GE DS200ITXDG1ABA Dynamic Braking Buffer Board

Technical Specifications

Board Type: Dynamic braking buffer board
Input Voltage: 375 HP for constant torque applications (575 VAC), 300 HP for variable torque applications (380 VAC)
Connectors: Four-pin connector for interface with the IMCP (Interface Module Control Panel)
IGBT Compatibility: Designed to meet the switching frequency requirements of dynamic braking IGBTs
Output Regulation: Adjusts IGBT gate driver outputs to match the electrical characteristics of AT frame drivers

Category:
Description
  • Environmental Rating: IP20 protection against dust and debris
  • Operating Temperature: -30°C to +70°C
  • Certifications: Complies with IEC 61508 (SIL 2), EN 50121-3-2, and EN 61000-6-2 for industrial EMC compliance

Functional Characteristics

  • Voltage Transient Limitation: Absorbs and limits voltage spikes generated by IGBT switching, protecting the control system from damage.
  • Dynamic Braking Control: Facilitates rapid reduction of motor speed during emergency stops, preventing overspeed conditions.
  • Output Regulation: Ensures compatibility with both variable and constant torque applications by adjusting IGBT gate driver outputs.
  • Diagnostic Capabilities: Features LED indicators for monitoring board status and identifying potential issues.
  • Modular Design: Easy to install and replace, with clear labeling and standardized connectors for quick maintenance.

Application Scenarios

  • Power Generation: Used in gas and steam turbine control systems to regulate excitation currents and ensure stable power output.
  • Industrial Automation: Integrates with DCS/PLC systems in manufacturing plants to control motor drives, conveyors, and robotic systems.
  • Energy Management: Monitors and controls grid equipment in substations, including transformers and circuit breakers, via precise voltage and current feedback.
  • Process Control: Supports chemical, petrochemical, and metallurgical plants by managing reactor temperatures, pressure valves, and flow rates.
  • Marine Propulsion: Deployed in shipboard turbine drives to maintain thrust control in extreme temperatures and corrosive environments.

Key Advantages

  • High Reliability: Designed for continuous operation in harsh industrial environments, with an MTBF exceeding 2,200,000 hours.
  • Flexibility: Supports both variable and constant torque applications, making it suitable for a wide range of industrial processes.
  • Ease of Maintenance: Hot-swappable design and diagnostic LEDs simplify troubleshooting and minimize downtime.
  • Cost Efficiency: Cross-compatible with multiple GE drive models, reducing spare part inventory requirements.
