Bently 330106-05-30-90-02-05-CN Product Information

Technical Specifications

• Probe Type: 3300 XL series 8mm reverse mount proximity probe
• Manufacturer: Bently Nevada (GE)
• Origin: United States
• Thread Size: M10 x 1 mm
• Total Cable Length: 9.0 meters (29.5 feet)
• Connector Type: Miniature ClickLoc coaxial connector
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Housing Material: AISI 303 or 304 stainless steel
• Measurement Range: 0 to 10 mm
• Sensitivity: 7.87 V/mm (200 mV/mil) ±5%
• Accuracy: ±0.1% full scale; ±0.05 mm
• Resolution: 0.01 mm
• Frequency Response: 0 to 8 kHz
• Operating Temperature Range: Standard: -52°C to +177°C; Extended: -52°C to +218°C (probe tip), -51°C to +260°C (cable and connector)
• DC Resistance: 9.87 ± 0.50 ohms (center conductor to outer conductor)
• Torque Specifications: Maximum rated torque 22.6 N·m (200 in·lbf); Recommended torque 7.5 N·m (66 in·lbf)
• Maximum Thread Engagement: 15 mm
• Pressure Sealing: Viton® O-ring for differential pressure sealing
• Protection Rating: IP67
• Power Supply: 24 V DC
• Power Consumption: Less than 3 W
• Output Signal: 4-20 mA analog output; Voltage signal proportional to distance
• Certifications: CSA, ATEX, IECEx; Compliance with Chinese industrial standards
• Weight: 0.323 kg (probe); Total weight 2.907 kg
• Dimensions: 20.4 cm x 22.2 cm x 3.7 cm
• Compatibility: Fully compatible with Bently Nevada 3300 XL series monitoring systems

Key Features

• Reverse Mount Design: Enables straightforward installation in confined spaces or applications requiring specific orientations, enhancing operational flexibility.
• Extended Cable Length: 9.0-meter cable provides ample reach for complex industrial setups, eliminating the need for additional extension cables.
• Precision Measurement Performance: Delivers high accuracy and resolution for shaft position, displacement, and vibration data, supporting early fault detection.
• Robust Construction: Stainless steel housing and PPS probe tip ensure durability, withstanding extreme temperatures, moisture, dust, and mechanical stress.
• Secure Connectivity: Miniature ClickLoc coaxial connector ensures stable, reliable connections, reducing installation time and connection-related failures.
• Broad Temperature Adaptability: Operates across a wide temperature range, including extended high-temperature options, suitable for diverse harsh environments.
• Electromagnetic Interference Resistance: Maintains reliable data output in electrically noisy industrial settings.
• Multiple Certifications: Holds CSA, ATEX, IECEx approvals and complies with Chinese standards, meeting global and local regulatory requirements.
• Pressure Sealing Capability: Viton® O-ring design provides effective sealing against differential pressures in demanding applications.
• Seamless System Integration: Works flawlessly with Bently Nevada 3300 XL monitoring systems for continuous, real-time condition monitoring.

Application Scenarios

Core Monitoring Functions

• Shaft position monitoring: Tracks relative displacement and alignment of rotating shafts to prevent mechanical collisions.
• Vibration analysis: Measures radial and axial vibration to identify faults such as imbalance, misalignment, and bearing degradation.
• Displacement measurement: Captures precise linear displacement data for critical machinery components.
• Predictive maintenance support: Provides real-time data to enable early detection of potential equipment issues, reducing unplanned downtime.

Typical Industrial Equipment

• Turbines: Gas, steam, and hydro turbines in power generation facilities.
• Compressors: Industrial compressors used in oil and gas, petrochemical, and manufacturing processes.
• Motors and generators: Large-scale electric motors and generators in power plants and industrial energy systems.
• Pumps: Various industrial pumps critical to production and utility workflows.
• Rolling mills: Rotating equipment in metallurgical industries (steel and non-ferrous metal production).
• Fans and blowers: Industrial fans and blowers in manufacturing and processing plants.

Industry Applications

• Power generation: Ensures reliable operation of turbines, generators, and auxiliary equipment in thermal, nuclear, and hydroelectric power plants.
• Oil and gas: Monitors critical machinery in extraction, refining, and pipeline operations, including harsh offshore and onshore environments.
• Petrochemical and chemical processing: Withstands corrosive and high-temperature conditions while monitoring pumps, compressors, and reactors.
• Metallurgical industry: Tracks performance of rolling mills, fans, and other rotating equipment in steel and aluminum production.
• General manufacturing: Supports condition monitoring of production line machinery, HVAC systems, and processing equipment.
• Industrial processing: Maintains integrity of critical rotating equipment in diverse processing facilities, optimizing operational efficiency.
