GE IC693PWR322F

Product Overview

The IC693PWR322F is a single‑slot DC‑input power supply module from GE Fanuc (Emerson Automation) for Series 90‑30 PLC systems, delivering +5VDC (logic), +24VDC Relay (output modules), and +24VDC Isolated (field devices) with 30W total output and 50W input power. It operates from 18–56VDC (21VDC minimum start), providing 1500VAC isolation between outputs and input, with over‑current/over‑voltage protection and LED status indicators. It fits standard Series 90‑30 baseplates, supporting CPU logic, I/O modules, and field loads in industrial automation with no internal battery backup.
Category:
Description

Technical Specifications

Parameter Details
Manufacturer GE Fanuc (Emerson Automation)
Model Number IC693PWR322F
Platform Compatibility Series 90‑30 PLC Systems
Module Type Single‑slot DC‑input power supply (3 outputs: +5VDC, +24VDC Relay, +24VDC Isolated)
Input Voltage Range 18–56VDC (nominal 24/48VDC); 21VDC minimum start
Input Power 50W (max full load)
Total Output Power 30W
Output Voltages & Power +5VDC (15W max, 3A max); +24VDC Relay (15W max, 0.625A max); +24VDC Isolated (20W max, 0.833A max)
Isolation Ratings 1500VAC (output‑to‑input, 1 minute)
Protection Features Over‑current limiting (4A peak for 100ms), over‑voltage clamping, reverse polarity protection
Indicators Power OK (green), +5VDC OK (green), +24VDC OK (green)
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5%–95% non‑condensing
Dimensions 127 mm × 76.2 mm × 152.4 mm (5.0 in × 3.0 in × 6.0 in)
Weight 0.6 kg (1 lbs 4 oz)
Mounting DIN rail via Series 90‑30 baseplate (power supply slot)
Protection Class IP20
Battery Backup None (external IC693ACC301 RAM battery required)

Functional Features

  • Triple Independent Outputs: +5VDC for logic, +24VDC Relay for outputs, +24VDC Isolated for field devices, with 1500VAC isolation.
  • Wide Input Range: 18–56VDC operation handles industrial voltage fluctuations.
  • 30W Total Output: 15W for +5VDC, 15W for +24VDC Relay, 20W for +24VDC Isolated (sum ≤30W).
  • Over‑Current/Over‑Voltage Protection: 4A peak surge tolerance (100ms) and voltage clamping prevent damage.
  • LED Status Indicators: Power OK, +5VDC OK, +24VDC OK for quick diagnostics.
  • No Internal Battery: Simplifies maintenance with external RAM backup option.
  • 1500VAC Isolation: Blocks noise between outputs and input for reliable system operation.
  • Single‑Slot Design: Fits any Series 90‑30 baseplate power slot without extra space.
  • Industrial Durability: -40°C to 85°C storage, 0°C to 60°C operating temps, 5%–95% non‑condensing humidity.

Application Scenarios

  • Series 90‑30 PLC Systems: Powers CPUs, I/O modules, and communication cards in manufacturing lines.
  • Process Automation: Supports pumps, valves, and sensors in chemical, water treatment, and food processing.
  • Machine Control: Drives motor starters, solenoids, and HMI panels with isolated 24VDC field power.
  • Material Handling: Supplies logic and output power for conveyors, sorters, and packaging machines.
  • Retrofit Projects: Replaces legacy Series 90‑30 power supplies with drop‑in compatibility.
  • DC‑Only Installations: Operates in remote sites, marine, and mining with 24/48VDC primary power.
  • Harsh Environment Use: Performs reliably in oil refineries, outdoor industrial sites, and temperature‑variable facilities.

Ordering & Compatibility

Standard model: IC693PWR322F. Compatible with all Series 90‑30 baseplates, CPUs (e.g., IC693CPU351‑HT/363), and I/O modules. Use with IC693ACC301 RAM battery for data retention; no internal battery. Install in dedicated power supply slot on Series 90‑30 baseplates.
