Bently Nevada 136188-01 3500/92 Communication Gateway Module

• Environmental Ratings:
  • Operating Temperature: -30°C to +65°C
  • Storage Temperature: -40°C to +85°C
  • Humidity Range: 95% RH (non-condensing)
• Physical & Mechanical Properties:
  • Dimensions: 241 mm x 24.4 mm x 99.1 mm
  • Weight: 0.44 kg
  • Mounting Requirements: 1 full-height front panel slot in 3500 system rack
  • Construction: Industrial-grade rugged materials for harsh environment resilience

Functional Features

• Comprehensive Communication Capabilities: Combines Ethernet and multi-configurable serial interfaces to support diverse connectivity needs between monitoring systems and external platforms.
• Multi-Protocol Support: Integrates Bently Nevada’s proprietary protocol and industry-standard Modbus RTU/TCP, ensuring compatibility with a wide range of industrial automation and data management systems.
• Centralized Data Aggregation: Consolidates data from all 3500 series monitoring modules (vibration, temperature, speed, etc.) in a single hub, enabling unified access to comprehensive equipment condition data.
• Seamless Software Integration: Communicates with Bently Nevada System 1 condition monitoring and diagnostic software via Ethernet TCP/IP, facilitating advanced data analysis and trend monitoring.
• Easy Configuration: Configurable remotely via 3500 Rack Configuration Software over Ethernet, eliminating the need for on-site adjustments and reducing downtime.
• Clear Status Visibility: Front-panel OK and TX/RX LED indicators provide immediate feedback on module operation and communication status, simplifying troubleshooting and maintenance.
• Rugged Industrial Design: Built to withstand extreme temperatures, high humidity, and harsh industrial conditions, ensuring consistent performance and long service life with minimal maintenance.
• Modular Compatibility: Designed specifically for the 3500 system rack, integrating seamlessly with other 3500 series modules without requiring system modifications.

Application Scenarios

• Power Generation: Facilitates data integration for monitoring turbines, generators, and auxiliary rotating equipment, supporting predictive maintenance and operational safety in power plants.
• Oil and Gas: Enables connectivity for drilling rigs, compressors, and pipeline pumps in upstream, midstream, and downstream operations, ensuring reliable data transmission in hazardous and remote environments.
• Chemical and Petrochemical: Integrates condition data from reactors, agitators, and centrifuges, enhancing process safety and minimizing unplanned downtime in chemical processing facilities.
• Pulp and Paper: Connects monitoring systems for rollers, fans, and pumps in paper mills, supporting continuous production and reducing maintenance costs.
• Mining: Enables data exchange for heavy-duty rotating machinery such as crushers, conveyors, and mills, ensuring operational reliability in harsh mining environments.
• Water Treatment: Integrates monitoring data from pumps, blowers, and mixers in water and wastewater treatment plants, supporting efficient and compliant operations.
• General Manufacturing: Connects condition monitoring systems for motors, gearboxes, and production line equipment, enhancing overall equipment effectiveness and reducing production disruptions.
• Metallurgy and Steel Production: Facilitates data transmission for rolling mills, fans, and compressors in steel plants, ensuring stable operation in high-temperature and high-dust environments.
