Motorola MVME-2604761 VMEbus Input/Output (I/O) Module
Technical Specifications
- Processor Compatibility: Based on the Motorola PowerPlus VME architecture, compatible with PowerPC-based microprocessors such as the MPC60x series.
- Memory: Supports up to 512 MB of ECC DRAM onboard memory for reliable data storage and processing. Additionally, it includes 8 MB of board-mounted flash memory and a 1 MB slot for additional storage expansion.
- Cache: Equipped with 16 KB/16 KB or 32 KB/32 KB L1 cache and 256 KB of L2 cache to enhance processing performance.
Motorola MVME-61006E-0163 VMEbus Single Board Computer
Technical Specifications
- Processor: Equipped with an NXP MPC7457 PowerPC processor, running at up to 1.267 GHz, featuring a 128-bit AltiVec coprocessor for enhanced parallel processing capabilities.
- Memory: Supports up to 1 GB of ECC-protected DDR DRAM for reliable data storage and processing, along with up to 128 MB of flash memory for firmware and application storage.
- VMEbus Interface: Utilizes the Tundra Tsi148 VMEBridge ASIC, providing 2eSST protocol support for a VMEbus transfer rate of up to 320 MB/s, ensuring high-speed data communication within the VMEbus system.
- I/O Interfaces:
- Ethernet: Dual Gigabit Ethernet ports for high-speed network connectivity.
- Serial Ports: One asynchronous serial port for communication with peripheral devices.
- PMC Sites: Two 64-bit PMC (PCI Mezzanine Card) sites, supporting PCI bus speeds from 33 MHz to 66 MHz, allowing for expansion with industry-standard modules.
- Other Interfaces: Includes a reset and abort switch, and LED indicators for board status monitoring.
Motorola MVME-6100 VMEbus Single Board Computer
Technical Specifications
- Processor: Equipped with an NXP MPC7457 PowerPC processor running at up to 1.267 GHz, featuring a 128-bit AltiVec coprocessor for enhanced parallel processing capabilities.
- Memory: Supports up to 2 GB of ECC-protected DDR DRAM for reliable data storage and processing, along with up to 128 MB of flash memory for firmware and application storage.
- VMEbus Interface: Utilizes the Tundra Tsi148 VMEBridge ASIC, providing 2eSST protocol support for a VMEbus transfer rate of up to 320 MB/s, ensuring high-speed data communication within the VMEbus system.
- I/O Interfaces:
- Ethernet: Dual Gigabit Ethernet ports for high-speed network connectivity.
- Serial Ports: One asynchronous serial port for communication with peripheral devices.
- PMC Sites: Two 64-bit PMC (PCI Mezzanine Card) sites, supporting PCI bus speeds from 33 MHz to 100 MHz, allowing for expansion with industry-standard modules.
- Other Interfaces: Includes a reset and abort switch, and LED indicators for board status monitoring.
MOTOROLA MVME-5500-0163 VMEbus Single Board Computer
Technical Specifications
- Processor: Equipped with a high-performance 1 GHz MPC7455 or MPC7457 PowerPC processor, featuring 512 KB L2 cache and 2 MB L3 cache for superior computational capabilities.
- Memory: Supports up to 512 MB ECC SDRAM onboard, with options for expansion via memory mezzanine cards. It also includes flash memory for firmware storage.
- I/O Interfaces:
- Ethernet: One Gigabit Ethernet port and one additional 10/100BaseTX Ethernet port for high-speed network connectivity.
- Serial Ports: Two asynchronous serial ports for communication with peripheral devices.
- PCI and PMC Sites: Dual independent 64-bit PCI buses operating at 33/66 MHz, each with a PMC site for expansion cards.
- VME Interface: Universe II VME interface for seamless integration with VMEbus systems.
- Expansion Connectors: 64-bit PCI expansion mezzanine connector for additional I/O expansion.
MOTOROLA MVME-5500 VMEbus High-Performance Single Board Computer
Technical Specifications
- Processor: Equipped with a high-performance 1GHz MPC7457 PowerPC processor, featuring 32KB/32KB L1 cache, 512KB L2 cache, and 2MB L3 cache for enhanced processing capabilities.
- Memory: Supports up to 512MB PC133 ECC SDRAM onboard, expandable to 1GB via memory mezzanine cards. Also includes 32KB NVRAM (4KB user-accessible) with battery backup for data retention.
- I/O Interfaces:
- Ethernet: One Gigabit Ethernet port and one additional 10/100BaseTX Ethernet port for high-speed network connectivity.
- Serial Ports: Two asynchronous serial ports (compatible with 16550) with a maximum baud rate of 38.4Kbps, routed to the front panel RJ-45 connectors.
- USB: USB interface for connecting peripheral devices.
- PCI and PMC Sites: Dual independent 64-bit PCI buses and PMC sites, supporting 33/66MHz operation for added expansion capabilities.
- VME Interface: Universe II VME interface for seamless integration with VMEbus systems.
