ABB TSXP571634M

Technical Specifications
Based on official documentation and supplier catalogs, the technical profile includes:

• Product Type: CPU Processor Module / Logic Controller
• Series Compatibility: Schneider Electric Unity Premium 571×4 Series
• Part Number: TSXP571634M (often with a “C” suffix for conformal coating, e.g., TSXP571634MC)
• Processor: 32-bit microprocessor
• Memory:
  • RAM: 64 KB
  • ROM: 64 KB
  • Program Capacity: Large capacity, suitable for complex logic
• Communication Interface:
  • Ethernet: 10BASE-T/100BASE-TX (RJ45)
  • Optional: FIPIO bus interface (depending on specific variant)
• I/O Capacity: Supports up to 512 I/O points
• Power Supply: Typically powered via the backplane bus (+5 VDC)
• Dimensions: Standard DIN-rail mounted form factor (Width: 35.56 mm, Height: 177.80 mm, Depth: 298.45 mm)
• Environmental Parameters:
  • Operating Temperature: 0°C to +60°C (32°F to 158°F)
  • Storage Temperature: -40°C to +85°C
  • Humidity: 5% to 95% (non-condensing)
• Certifications: Complies with CE, UL, cULus, and other industrial standards

Functional Features

• High-Speed Processing: The module is capable of real-time data transmission. During the PLC input sampling stage, it reads all input states and stores them in registers to ensure the control system responds immediately to changes in field status.
• Integrated Ethernet: Features a built-in Ethernet port for high-speed network communication (10/100 Mbps), enabling connectivity with HMIs, SCADA systems, and other controllers.
• Modular Expansion: Designed to be paired with the CPU and up to two communication modules, enabling a flexible and scalable system architecture. Users can customize communication capabilities (e.g., adding Profibus, Profinet, or Ethernet/IP modules).
• Redundancy Support: The dual communication slots allow for the implementation of redundant network topologies (e.g., ring or star redundancy), ensuring continuous operation even if one network path fails.
• Advanced Diagnostics: Equipped with LED status indicators for power, communication activity, and module health. It performs continuous self-supervision of hardware (CPU, memory, bus interface) and auxiliary supplies.
• Hot-Swap Capability: Designed to support online replacement and maintenance without shutting down the entire control system, significantly reducing downtime.
• Robust Construction: Built with industrial-grade materials to withstand harsh environments, including vibration, electromagnetic interference (EMI), and temperature fluctuations.

Application Scenarios
The ABB TSXP571634M (Schneider Unity Premium CPU) is deployed in sectors requiring high-precision control and robust network infrastructure:

• Industrial Process Automation: Core component in chemical plants, oil refineries, and pulp and paper mills for process control.
• Power Generation and Distribution: Used in thermal power plants, hydroelectric stations, and substation automation for turbine control and grid stability.
• Water and Wastewater Treatment: Manages pumping stations, filtration systems, and chemical dosing processes.
• Building Automation: Controls HVAC systems, lighting, and security in large commercial buildings.
• Manufacturing and Machinery: Serves as the central controller for automotive assembly lines, packaging machinery, and robotic cells.
• Marine and Offshore: Utilized in shipboard propulsion control systems and power management systems due to its resistance to vibration and corrosion.
• Renewable Energy: Integral to wind turbine control systems (pitch and yaw control) and solar power plant inverters.

Market Information and Availability

• Supply Chain: The module is actively traded by specialized industrial automation distributors globally, with a high concentration in China, Europe, and North America. It is often stocked as a critical spare part for maintaining legacy Schneider Electric PLC systems.
• Pricing: Prices vary significantly based on condition (new, refurbished, or surplus) and supplier. Listings from 2026 indicate a price range for the module itself, typically quoted between 150 RMB to over 600 RMB per unit, depending on the specific configuration and warranty terms.
• Packaging & Warranty: Typically shipped in original factory packaging with anti-static protection. Most suppliers offer a one-year warranty for refurbished or surplus units.
• Product Status: The TSXP571634M is a mature but active product. While it is listed as a legacy product for new projects in some contexts, it remains in active demand for system maintenance and retrofits of existing Unity Premium installations.
