GE IC200ALG260

• Isolation: 250 VAC continuous optical isolation, 1500 VAC for 1 minute.
• Filter Response Time: 5 ms.
• Update Rate: 0.4 ms per channel.
• Power Supply: Backplane powered, with a maximum current consumption of 5 mA at 130 VDC.
• Dimensions: 4.3 x 2.63 x 1.956 inches.
• Weight: Approximately 0.5 kg.
• Operating Temperature: -10°C to 55°C (no thermal derating).

Functional Characteristics:

• Flexibility: Supports both voltage and current input signals, allowing for easy configuration to match different sensor types.
• High Resolution: The 12-bit resolution ensures precise analog signal conversion, meeting the demands of precision control applications.
• Isolation: Provides strong electrical isolation between input channels and the logic ground, enhancing system reliability and safety.
• Diagnostics: Equipped with built-in diagnostic functions, including under-range and over-range detection, open circuit detection, and power failure diagnostics.
• LED Indicators: Features two LED indicators (INT PWR and OK) for visual indication of power status and module health.
• Configuration: The signal type (voltage/current) and polarity (unipolar/bipolar) can be easily configured via jumpers on the module top, eliminating the need for programming.
• Hot Swapping: Supports hot plugging, allowing for easy installation and replacement without powering down the system.

Application Scenarios:

• Industrial Automation: Used in manufacturing plants to monitor and control various process parameters, such as temperature, pressure, flow, and level, ensuring optimal process performance and efficiency.
• Power Generation: Employed in power plants for real-time monitoring of generator and transformer parameters, enabling early fault detection and preventive maintenance.
• Water Treatment: Utilized in water treatment facilities to monitor water quality parameters, such as pH, turbidity, and chlorine levels, ensuring compliance with regulatory standards.
• Building Automation: Integrated into building management systems for monitoring environmental parameters, such as temperature, humidity, and air quality, providing a comfortable and healthy indoor environment.
• Renewable Energy: Applied in solar and wind power systems to monitor and control the performance of inverters and other key components, maximizing energy production and system reliability.
