FOXBORO H92904CC0500 Pressure Transmitter
Technical Specifications
- Measurement Accuracy: High-precision sensing technology ensures accurate pressure capture.
- Output Signals: Supports multiple output types, including 4-20mA and 0-10V, for compatibility with diverse control systems.
- Response Time: Rapid response to pressure changes, providing real-time data for timely control actions.
- Operating Temperature Range: -20°C to +60°C (or wider, depending on specific configurations).
- Protection Rating: High IP rating (e.g., IP65) for dust and water resistance, ensuring longevity in challenging environments.
- Construction: Compact, rugged design with durable materials to withstand vibration, shock, and corrosive substances.
- Mounting: DIN rail or panel mounting options for flexible installation.
FOXBORO FPS400-24 P0922YU Power Module
Technical Specifications
- Input Voltage:
- 120/240 V AC (47–63 Hz) or 125 V DC (range: 108–145 V DC).
- Output Voltage:
- 24 V DC ±0.2 V (nominal factory setting).
- Power Capacity:
- 400 W maximum output power.
- Efficiency:
- Up to 95% at 120 V AC input (typical).
- Operating Temperature:
- -30°C to +71°C (-22°F to +160°F).
FOXBORO FCP280 Field Control Processor
Technical Specifications
- Processor: ARM-based chipset with a 500 MHz operating frequency.
- Memory: 128 MB SDRAM + 128 MB flash memory.
- Function Block Processing Speed: Up to 16,000 function blocks per second.
- I/O Expansion:
- Supports up to 128 compact/standard 200-series Fieldbus Modules (FBMs) per module (32 per chain, with multi-chain combinations).
- Supports up to 64 100-series FBMs per PIO port in dual-波特 configurations.
- Mixed configurations of 100-series and 200-series FBMs (total of 128 modules, with ≤64 100-series FBMs per port).
- Fieldbus Speed: 2 Mbps (HDLC) or 268 Kbps.
FOXBORO FCP270 P0917YZ Field Control Processor
Technical Specifications
- Processor: High-speed CPU with 16 MB SDRAM and 32 MB flash memory for efficient data handling.
- Power Supply: 24 V DC (typical), with a maximum power consumption of 8.5 W per non-fault-tolerant module.
- Operating Temperature: 0°C to +60°C (32°F to +140°F), suitable for G3-class harsh environments.
- Dimensions: 14.7 cm (L) × 5.15 cm (W) × 11.4 cm (H); weight: 0.6 kg (1.5 kg shipping weight).
- I/O Support:
- Up to 32 Fieldbus Modules (FBMs) of the 200 series.
- Up to 128 FBMs of the 200 series via Fieldbus Expansion Module 100 (FEM100).
- Up to 64 FBMs of the 100 series.
FOXBORO FCP70 Field Control Processor
Technical Specifications
- Processor Type: High-performance microprocessor with integrated control algorithms.
- Communication Protocols: Supports standard industrial protocols such as Modbus, Ethernet/IP, and FOUNDATION Fieldbus for seamless integration with other automation equipment.
- I/O Capacity: Configurable input/output channels for connecting various sensors, actuators, and field devices.
- Power Supply: Operates on 24 V DC power supply with built-in protection against voltage fluctuations.
- Environmental Tolerance: Designed to withstand harsh industrial conditions, including temperature ranges from -20°C to +70°C and humidity levels up to 95% RH (non-condensing).
- Certifications: Complies with international standards such as CE, UL, and IEC for safety and electromagnetic compatibility.
FOXBORO FCM10E Fieldbus Communication Module
Technical Specifications
- Communication Protocols: Supports 10 Mbps Ethernet backbone and 2 Mbps fieldbus signals.
- Redundancy: Modules operate in pairs for fault tolerance; one pair supports up to 30 FBMs.
- Power Requirements: Input voltage range of 24 V DC (±5%, -10%); maximum power consumption of 7 W at 24 V DC.
- Environmental Tolerance:
- Operating Temperature: -20°C to +70°C (-4°F to +158°F).
- Storage Temperature: -40°C to +70°C (-40°F to +158°F).
- Humidity: 5%–95% RH (non-condensing).
- Altitude: -300 to +3,000 m (-1,000 to +10,000 ft) for operation; -300 to +12,000 m (-1,000 to +40,000 ft) for storage.
FOXBORO FBMSVH Electro-Hydraulic Servo Control Module
Technical Specifications
- Dimensions: 100 × 200 × 300 mm
- Weight: 1 kg
- Output Range: ±27 mA (for servo control applications)
- Input/Output Channels: Multiple channels for connecting sensors, actuators, and feedback devices (e.g., LVDTs).
