Technical Specifications

• Brand: ABB
• Model: PM866AK01
• Part Number: 1SBH780000R0000
• Type: Industrial PLC Controller
• Product Origin: Switzerland
• Processor: 32-bit ARM Cortex-A9; some versions adopt MPC866 processor
• Clock Speed: 100 MHz; some versions are 133 MHz
• Memory: Up to 128 MB; some versions have 64 MB memory, with 51.389 MB available for application programs and 4 MB flash PROM for firmware storage
• Interfaces: Two RJ45 Ethernet ports (CN1, CN2), two RJ45 serial ports (COM3, COM4); COM3 is an RS-232C port with modem control signals, and COM4 is isolated; it also has Ethernet, PROFINET, Modbus, CANopen, and DeviceNet interfaces
• I/O Points: Up to 4096
• Power Supply: 24V DC (19.2-30V DC); power consumption at +24V is typically 210mA and maximum 360mA; power dissipation is 5.1W (maximum 8.6W); built-in backup lithium battery with a voltage of 3.6V
• Dimensions: 120mm x 120mm x 45mm
• Weight: 0.6kg
• Certifications: CE, UL, CSA
• Performance Parameters: 1000 Boolean operations take 0.09 milliseconds; maximum red switching time is 10 milliseconds; each controller can have 32 application programs, 64 programs per application program, 128 charts per application program, 32 tasks per controller, 32 different cycle times, and the cycle time per application program can be as low as 1 millisecond

Technical Specifications

• Brand: ABB
• Model: PM866K01 3BSE050198R1
• Product Origin: Switzerland
• Product Positioning: Member of the ABB AC 800M series controllers
• Processor: Dual-core ARM Cortex-A9, main frequency 800MHz
• Memory: 4GB eMMC storage, 2GB RAM
• Working Voltage: AC 120V, AC 230V
• Output Frequency: 8-channel relay contact output
• Interfaces: 2 Ethernet ports, 2 serial ports, 1 PROFIBUS DP interface, high-speed USB 2.0 interface
• Sampling Rate: Up to 500kHz
• Working Temperature: -20℃ ~ +60℃
• Storage Temperature: -40℃ ~ +85℃
• Humidity: 5% to 95% non-condensing
• Vibration: 5Hz to 150Hz, 1mm amplitude
• Shock: 15g, 11ms half-sine
• Overall Dimensions: 239mm × 80mm × 35mm
• Weight: 0.72kg

• The PM891K01 operates as a high-performance CPU within the AC 800M system, suitable for handling extensive control logic and data processing tasks.
• Supports multiple communication protocols including Ethernet/IP, Profibus-DP, and Modbus TCP, facilitating connectivity with other devices and systems within an industrial network.
• Equipped with sufficient memory to store large-scale applications, user programs, and historical data, ensuring efficient operation without frequent memory constraints.
• Capable of operating under industrial environmental conditions, featuring resistance to vibration, temperature fluctuations, and electrical noise.

• The PM902F is a high-performance controller capable of executing complex control algorithms and handling large volumes of I/O data with deterministic response times.
• It features a robust processor architecture optimized for real-time control tasks, ensuring reliable and consistent performance in mission-critical environments.
• Supports extensive memory capacity for storing user programs, configuration data, and historical information, enabling advanced control strategies and data logging.
• Provides multiple communication interfaces, including Ethernet ports, for seamless integration with engineering workstations, operator interfaces, remote I/O, and other controllers within the Symphony Plus network.
• Operates under industrial-grade environmental specifications, with resistance to temperature variations, electrical noise, and mechanical vibration.

• Display: 5.4-inch TFT LCD with touchscreen functionality.
• Resolution: Designed for clear visualization of process data and graphical interfaces.
• Communication: Supports Profibus protocol for seamless integration with PLCs and other industrial devices.
• Interfaces:
  • RS-232 serial port for local configuration and debugging.
  • Bluetooth connectivity for wireless data exchange (in some configurations).
  • Additional communication cards (e.g., Ethernet) can be added via expansion slots.

• Technical Specifications:
  • Processor: PSR-2 industrial-grade processor with a main frequency of 1GHz.
  • Memory Configuration: 512MB RAM + 8MB Flash (supports SD card expansion up to 128GB).
  • Communication Interface: 2×RS-232, 1×RS-485, 1×Ethernet (10/100Mbps).
  • Supported Protocols: PROFIBUS DP, Modbus RTU, EtherNet/IP, OPC UA.
  • Power Supply Voltage: 24V DC (±20% wide-range compatibility).
  • Operating Temperature: -40°C to +70°C (no condensation).
  • Protection Level: IP20 (must be installed in a control cabinet).
  • Installation Method: 35mm DIN rail mounting.
  • Overall Dimensions: 120mm×80mm×45mm.
  • Weight: Approximately 0.5kg.
  • Certification Standards: CE, UL, IEC 61010-1.
  • Vibration Resistance: 10G acceleration (10-2000Hz).
