ABB FPNO-21 PROFINET IO Adapter Module

Technical Specifications

• Interface Type: Dual-port PROFINET IO interface
• Supported Protocols: PROFINET IO, PROFIdrive, OPC UA (in parallel to the field protocol)
• Conformance Class: Certified according to Conformance Class B (CC-B)
• Network Topology: Supports star, daisy-chain, and ring topologies (Media Redundancy Protocol – MRP)
• Data Transmission Rates: Supports 10 Mbit/s and 100 Mbit/s, with auto-detection of network speed
• S2 Functionality: Enables connection of two PROFINET controllers (one primary and one backup) to ABB drives
• PROFIsafe Support: Supports PROFIsafe over PROFINET (requires FSO-12 or FSO-21 with ACS880)
• SNTP Support: Supports Simple Network Time Protocol (SNTP) for time synchronization
• Operating Temperature: Typically within the range of -20°C to +60°C (may vary based on specific configurations and applications)
• Storage Temperature: -40°C to +85°C
• Enclosure Protection Rating: IP20 or higher (depending on the specific model and application requirements)

Functional Features

• High Reliability: Built with high-quality materials and precision circuitry, ensuring accurate data transmission and long-term reliability.
• Robust Design: Capable of withstanding vibration, shock, and electromagnetic interference, making it suitable for harsh industrial environments.
• Easy Installation: The module is designed for easy installation and configuration, with no special tools required to rename the PROFINET station.
• Media Redundancy: Supports Media Redundancy Protocol (MRP) for enhanced network reliability and availability.
• Shared Device Support: Enables accessing one drive from two controllers via one FPNO-21, facilitating separate PLCs for drive control and safety communication.
• Diagnostic Capabilities: Each channel is equipped with diagnostic features, allowing for quick identification and resolution of issues. LED indicators provide visual feedback on the status of each byte, enhancing troubleshooting efficiency.
• Drive Composer Pro Support: The module is compatible with Drive Composer Pro software, enabling easy start-up and maintenance of ABB drives.

Application Scenarios

• Manufacturing Automation: In manufacturing settings, the FPNO-21 integrates with assembly lines, packaging machines, and material handling systems. It enables precise control of sequential operations, enhancing productivity and quality.
• Process Control: In chemical, petrochemical, and other process industries, the module monitors and controls critical process variables, contributing to operational stability and product quality. It supports the integration of various field devices into the DCS or PLC system.
• Power Generation: The FPNO-21 is widely used in power plants for monitoring and controlling various process parameters, ensuring stable and efficient operation. It interfaces with sensors, actuators, and other devices to provide real-time data and control signals.
• Water Treatment: The module monitors and controls water quality and flow in municipal and industrial water treatment facilities, ensuring compliance with regulatory standards and efficient operation.
• Building Automation: The FPNO-21 supports HVAC, lighting, and security systems in commercial and industrial buildings. It facilitates centralized monitoring and control, contributing to energy efficiency and comfort.
• Transportation: The module is applied in railway signaling, traffic control systems, and other transportation-related applications. Its reliable performance ensures safe and efficient transportation operations.
