GE IC200ALG326 Analog Output Module

Product Introduction

The GE IC200ALG326 is an 8-channel analog current output module designed for industrial automation applications. It is part of the VersaMax I/O series, providing high-precision analog current outputs to control various industrial devices such as valves, dampers, and variable frequency drives (VFDs). This module ensures reliable and accurate control signals for precise process regulation.

Category:
Description

Technical Specifications

  • Number of Channels: 8 single-ended output channels
  • Output Range: Supports 4-20 mA and 0-20 mA current outputs
  • Resolution: 13-bit digital-to-analog conversion (DAC) for high-precision output
  • Accuracy: High linearity and long-term stability in output signals
  • Update Rate: Fast update rate of 15 milliseconds per channel for timely response
  • Voltage Range: 18-30 VDC power supply required
  • Backplane Current Consumption: 50 mA per channel at 5 V
  • Isolation: Maximum isolation voltage of 250 VAC continuous between channels
  • Protective Features: Built-in protection circuits to prevent short circuits and overload damage
  • LED Indicators: FLD PWR (Field Power) and OK (Module Status) LEDs for visual feedback
  • Configuration: Output range can be configured via jumpers for flexibility

Functional Features

  • High Precision: The 13-bit DAC resolution ensures accurate and stable current outputs, providing reliable control signals for industrial devices.
  • Fast Response: The 15-millisecond update rate enables real-time control, ensuring timely adjustments to process variables.
  • Flexible Output Ranges: Supports both 4-20 mA and 0-20 mA output ranges, making it compatible with a wide range of industrial devices.
  • Diagnostic Capabilities: The module includes diagnostic tools and LED indicators to simplify operation and maintenance, providing visual feedback on power and module status.
  • Protection Mechanisms: Built-in protection circuits safeguard the module against short circuits and overloads, enhancing system reliability.
  • Easy Configuration: The output range can be easily configured using jumpers, reducing setup time and complexity.
  • Compact Design: The module’s compact design saves space and facilitates easy installation in control cabinets.

Application Scenarios

  • Process Control: Used in chemical, pharmaceutical, and food processing plants to control valves, pumps, and other process variables such as temperature, pressure, and flow.
  • Machine Control: In CNC machines and processing centers, it controls machine feed rates, spindle speeds, and other parameters for precise manufacturing operations.
  • Building Automation: Utilized in smart building systems to control HVAC equipment, lighting, and other facilities, enhancing energy efficiency and occupant comfort.
  • Energy Management: Deployed in power generation and distribution systems to monitor and control energy consumption and distribution, ensuring grid reliability and efficiency.
  • Water and Wastewater Treatment: Used to control valves and pumps in water treatment plants, ensuring accurate dosing of chemicals and efficient water distribution.
  • Oil and Gas: Installed in remote and hazardous locations to monitor and control production processes, withstanding extreme temperatures and resistive to explosive atmospheres.
