ALSTOM PIB102A3BEB0180 Intelligent Protection and Control Unit

• Communication Protocols:
  • Supports IEC 61850, Modbus, DNP3, and Profibus for seamless integration with SCADA systems and substation automation.
  • Ethernet and serial communication interfaces for high-speed data exchange.
• Input/Output (I/O) Channels:
  • Multiple digital and analog inputs for connecting sensors, CTs, and voltage transformers (VTs).
  • Programmable relay outputs for tripping, signaling, and control purposes.
• Display and Interface:
  • Built-in LCD display for local monitoring and configuration.
  • Intuitive HMI (Human-Machine Interface) with touchscreen or keypad navigation.
• Environmental Resistance:
  • Operates in temperatures ranging from -40°C to +70°C.
  • Resistant to humidity, dust, vibration, and electromagnetic interference (EMI).
• Physical Dimensions: Compact and rugged enclosure suitable for panel mounting or outdoor installations.

Functional Characteristics:

• Real-Time Monitoring: Continuously monitors electrical parameters such as voltage, current, frequency, and power quality, providing accurate data for system analysis.
• Advanced Protection Algorithms: Implements sophisticated algorithms for fast and accurate fault detection, minimizing downtime and equipment damage.
• Auto-Reclosing: Features configurable auto-reclosing functionality to restore power automatically after transient faults.
• Event Logging and Reporting: Records and stores fault events, operational data, and system alarms for post-event analysis and compliance reporting.
• Remote Configuration and Firmware Updates: Allows remote parameter setting, logic modification, and firmware upgrades via communication networks, reducing maintenance costs.
• Multi-Language Support: Provides user-friendly interfaces in multiple languages for global applications.
• Cybersecurity: Incorporates robust cybersecurity features to protect against unauthorized access and cyber threats.

Application Scenarios:

• Electrical Substations: Used in MV and HV substations for line protection, transformer protection, busbar protection, and feeder control.
• Power Generation: Integrates with generators, wind turbines, and solar inverters for grid stability and protection.
• Industrial Power Distribution: Controls motors, drives, and electrical equipment in manufacturing, mining, and oil and gas industries.
• Renewable Energy Systems: Manages grid-connected and off-grid renewable energy installations, ensuring compliance with grid codes.
• Railway Electrification: Provides traction power system protection and control for electric railways.
• Water and Wastewater Treatment: Monitors and controls pumps, motors, and electrical distribution in water treatment plants.

Key Advantages:

• High Reliability: Built with industrial-grade components and rigorous testing to ensure long-term performance in harsh environments.
• Flexibility: Supports customization of protection settings, control logic, and communication protocols to meet specific application requirements.
• Scalability: Can be integrated into existing substation automation systems or used as a standalone solution for new installations.
• Cost-Effectiveness: Reduces operational costs by minimizing unplanned outages, extending equipment lifespan, and simplifying maintenance.
• Compliance: Meets international standards for electrical protection, safety, and cybersecurity, ensuring regulatory compliance.

Industry Recognition:
ALSTOM is a trusted leader in power system automation, and the PIB102A3BEB0180 unit reflects the company’s commitment to innovation, quality, and customer satisfaction. It is widely adopted by utilities, industrial enterprises, and infrastructure projects worldwide for its advanced features, reliability, and ease of integration.
