The IC693MDL655K is a high-density discrete input module tailored for the GE Fanuc Series 90-30 PLC system, engineered to collect 24VDC discrete input signals from industrial field devices. It features 32 input points split into four isolated groups of eight, each with an independent common terminal, supporting both positive and negative logic for versatile device integration. The module provides 1500 VDC isolation between the field and logic sides, plus 250 VAC isolation between groups, ensuring operational safety in harsh industrial environments. It incorporates individual LED indicators for each input point, a 32-screw removable terminal block for secure wiring, and optocoupler-based isolation for noise immunity. It draws 195 mA max from the 5 VDC backplane and 224 mA typical from the 24 VDC isolated bus, and fits any I/O slot of Series 90-30 baseplates, making it ideal for large-scale signal acquisition with high isolation and flexible grouping.

The IC693MDL730 is an 8‑channel discrete output module from GE Fanuc (now part of Emerson Automation) for the Series 90‑30 PLC platform, providing 12/24VDC positive logic transistor outputs in a single group with a shared common terminal. It uses 1500V field‑to‑logic isolation to protect against noise and transients, supports 2A per‑channel current capacity, and offers 9.4A inrush current for 10 ms to handle inductive loads. The module has a 2A group fuse at 60°C (4A at 50°C) for overload protection, a 5V backplane power draw of 120 mA, and operates with an external 12/24VDC supply (10.2–28.8VDC range). It serves as a high‑current interface for controlling industrial actuators, solenoids, and motor starters in harsh environments.

The IC693MDL753 is a 32-point discrete output module dedicated to the GE Fanuc Series 90-30 PLC system, designed to drive 12/24VDC loads through positive (sourcing) logic. It has 32 output points divided into four isolated groups of eight, each with an independent common terminal that can bear up to 3A current per pin. The module can provide 0.5A current per channel and 4A current per group, supporting an inrush current of 5.4A for 10ms to meet the operation of inductive loads. It is equipped with optocouplers that provide 1500VDC isolation between the field side and the logic side to ensure the safety and stability of the system. Each output point is equipped with an individual green LED indicator for real-time monitoring, and it is installed with a 26-screw removable terminal block for easy wiring. It draws 260mA from the 5VDC backplane and can be inserted into any I/O slot of the Series 90-30 baseplate, making it an ideal choice for high-density and high-reliability load control applications.

The IC693MDL753K is a 32‑channel discrete output module from GE Fanuc (now part of Emerson Automation) for the Series 90‑30 PLC platform, offering 0.5A per‑channel transistor outputs in four isolated groups of eight channels each, with independent commons for flexible field wiring. It employs 1500VAC field‑to‑logic optical isolation to shield against electrical noise and transients, supports 10.2–28.8VDC output voltage, and delivers 5.4A inrush current for 10 ms to handle inductive loads like solenoids and small motors. The module has a 260 mA 5V backplane power draw, 0.3V max on‑state voltage drop, and 1.1 mA max off‑state leakage current, ensuring efficient and reliable operation in industrial environments. It integrates seamlessly with Series 90‑30 baseplates, power supplies, and CPUs, serving as a high‑density, isolated interface for controlling multiple DC loads in automation systems.

The IC693MDL940L is a 16-point normally-open (NO) relay output module belonging to the GE Fanuc Series 90-30 PLC system, tailored to switch both AC and DC loads with 2A per channel and 4A per group common. It is structured into four isolated groups of four output points each, each group having an independent common terminal. The module supports 5-30VDC and 5-250VAC (50/60Hz) field voltages, and provides 1500VDC isolation between the field and logic sides, as well as 500VAC isolation between groups. It is fitted with individual green LED indicators for each output point, uses a 20-pin removable terminal block, and draws 7mA from the 5VDC backplane and 135mA from the 24VDC backplane when all outputs are on. It can be installed in any I/O slot of Series 90-30 baseplates, providing a reliable solution for controlling heavy industrial loads in various automation applications.

The IC693MDR390C is a single‑slot mixed I/O module from GE Fanuc (Emerson Automation) for the Series 90‑30 PLC platform, integrating 8 channels of 24VDC discrete input (sinking/sourcing) and 8 channels of normally‑open relay output (2 groups × 4 channels, independent commons). It features 1500VAC field‑to‑logic optical isolation and 500VAC group‑to‑group isolation to block noise and transients, supporting 15–32VDC input voltage and 5–30VDC/5–250VAC output voltage. The module delivers 2A max per output channel and 4A max per group common, with 70 mA 24V relay supply and 80 mA 5V backplane power draw. It offers 7 ms typical input response and ≤15 ms output response, with channel‑level LEDs for input/output status, serving as a compact, integrated interface for combined sensing and actuation in industrial automation.
