GE IC693PWR330

Product Overview

The IC693PWR330 is a single‑slot, high‑capacity power supply module from GE Fanuc (Emerson Automation) for Series 90‑30 PLC systems, designed to deliver 30W total output with flexible power distribution—all 30W can be allocated to the +5VDC output for high‑current logic loads, while also providing +24VDC Relay (for output modules) and isolated +24VDC (for field devices). It accepts 85–264 VAC (50/60 Hz) or 100–300 VDC input, with 1500VAC isolation between outputs and input, over‑current/over‑voltage protection, and 4A peak inrush current tolerance (250 ms max). The module fits the leftmost slot of Series 90‑30 baseplates, delivering 6A max +5VDC, 0.625A max +24VDC Relay, and 0.833A max isolated +24VDC, with LED indicators for power and output status, ensuring stable backplane power for large CPU/module configurations in industrial automation.

Category: GE

Description

Technical Specifications

Parameter	Details
Manufacturer	GE Fanuc (Emerson Automation)
Model Number	IC693PWR330
Platform Compatibility	Series 90‑30 PLC Systems
Module Type	Single‑slot high‑capacity power supply (AC/DC input, 3 outputs), leftmost slot only
Input Voltage Range	85–264 VAC (50/60 Hz), 100–300 VDC
Input Power	100VA (VAC input), 50W (VDC input)
Total Output Power	30W (all allocable to +5VDC)
Output Voltages & Power	+5VDC: 30W max (6A max); +24VDC Relay: 15W max (0.625A max); Isolated +24VDC: 20W max (0.833A max) (sum ≤30W)
Isolation Ratings	1500VAC output‑to‑input (1 minute)
Inrush Current	4A peak, 250 ms max
Protection Features	Over‑current limiting, over‑voltage clamping, reverse polarity protection
Indicators	Power OK (green), +5VDC OK (green), +24VDC OK (green)
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Humidity	5%–95% non‑condensing
Dimensions	127 mm × 76.2 mm × 152.4 mm (5.0 in × 3.0 in × 6.0 in)
Weight	0.6 kg (1 lbs 4 oz)
Mounting	DIN rail via Series 90‑30 baseplate, leftmost slot only
Protection Class	IP20
Battery Backup	None (external IC693ACC301 RAM battery required)

Functional Features

30W Allocable Power: All 30W can be used for +5VDC to support high‑current CPU/communication modules.
Triple Independent Outputs: +5VDC (logic), +24VDC Relay (output modules), isolated +24VDC (field devices).
Universal Input: 85–264 VAC / 100–300 VDC operation for global industrial use.
1500VAC Isolation: Blocks noise and transients between outputs and input for reliable operation.
Over‑Current/Over‑Voltage Protection: 4A peak inrush tolerance (250 ms) and voltage clamping prevent damage.
LED Status Indicators: Power OK, +5VDC OK, +24VDC OK for quick diagnostics.
Single‑Slot Design: Fits leftmost slot of Series 90‑30 baseplates without extra space.
Industrial Durability: -40°C to 85°C storage, 0°C to 60°C operating temps, 5%–95% non‑condensing humidity.
6‑Terminal Wiring: Secure AC/DC input terminals for field connections.

Application Scenarios

Large Series 90‑30 Racks: Powers high‑current CPUs (e.g., IC693CPU363), communication modules, and dense I/O configurations.
High‑Logic Load Systems: Supports programming stations, HMIs, and data loggers requiring 6A +5VDC.
Process Automation: Drives pumps, valves, and sensors in chemical, water treatment, and food processing plants.
Machine Control: Supplies logic and output power for conveyors, sorters, and packaging machines.
Retrofit Projects: Replaces standard supplies (IC693PWR321) in Series 90‑30 upgrades for higher +5VDC capacity.
Global Industrial Sites: Operates on 85–264 VAC/100–300 VDC grids in oil refineries, mining, and manufacturing.

Ordering & Compatibility

Standard model: IC693PWR330. Compatible with all Series 90‑30 baseplates (leftmost slot only), CPUs, and I/O modules. Use with IC693ACC301 RAM battery for data retention; no internal battery. Pair with pre‑wired cables and terminal blocks for field connections.
