:
- Operating voltage: 24 V DC (standard); supports up to 60 V DC via external power distribution units.
- Field terminal wire size: 12 AWG to 28 AWG.
- Current Rating:
- Maximum current per channel: 2 A.
- Power dissipation: 0.5 W per power group.
- Isolation:
- Channel-to-channel isolation: 50 V reinforced (continuous), tested at 1411 V DC for 60 seconds.
- Power group-to-power group isolation: 250 V basic (fault), tested at 2436 V DC for 60 seconds.
ICS Triplex T8480C Digital Input Module
Technical Specifications
- Input Channels: 32 digital input channels for receiving switch-type signals from field devices (e.g., buttons, relays, limit switches).
- Voltage Range: 24 V DC (operating voltage).
- Current Range: 2 A per channel.
- Response Time: Less than 2 milliseconds for rapid signal capture.
- Accuracy: ±0.1% for precise measurement.
- Isolation Voltage: 250 V RMS (channel-to-ground isolation).
- Surge Voltage: 4 kV for protection against electrical surges.
- Noise Suppression: 500 V/μs to minimize interference.
ICS Triplex T8461C Digital Output Module
Technical Specifications
- Output Channels: 40 digital output channels for controlling external devices like valves, motors, and relays.
- Voltage Range:
- System power supply: 20–32 V DC
- Working output/field voltage: 18–60 V DC
- Output Current: 0.75 A per channel
- Response Time: Less than 1 millisecond for rapid switching.
- Isolation: 2500 V pulse-tolerant optical isolation barrier to prevent electrical interference.
- Protection: Automatic overcurrent protection per channel (no external fuses required).
- Power Groups: 8 independent power groups (5 outputs per group) for flexible device power management.
ICS Triplex T8461 Digital Output Module
Technical Specifications
- Output Channels: 40 digital output channels for controlling external devices like valves, motors, and relays.
- Voltage Range:
- System power supply: 20–32 V DC
- Working output/field voltage: 18–60 V DC
- Isolation: 2500 V pulse-tolerant optical isolation barrier to prevent electrical interference.
- Protection: Automatic overcurrent protection per channel (no external fuses required).
- Response Time: Sub-millisecond switching for real-time control.
- Event Reporting: Sequence of Events (SOE) logging with 1 ms resolution for troubleshooting.
- Power Groups: 8 independent power groups (5 outputs per group) for flexible device power management.
- Environmental Rating: IP20 enclosure (dust-protected, non-immersion-resistant).
- Operating Temperature: -40°C to +70°C, suitable for extreme industrial conditions.
- Communication Protocols: Supports Modbus, Profibus, and Foundation Fieldbus for seamless integration.
ICS Triplex T8403C Trusted Digital Input Module
Technical Specifications
- Input Channels: 32 digital input channels for connecting multiple discrete sensors or switches.
- Input Voltage: 24 V DC, compatible with standard industrial power supplies.
- Operating Temperature Range: -40°C to +70°C, enabling deployment in extreme conditions.
- Protection Rating: IP65, offering dust-tight and water-resistant enclosure.
- Dimensions: 192 mm (L) x 92 mm (W) x 35 mm (H), compact for space-constrained installations.
- Weight: 0.7 kg, facilitating easy integration into existing systems.
- Communication Protocols: Supports Modbus TCP/IP, Ethernet, and other industrial protocols for seamless integration.
- Response Time: Less than 1 millisecond, ensuring real-time data acquisition.
- Accuracy: ±0.1%, providing precise signal interpretation.
ICS Triplex T8403 Triple Modular Redundant (TMR) Safety Controller Module
Technical Specifications
- Architecture: True TMR with three isolated CPU channels and redundant voting logic.
- Power Supply: 24 V DC (redundant power inputs supported).
- Operating Temperature: 0°C to 60°C (industrial-grade design).
- Enclosure Rating: IP20 (dust-protected, non-immersion-resistant).
- Safety Certifications: Complies with IEC 61508 SIL3 and IEC 61511 SIL3 standards.
- Hot-Swap Support: Faulty modules can be replaced during operation without system interruption.
