Technical Specifications

• Input/Output (I/O) Configuration:
  • Digital Inputs (DI): 8 channels (24 V DC, sinking type; input current: 5 mA max per channel)
  • Digital Outputs (DO): 4 channels (24 V DC, sourcing type; output current: 0.5 A max per channel)
  • Analog Inputs (AI): 2 channels (4-20 mA DC; resolution: 12 bits; input impedance: 250 Ω)
  • Analog Outputs (AO): 2 channels (4-20 mA DC; resolution: 12 bits; load impedance: 0-500 Ω)
• Signal Isolation:
  • Channel Isolation: 2500 V DC between I/O channels and ground (per IEC 61131-2)
  • EMC Immunity: Complies with IEC 61000-6-2 (industrial environment) – surge: ±2 kV (line-line), ±4 kV (line-ground); ESD: ±15 kV (contact), ±8 kV (air)
• Power Supply:
  • Input Voltage: 24 V DC (19.2 V DC – 30 V DC tolerance)
  • Power Consumption: 3 W typical (5 W max at full load)
  • Current Draw: 125 mA typical (208 mA max) at 24 V DC
• Environmental Parameters:
  • Operating Temperature Range: -25°C to +70°C
  • Storage Temperature Range: -40°C to +85°C
  • Humidity Tolerance: 5% – 95% (non-condensing, up to 40°C)
  • Altitude: ≤ 2000 m (derate 1% per 100 m above 1000 m)

• Processor Type: High-speed processor for rapid data handling and real-time control.
• Input/Output (I/O) Points: 24 (expandable) to accommodate diverse industrial requirements.
• Input Voltage: 24 VDC ±20%, ensuring compatibility with standard industrial power supplies.
• Input Current: Maximum 5 mA for digital inputs and 0.5 A for analog inputs, supporting mixed signal types.
• Output Frequency: Up to 100 Hz for precise motor or process control.
• Processing Speed: 550 μs response time for fast, reliable command execution.
• Operating Temperature: -20°C to 60°C, suitable for harsh industrial environments.

• Technical Specifications:
  • Electrical Parameters: Power supply is 24V DC; Input signals include analog (voltage, current) and digital; It has 51 I/O points, including 32 digital inputs and 8 analog inputs; The transmission rate of the Profibus DP interface is 960 kbps, and the node address ranges from 0 to 127.
  • Physical Characteristics: Size is 105mm x 230mm x 170mm; Weight is 1.9kg; Installation method adopts DIN rail installation.
  • Environmental Parameters: Operating temperature is -20°C to +55°C; Storage temperature is -40°C to +85°C; Relative humidity is 5% to 95% (non-condensing); Altitude is up to 1000 meters; Vibration resistance is 5.9m/s² (10 to 58Hz); Shock resistance is 30m/s² (3ms).
  • Communication Interface: Equipped with Ethernet, CANopen, Profibus DP and other interfaces.

• Technical Specifications:
  • Electrical Parameters: Input voltage is 220VAC; Output voltage range is 0-480VAC; Rated power is 48kW; Isolation voltage is greater than 2500V AC.
  • Physical Characteristics: Size is 500mm x 300mm x 200mm; Weight is 20kg; Protection level is IP20.
  • Environmental Parameters: Operating temperature is -20℃ to +55℃; Storage temperature is -25 to 70℃; Humidity is 5 to 95% (non-condensing); Altitude is up to 1000m above sea level.
  • Control Mode: PWM (Pulse Width Modulation) control mode is adopted.
  • Response Time: Less than 1ms.

Technical Specifications:

• The SPASI23 is an Analog Input Module that can interface with various types of analog sensors.
• It supports standard analog signals such as 4-20 mA or voltage inputs.
• The module typically provides isolation to protect against electrical noise and interference.
• High accuracy and resolution ensure reliable measurement results.

• System Compatibility: Part of the ABB Symphony Plus (S+) control system
• Input/Output Capacity: Supports multiple I/O channels depending on configuration
• Communication Protocols: Integrated support for Ethernet-based communication, including OPC, Modbus TCP, and IEC 61850
• Power Supply: Operates on standard 24 V DC supply
• Operating Temperature: 0°C to +55°C
• Storage Temperature: -20°C to +80°C
• Humidity Range: 5% to 95% relative humidity, non-condensing
• Dimensions: Designed for standard rack or chassis mounting (exact dimensions vary based on chassis type)
• Certifications: CE, UL, and other relevant industrial standards
