Bently Nevada 13677-01 Industrial Signal Conditioning Module

• Physical & Environmental Parameters
  • Housing material: High-strength industrial-grade plastic (impact-resistant and corrosion-proof)
  • Dimensions: 100 mm × 80 mm × 30 mm (length × width × height)
  • Mounting type: DIN rail mounting (standard for industrial control cabinets)
  • Operating temperature: -40 °C to +70 °C (adapts to extreme industrial climates)
  • Storage temperature: -55 °C to +85 °C (safe for long-term storage)
  • Relative humidity: 5%–95% non-condensing (resists moisture-related damage)
  • Ingress protection: IP20 (suitable for installation in control cabinets)
  • Certifications: CE, UL, CSA (meets global industrial safety and quality standards)
• Signal Processing & Communication
  • Filtering: Built-in low-pass filter with configurable cutoff frequency (1 Hz to 1 kHz)
  • Response time: ≤ 10 ms (ensures real-time signal processing)
  • Communication interface: RS485 (Modbus RTU protocol) for remote configuration and diagnostics
  • Self-test function: Integrated (automatically verifies module functionality and signal integrity)

Function Features

• High-Precision Signal ConditioningDelivers ±0.05% full-scale output accuracy and 16-bit resolution, ensuring precise conversion of low-level sensor signals into reliable control signals.
• Dual Input ConfigurationSupports 4 differential or 8 single-ended input channels, offering flexibility to connect multiple sensors of different types (temperature, pressure, vibration, etc.).
• Strong Anti-Interference CapabilityHigh CMRR (≥80 dB) and compliance with IEC 61000-6-2 standards minimize the impact of electromagnetic interference (EMI) and radio frequency interference (RFI) in industrial environments.
• Remote Configuration & DiagnosticsRS485 (Modbus RTU) interface enables remote adjustment of input/output parameters and real-time monitoring of module status, reducing on-site maintenance work.
• Integrated Protection FunctionsReverse polarity protection and overload protection prevent module damage from wiring errors or abnormal signal conditions, enhancing operational reliability.
• Easy Installation & IntegrationDIN rail mounting design simplifies installation in control cabinets, and standardized output signals ensure seamless integration with most PLCs, DCS, and industrial control systems.
• Rugged Environmental AdaptabilityOperates reliably in a wide temperature range (-40 °C to +70 °C) and high humidity (5%–95% non-condensing), suitable for harsh industrial sites.

Application Scenarios

• Oil & Gas IndustrySignal conditioning for pressure, temperature, and flow sensors in refineries, pipelines, and offshore platforms, supporting process control and safety monitoring.
• Power GenerationInterface with vibration, temperature, and pressure sensors in thermal, nuclear, or renewable energy plants to monitor turbine, generator, and boiler operations.
• Chemical & Pharmaceutical IndustryProcessing signals from pH, level, and temperature sensors in reaction vessels and production lines, ensuring compliance with strict process control standards.
• Manufacturing IndustryConditioning signals from production line sensors (e.g., position, force, and temperature sensors) for automated assembly lines, machining centers, and packaging equipment.
• Water & Wastewater TreatmentConverting signals from flow, level, and turbidity sensors in treatment facilities to support pump control, chemical dosing, and water quality monitoring.
• Mining & MetalsHandling signals from load cells, pressure sensors, and temperature sensors in crushers, conveyors, and smelting equipment, withstanding dust and temperature fluctuations.
• Food & Beverage IndustryProcessing signals from temperature, level, and flow sensors in production and packaging lines, meeting hygiene and process control requirements.
