GE IC698CHS117C
GE IC698CHS117C

GE IC697PWR711K

  • Product Introduction: The IC697PWR711K is a 100W rack-mounted switching power supply module designed for GE Series 90-70 PLC systems, installed in the leftmost slot of standard IC697 or VME Integrator racks via a 48-pin backplane connector. It delivers +5 VDC, +12 VDC, and -12 VDC regulated outputs to power PLC CPUs, I/O modules, and peripherals, with support for 120/240 VAC or 125 VDC input, power factor correction, and ride-through capability for transient power loss. It can power one or two racks when total load stays within 100W rating, connected via a prewired inter-rack cable.
  • Manufacturer: GE Fanuc (General Electric Fanuc Intelligent Platforms, now part of Emerson Automation)
  • Module Type: 100W switching power supply for Series 90-70 PLC backplanes
Category:
Description
  • Input Voltage Range: 90-132 VAC / 180-264 VAC (47-63 Hz); 100-150 VDC (125 VDC nominal)
  • Input Power: 160W maximum at full load
  • Input Peak Inrush: 55 A typical, 77 A maximum (half-cycle peak)
  • Output Power: 100W total (all outputs combined)
  • Output Voltages & Currents: +5 VDC (4.90-5.25 V, 5.07 V nominal), 20 A max; +12 VDC (11.75-12.6 V), 2 A max; -12 VDC (-12.6 to -11.75 V), 1 A max
  • Overcurrent Limits: +5 VDC: 26 A max; +12 VDC: 4 A max; -12 VDC: 2 A max
  • Overvoltage Limit: +5 VDC: 5.7-6.7 V
  • Holdup Time: ≥21 ms (at full load, loss of AC input)
  • Power Factor Correction: Active PFC for AC operation improves efficiency and reduces harmonic distortion
  • Backplane Connection: 48-pin backplane connector (leftmost slot)
  • LED Indicators: Power OK, +5 VDC OK, +12 VDC OK, -12 VDC OK, Fault
  • Physical Dimensions: 6.3 cm × 29.2 cm × 22.2 cm (2.5 in × 11.5 in × 8.8 in)
  • Weight: 1.36 kg (3 lbs)
  • Operating Temperature: 0°C to 55°C
  • Storage Temperature: -40°C to 85°C
  • Relative Humidity: 5% to 95% (non-condensing)
  • Certifications: CE, UL 61010-1, CSA C22.2 No. 61010-1, EU RoHS compliant
  • Regulated Multi-Voltage Outputs: Provides stable +5 VDC, +12 VDC, and -12 VDC to support diverse PLC and I/O loads
  • Dual Input Compatibility: Works with 120/240 VAC or 125 VDC input for global deployment and mixed power systems
  • Dual-Rack Operation: Powers two racks via prewired cable to reduce hardware costs
  • Power Factor Correction: Minimizes input harmonic distortion and improves energy efficiency for AC operation
  • Transient Ride-Through: ≥21 ms holdup time maintains output during short input power interruptions
  • Comprehensive Protection: Electronic short-circuit, overcurrent, and overvoltage protection prevents damage to modules and backplane
  • Hot-Swappable Design: Slide-in rack mount allows replacement without full system shutdown (with proper safety procedures)
  • Process Automation: Powers Series 90-70 PLC systems in oil/gas, chemical, water/wastewater, and power generation plants
  • Manufacturing Control: Supplies power to PLC CPUs, I/O, and HMIs in automotive, packaging, and material handling lines
  • Dual-Rack Systems: Supports two interconnected racks for expanded I/O in medium to large control systems
  • Harsh Industrial Environments: Stable performance from 0°C to 55°C with wide input voltage range and ride-through capability
  • Legacy System Upgrades: Compatible with existing Series 90-70 racks during plant modernization projects
  • Redundant Power Configurations: Can be paired with backup supplies to enhance system availability in critical applications