- Power Requirements: 24 V DC (±5% tolerance) with explicit voltage and current specifications for stable operation.
- Communication Protocols: Supports industry-standard protocols such as Modbus and Foundation Fieldbus for seamless integration with other automation equipment.
- Environmental Tolerance: Designed to operate in harsh industrial environments with resistance to vibration, temperature fluctuations, and electromagnetic interference.
FOXBORO FBM242 Discrete Output Interface Module
Technical Specifications
- Output Channels: 16 discrete output channels, each rated for up to 2 A at 60 V DC.
- Supported Voltages:
- DC: 15–60 V
- AC: 120 V AC / 125 V DC or 240 V AC (via terminal assemblies).
- Isolation: Each output channel is electrically isolated from others and from ground, with group isolation when external excitation is used.
- Power Supply: External 24 V DC (±5%, -10% tolerance).
- Power Consumption: ≤3 W at 24 V DC (maximum).
- Environmental Tolerance:
- Operating Temperature: -20°C to +70°C (-4°F to +158°F).
- Humidity: 5%–95% RH (non-condensing).
- Pollution Level: G3 (harsh industrial environments per ISA S71.04).
FOXBORO FBM237 Channel Isolated Output Interface Module
Technical Specifications
- Output Channels: 8 isolated analog output channels (0–20 mA DC, configurable to 4–20 mA).
- Isolation: Each channel is electrically isolated to prevent cross-talk and ground loop interference.
- Output Range: 0–20.4 mA DC (resolution: 13-bit).
- Load Capacity: Maximum 750 Ω per channel.
- Power Supply: 24 V DC ±5%, -10% (redundant power input supported).
- Power Consption: ≤7 W (maximum).
- Environmental Tolerance:
- Operating Temperature: -20°C to +70°C (-4°F to +158°F).
- Storage Temperature: -40°C to +85°C (-40°F to +185°F).
- Humidity: 5%–95% RH (non-condensing).
- Altitude: -300 to +3,000 m (-1,000 to +10,000 ft).
- Pollution Level: G3 (harsh industrial environments per ISA S71.04).
FOXBORO FBM219 Digital Input/Output Module
Technical Specifications
- Input/Output Channels:
- Typically configured with multiple digital input channels (e.g., 8 or 16 channels) for discrete signal monitoring (e.g., switch status, alarm triggers).
- Some variants support digital output channels for controlling actuators or indicators.
- Signal Types:
- Accepts dry contact signals (e.g., relay outputs) or voltage signals (e.g., 24 V DC).
- Communication Protocols:
- Integrates with the I/A Series system via redundant 2 Mbps fieldbus networks.
- Supports standard industrial protocols like Modbus TCP/RTU for compatibility with third-party devices.
- Power Requirements:
- Operates on 24 V DC ±5% (some variants support 26–42 V DC).
- Power consumption: ≤14 W under normal operating conditions.
FOXBORO FBM217 P0914TR Discrete Input Interface Module
Technical Specifications
- Input Channels: 32 isolated channels, each accepting 2-wire DC voltage inputs.
- Input Voltage Range: Supports signals below 60 V AC, 120 V AC/125 V DC, or 240 V AC via associated terminal assemblies (TA).
- Current Consumption: 2.2 mA (typical) at 30 V DC input.
- Communication Protocol: Connects to redundant 2 Mbps module fieldbuses, enabling communication with associated Field Control Modules (FCM) or Field Control Processors (FCP).
- Power Requirements: 24 V DC ±5%, -10%; consumes 3 W at 24 V DC.
- Physical Dimensions: Approximately 10.2 cm (height) × 11.4 cm (width, including mounting ears) × 4.5 cm (depth) × 10.4 cm.
- Environmental Tolerance: Operates reliably in industrial settings with standard temperature and humidity ranges.
- Certifications: Complies with industrial safety and reliability standards.
FOXBORO FBM216 Industrial Control Module
Technical Specifications
- Input/Output Channels:
- Supports up to 8 isolated channels (configurable for analog or digital signals).
- Signal types: 4–20 mA, 0–10 V, thermocouple inputs (e.g., K, J, T types), and HART digital signals.
- Communication Protocols:
- Ethernet/IP for high-speed data transfer (10/100 Mbps).
- HART protocol for bidirectional communication with smart field devices.
- Modbus RTU/TCP for compatibility with legacy systems.
- Accuracy:
- Analog signal accuracy: ±0.075% full-scale.
- Resolution: 15-bit for precise signal detection.
