HIMA F3330 984333002 Safety Control Module

• Power Supply: 24V DC input with redundant power modules (5V DC output for internal components).
• Operating Conditions:
  • Temperature: -20°C to 60°C (operating), -40°C to 85°C (storage).
  • Humidity: Up to 90% RH (non-condensing).
• Certifications: CUL Class I Division 2, CE, and compliance with IEC 61508 (SIL 3).

Functional Characteristics

• Fault Tolerance: The QMR architecture ensures continuous operation even if one or more components fail. A hardware comparator monitors external accesses, triggering a safe state if discrepancies arise.
• High Availability: Dual-port RAM (DPR) enables real-time data exchange between CU modules, eliminating downtime during fault recovery.
• Diagnostics: Built-in self-diagnostics monitor module health, reporting faults via LED indicators and communication ports.
• Programming Flexibility: Supports custom logic configuration using tools like SILworX, allowing adaptation to diverse safety requirements.
• Multi-Protocol Support: Acts as a protocol converter, data concentrator, and gateway, facilitating seamless integration with PLCs, motion controllers, and other devices.
• Digital Output Capabilities: Features 8 channels with 24V DC output (4.7A per channel) for controlling actuators, valves, and alarms.

Application Scenarios

• Emergency Shutdown Systems (ESD): Triggers safety valves and isolates equipment during hazardous events in chemical, petrochemical, and oil/gas plants.
• Burner Management Systems (BMS): Monitors flame detectors and controls fuel valves in boilers and furnaces.
• Mechanical Safety: Manages safety interlocks in presses, injection molding machines, and robotic assembly lines.
• Power Generation: Ensures safe operation of turbines and generators by monitoring critical parameters.
• Railway Signaling: Provides fail-safe control for signaling systems, enhancing passenger and infrastructure safety.
• Pharmaceutical Manufacturing: Regulates sterile processes and prevents contamination through precise control of valves and sensors.
