GE IS200WEORG1A Wind Energy Output Regulator (WEOR) PCB Module

Product Overview

The IS200WEORG1A is a dedicated Wind Energy Output Regulator (WEOR) printed circuit board module designed by General Electric for Mark VIe Speedtronic wind turbine control systems. It serves as a core component for managing and regulating the electrical output of wind turbines, enabling seamless integration with grid infrastructure and ensuring optimal energy conversion efficiency. The module processes real-time data from turbine sensors, generators, and grid interfaces to adjust power output, maintain grid stability, and support compliance with grid codes. It integrates with Mark VIe controllers and ToolboxST software for configuration, monitoring, and diagnostics, providing reliable performance in harsh wind energy environments. The board features a compact form factor with standard PCB coating, facilitating easy installation in turbine control cabinets while ensuring protection against environmental factors.

Category: GE

Description

Technical Specifications

Parameter	Details
Model Number	IS200WEORG1A
Manufacturer	General Electric (GE Energy)
Module Type	Wind Energy Output Regulator (WEOR) PCB Module
Series Compatibility	Mark VIe Speedtronic Wind Turbine Control Systems
PCB Coating	Normal Conformal Coating
Form Factor	Standard Single-Slot PCB (VME Bus Compatible)
Dimensions (L×W×H)	28.0 cm × 18.0 cm × 3.5 cm
Weight	0.38 kg
Power Supply	+5 VDC, +12 VDC, -12 VDC (system power)
Operating Temperature	-40°C to +70°C
Storage Temperature	-40°C to +85°C
Isolation	Channel-to-channel and channel-to-ground isolation (500 VAC, 1 minute)
Communication Interface	VME Bus, Ethernet (Modbus TCP/IP, IEC 61850)
Certifications	CE, UL 508, IEC 61508 SIL 2
Functional Revision	1A
Documentation	GE Mark VIe Wind Turbine Control System Manual (GEH-6700W)

Function Features

Wind Turbine Output Regulation: Manages real-time power output adjustment based on wind speed, generator load, and grid demand signals.
Grid Code Compliance: Supports frequency and voltage regulation, reactive power control, and low-voltage ride-through (LVRT) capabilities to meet global grid standards.
Mark VIe Integration: Seamlessly interfaces with Mark VIe controllers, I/O modules, and communication networks for unified system operation.
Real-Time Data Processing: High-speed signal processing for turbine sensor inputs, generator parameters, and grid interface data to ensure rapid response to dynamic wind conditions.
ToolboxST Compatibility: Configurable via GE ToolboxST software for parameter setting, alarm configuration, and diagnostic monitoring.
Conformal Coating: Normal conformal coating protects against moisture, dust, and chemical contaminants in offshore and onshore wind environments.
Modular Design: Single-slot form factor and edge connectors facilitate quick replacement and maintenance, minimizing downtime during repairs.
Redundancy Support: Operates in simplex and dual redundant configurations to enhance system reliability in critical wind energy applications.

Application Scenarios

Onshore and Offshore Wind Farms: Primary use in Mark VIe-based wind turbine control systems for power output regulation and grid integration.
Grid-Connected Wind Turbines: Ensures compliance with grid codes for frequency control, voltage stability, and reactive power management.
Wind Energy Conversion Systems: Critical for optimizing energy conversion from wind to electricity in doubly-fed induction generator (DFIG) and permanent magnet generator (PMG) systems.
Renewable Energy Integration: Facilitates seamless integration of wind energy into smart grids and microgrids, supporting distributed energy resource (DER) management.
Wind Turbine Retrofits: Direct replacement for legacy output regulation modules in Mark VIe system upgrades, enhancing performance and grid compatibility.
Remote Monitoring and Diagnostics: Supports data transmission to SCADA systems for remote performance monitoring and predictive maintenance in wind farms.

Compatibility and Integration

Mark VIe Systems: Fully compatible with Mark VIe controllers, I/O packs, and communication modules, enabling data exchange in wind turbine control networks.
Software Support: Configurable via GE ToolboxST software, providing tools for power curve calibration, grid code compliance setup, and output regulation tuning.
Grid Interface Compatibility: Interfaces with grid protection relays, energy management systems (EMS), and SCADA systems for enhanced grid integration.
Generator Compatibility: Supports doubly-fed induction generators (DFIG) and permanent magnet generators (PMG) for diverse wind turbine configurations.
Documentation: Detailed guidelines available in GE Mark VIe Wind Turbine Control System Manual (GEH-6700W) and WEOR Module Application Guide.