- Diagnostic Features: Built-in memory tests, communication checks, watchdog timers, and LED status indicators for each CPU channel (RUN/COMM/FAIL/RED).
- Processing Speed: Sub-millisecond response time for critical safety actions.
- Connectivity: Supports Ethernet, serial ports (RS-232/RS-485), and fieldbus protocols (e.g., Modbus TCP/IP, OPC UA).
ICS Triplex T8830 Trusted 40-Channel Analogue Input Field Termination Assembly (FTA)
Technical Specifications
- Input Channels: 40 analogue channels, supporting simultaneous connection of multiple sensors (e.g., temperature, pressure, flow).
- Signal Conversion: Converts analogue signals (voltage/current) into digital data for transmission to control systems via industrial protocols like Modbus or Profibus.
- Input Range: Compatible with a wide range of sensor outputs, including 0-10V and 4-20mA signals.
- Resolution: Features 16-bit ADC (Analog-to-Digital Converter) for high-precision capture of minute signal variations.
- Sampling Rate: Short sampling cycles to meet real-time control demands.
- Redundancy: Certain models support redundant configurations to enhance system availability and prevent data loss from single-point failures.
- Isolation: Electrical isolation technology minimizes electromagnetic interference (EMI) for accurate data transmission.
Honeywell TK-IOLI01 I/O LIM Link Interface Module
Technical Specifications
- Brand: Honeywell
- Model: TK-IOLI01
- I/O Module Support: Supports up to 8 I/O modules
- Communication Protocol: LIM link communication
- I/O Point Types: Configurable
- Standards Compliance: Meets IEC 61131-2 standards
- Protection Class: IP66
- Operating Temperature Range: -40°C to 70°C
- Humidity Range: 5% to 95% (non-condensing)
- Physical Dimensions: Compact design for easy installation in standard industrial enclosures
Honeywell TC-PRR021 51309288-225
Technical Specifications
- Brand: Honeywell
- Model: TC-PRR021
- Part Number: 51309288-225
- Type: Redundancy Module for DCS
- Shipping Weight: Approximately 2.6 kg
- Design: Compact and rugged, suitable for mounting in standard industrial enclosures or control panels.
- Environmental Resistance: Built to withstand harsh industrial environments, with resistance to dust, moisture, and electrical noise.
Honeywell TC-PRR021 Redundancy Module
Technical Specifications
- Brand: Honeywell
- Model: TC-PRR021
- Type: Redundancy Module for DCS
- Voltage Rating: Supports a wide range of DC input voltages, typically from 18V to 32V DC, ensuring compatibility with various power supplies.
- Power Consumption: Low power consumption, with typical values around 3.25W for 4-20mA signals and 3.75W for catalytic sensors, contributing to energy efficiency.
- Environmental Resistance: Designed to operate in harsh industrial environments, with resistance to dust, moisture, and electrical noise.
- Physical Dimensions: Compact and rugged design, suitable for mounting in standard industrial enclosures or control panels.
- Weight: Lightweight, facilitating easy installation and handling.
Honeywell TC-PPD011 Analog Input Module
Technical Specifications
- Brand: Honeywell
- Model: TC-PPD011
- Type: Analog Input Module
- Signal Processing Capability:
- Supports 4-20mA and 0-5V analog signals.
- Capable of processing multiple types of analog inputs, converting them into digital signals for control systems.
- Communication Protocols:
- Supports UDP, TCP, and other communication protocols for multi-center data transmission.
- Ensures timely and accurate data transfer between the module and control systems.
Honeywell TC-PCIC01K Digital Input/Output Module
Technical Specifications
- Brand: Honeywell
- Model: TC-PCIC01K
- Type: Digital Input/Output Module
- Input/Output Configuration: The module supports multiple digital input and output channels, allowing for flexible configuration based on specific application requirements.
- Voltage Rating: Designed to operate within a standard industrial voltage range, ensuring compatibility with common power supplies.
- Communication Protocol: Supports standard industrial communication protocols, facilitating integration with Honeywell's Experion PKS and other control systems.
- Environmental Resistance: Built to withstand harsh industrial environments, featuring resistance to dust, moisture, and electrical noise.
- Physical Dimensions: Compact design for easy installation in standard industrial enclosures or control panels.
