GE IS220PTURH1A
Technical Specifications:
- Supply Voltage: Typically powered from the system backplane, 24 V DC nominal
- Power Consumption: Low power draw suitable for continuous operation
- Operating Temperature: 0°C to +60°C
- Storage Temperature: -40°C to +85°C
- Humidity Range: 5% to 95% relative humidity, non-condensing
- Relay Outputs: Multiple high-reliability relays for trip and alarm signaling
- Input Compatibility: Accepts discrete and analog inputs from sensors and other control modules
- Communication Interfaces: Integrated with the Speedtronic Mark VI system through backplane connections
- Certifications: UL, CE, and other relevant industrial certifications ensuring safety and reliability standards are met
- Mounting: Rack-mounted within the Speedtronic Mark VI system cabinet
Woodward PEAK200-HVAC 8200-1501
Technical Specifications:
- Model Number: 8200-1501
- Controller Type: Digital microprocessor-based HVAC controller
- Supply Voltage: 24 V AC ± 10%, 50/60 Hz
- Power Consumption: Less than 15 VA
- Operating Temperature: 0°C to +50°C
- Storage Temperature: -25°C to +70°C
- Humidity Range: 5% to 95% relative humidity, non-condensing
BENTLEY 3500/65 145988-02
Technical Specifications:
- Module Type: Keyphasor and Speed Monitoring Module
- Part Number: 145988-02
- System Platform: Bently Nevada 3500 Series Rack
- Input Channels: Accepts signals from one or two Keyphasor or speed sensors (configurable)
- Sensor Compatibility: Compatible with Bently Nevada proximity probes (e.g., 3300 series) and other active or passive speed sensors
- Frequency Range: 0.1 Hz to 20,000 Hz (suitable for low-speed to high-speed machinery)
- Speed Measurement Accuracy: ±0.05% of reading
SAACKE FSC-01
Technical Specifications:
- Supply Voltage: 24 V DC (typical), with options for 110–230 V AC in certain configurations
- Power Consumption: Low power draw, optimized for continuous operation
- Operating Temperature: -10°C to +55°C
- Storage Temperature: -25°C to +70°C
- Humidity Range: 5% to 95% relative humidity, non-condensing
- Protection Rating: IP20 (suitable for indoor panel mounting)
- Input Compatibility: Accepts signals from flame detectors including UV, IR, and ionization sensors
- Output Relays: Equipped with safety-rated relay outputs for burner activation, alarm signaling, and system shutdown
PARKER AR-04AE-13574
BENDER IRDH575B1W-435
Technical Specifications:
-
- Rated Voltage: Up to 690 V AC, 24–300 V DC
- Measuring Range: 0 to 999 kΩ (depending on voltage level)
- Response Time: Rapid detection time for insulation faults
- Operating Temperature: -10°C to +60°C
- Storage Temperature: -25°C to +70°C
- Humidity Range: 0% to 95% relative humidity, non-condensing
- Communication Interfaces: RS-485, Modbus RTU, Ethernet interface for network integration
- Display: LCD display for status indication and parameter setting
GE PQMII-T20
Technical Specifications:
- Measurement Standards: IEC 61000-4-30 Class A compliant for power quality monitoring
- Voltage Inputs: 3-phase or single-phase configurations, typical ranges up to 690 V AC
- Current Inputs: Compatible with Rogowski coils, CTs (current transformers), or clamp sensors
- Sampling Rate: High-speed sampling for transient and waveform capture
- Frequency Range: 45 Hz to 65 Hz (extendable for special applications)
- Voltage Accuracy: ±0.1% of reading
- Current Accuracy: ±0.5% of reading
- Harmonic Analysis: Up to 63rd harmonic for voltage and current
DEIF DLQ144-PC-NB
Technical Specifications:
- Supply Voltage: 24 V DC (standard industrial voltage)
- Power Consumption: Low consumption suitable for energy-efficient applications
- Operating Temperature: -25°C to +70°C, ensuring performance in diverse environments
- Storage Temperature: -40°C to +85°C
- Humidity Range: 5% to 95% relative humidity, non-condensing
- Communication Protocols: Supports Modbus RTU, Modbus TCP, and other standard protocols for integration with SCADA systems
- Dimensions (WxHxD): Compact design suitable for mounting in switchgear cabinets or control panels
- Certifications: CE, UL, and other relevant industry standards
