Product Overview

• Processor:
  • Motorola 68020 (some versions may feature different processors, such as the PowerPC e500 in advanced models).
  • Advanced models may include the Freescale MPC8540 system-on-chip with a PowerPC e500 core, running at speeds up to 833 MHz.
• Memory:
  • 2MB RAM (expandable in some models).
  • 1MB Flash memory for firmware storage.
  • Advanced models support up to 512MB DDR333 ECC memory for enhanced data processing accuracy.

• Processor: Supports multiple processor options, including MPC7410, MPC750, or MPC755-grade microprocessors from Motorola or Freescale, featuring high performance and low power consumption.
• Memory:
  • Standard configuration includes 128 MB SDRAM, expandable up to 1 GB via memory mezzanine cards.
  • Typically equipped with a 2 GB IDE hard disk or solid-state drive (SSD).
• I/O Interfaces:
  • 2 x RS-232C serial ports.
  • 1 x 10/100BaseTX Ethernet interface (some models offer dual Gigabit Ethernet ports).
  • 1 x PCI slot and 1 x CompactFlash slot for extensive peripheral expansion.

• Processor: Equipped with a high-performance 1GHz MPC7457 PowerPC processor, featuring 32KB/32KB L1 cache, 512KB L2 cache, and 2MB L3 cache for enhanced processing capabilities.
• Memory: Supports up to 512MB PC133 ECC SDRAM onboard, expandable to 1GB via memory mezzanine cards. Also includes 32KB NVRAM (4KB user-accessible) with battery backup for data retention.
• I/O Interfaces:
  • Ethernet: One Gigabit Ethernet port and one additional 10/100BaseTX Ethernet port for high-speed network connectivity.
  • Serial Ports: Two asynchronous serial ports (compatible with 16550) with a maximum baud rate of 38.4Kbps, routed to the front panel RJ-45 connectors.
  • USB: USB interface for connecting peripheral devices.
  • PCI and PMC Sites: Dual independent 64-bit PCI buses and PMC sites, supporting 33/66MHz operation for added expansion capabilities.
  • VME Interface: Universe II VME interface for seamless integration with VMEbus systems.

• Processor: Equipped with an NXP MPC7457 PowerPC processor running at up to 1.267 GHz, featuring a 128-bit AltiVec coprocessor for enhanced parallel processing capabilities.
• Memory: Supports up to 2 GB of ECC-protected DDR DRAM for reliable data storage and processing, along with up to 128 MB of flash memory for firmware and application storage.
• VMEbus Interface: Utilizes the Tundra Tsi148 VMEBridge ASIC, providing 2eSST protocol support for a VMEbus transfer rate of up to 320 MB/s, ensuring high-speed data communication within the VMEbus system.
• I/O Interfaces:
  • Ethernet: Dual Gigabit Ethernet ports for high-speed network connectivity.
  • Serial Ports: One asynchronous serial port for communication with peripheral devices.
  • PMC Sites: Two 64-bit PMC (PCI Mezzanine Card) sites, supporting PCI bus speeds from 33 MHz to 100 MHz, allowing for expansion with industry-standard modules.
  • Other Interfaces: Includes a reset and abort switch, and LED indicators for board status monitoring.

• Processor: Equipped with an NXP MPC7457 PowerPC processor, running at up to 1.267 GHz, featuring a 128-bit AltiVec coprocessor for enhanced parallel processing capabilities.
• Memory: Supports up to 1 GB of ECC-protected DDR DRAM for reliable data storage and processing, along with up to 128 MB of flash memory for firmware and application storage.
• VMEbus Interface: Utilizes the Tundra Tsi148 VMEBridge ASIC, providing 2eSST protocol support for a VMEbus transfer rate of up to 320 MB/s, ensuring high-speed data communication within the VMEbus system.
• I/O Interfaces:
  • Ethernet: Dual Gigabit Ethernet ports for high-speed network connectivity.
  • Serial Ports: One asynchronous serial port for communication with peripheral devices.
  • PMC Sites: Two 64-bit PMC (PCI Mezzanine Card) sites, supporting PCI bus speeds from 33 MHz to 66 MHz, allowing for expansion with industry-standard modules.
  • Other Interfaces: Includes a reset and abort switch, and LED indicators for board status monitoring.
