GE IC752SPL013

  • Product Introduction: The IC752SPL013 is a dedicated operator interface panel for GE EX2100 excitation control systems, serving as the primary HMI for generator excitation monitoring and control. It integrates a 16‑character alphanumeric display, 12‑button keypad, and multiple communication ports to enable parameter configuration, real‑time status visualization, alarm management, and manual control functions in power generation applications. It is engineered for harsh industrial environments, with an IP54/NEMA 4X enclosure rating and wide temperature tolerance.
  • Manufacturer: GE Energy (General Electric Energy, now part of GE Vernova)
  • Display: 16‑character alphanumeric backlit LCD; LED backlight for visibility in low‑light conditions
Category:
Description
  • Keypad: 12 tactile buttons (function keys, numeric keys, and navigation keys) for input and control
  • Communication Interfaces: RS‑232 (for local configuration), RS‑485 (for daisy‑chain connections), 10/100 Mbps Ethernet (for remote monitoring)
  • Power Requirements: 24 VDC, 20 W max power consumption
  • Physical Dimensions: 188 mm × 164 mm × 40 mm (7.4 in × 6.5 in × 1.6 in)
  • Weight: 0.54 kg (1.19 lbs)
  • Operating Temperature: -20°C to 60°C (-4°F to 140°F)
  • Storage Temperature: -40°C to 85°C (-40°F to 185°F)
  • Relative Humidity: 5% to 95% (non‑condensing)
  • Enclosure Rating: IP54/NEMA 4X (dust and water resistant)
  • Certifications: CE, UL 61010‑1, CSA C22.2 No. 61010‑1, EU RoHS compliant
  • Integrated HMI: 16‑character backlit LCD and 12‑button keypad enable local parameter setting, status monitoring, and manual control
  • Multi‑Protocol Communication: RS‑232, RS‑485, and Ethernet ports support local/remote configuration and data exchange
  • Backlit Display: LED backlight ensures readability in dark industrial environments
  • IP54/NEMA 4X Enclosure: Resists dust, water, and corrosion in harsh power generation settings
  • Real‑Time Status Visualization: Displays generator voltage, current, field excitation, and alarm conditions
  • Manual Control Override: Allows manual field adjustment during system testing or emergencies
  • Alarm Management: Visual and audible indicators for fault detection and troubleshooting
  • Modular Design: Snap‑on mounting for easy installation, removal, and maintenance
  • Firmware Updates: Flash memory supports in‑field upgrades via communication ports
  • Power Generation: Interfaces with EX2100 systems in fossil fuel, nuclear, hydroelectric, and wind power plants
  • Industrial Power Systems: Controls generator excitation in distributed generation, microgrids, and co‑generation facilities
  • Transmission & Distribution: Monitors and adjusts excitation in grid‑connected generators and synchronous condensers
  • Marine & Offshore Applications: Operates reliably in saltwater environments for shipboard power systems
  • Emergency Backup Power: Controls standby generators in hospitals, data centers, and critical infrastructure
  • Commissioning & Maintenance: Enables parameter tuning, system testing, and troubleshooting during installation and routine checks
  • Remote Monitoring: Ethernet connectivity allows integration with SCADA/DCS for centralized power plant control
